APC SMT2200RM2UC uninterruptible power supply (UPS) Line-Interactive 2.2 kVA 1980 W 8 AC outlet(s)
- Brand: APC
- Category:
- SKU: SMT2200RM2UC
- EAN: 0731304331056
2.2 kV, 1.98 kW, 75-154V, 530J, 2U, 480x683x86mm, 43.21kg, Black
Offer details
Trade Prices
| Distributor | Product | SKU | Stock | Updated | Price |
|---|---|---|---|---|---|
|
UPS |
APCSMT2200RM2UC | |||
|
SMART-UPS SMARTCONNECT, 2200VAREMOTE MONT, (6)5-15R,(2)5-20RR/M, 2U L5-20P - 8FT |
956072 | |||
|
Smart-UPS SMT2200RM2UC 2200VA RM 2U LCD 120V with SmartConnect Brown Box |
219520 | |||
|
2200VA Smart UPS C LCD RM |
SMT2200RM2UC | |||
|
SMART UPS 2200VA LCD RM 2U 120V |
2MZ147 | |||
|
APC Smart-UPS 2200VA LCD RM 2U 120V wSC |
APC-SMT2200RM2UC | |||
|
2200VA LCD RM 2U 120V WITH SMARTCONNECT |
5080459 |
Description
Reliable Backup Power and Protection for Your Valuable IT Equipment
Protect your servers, switches, routers and networking devices while providing battery backup power with Smart-UPS SMT2200RM2UC with APC SmartConnect, the first cloud-enabled UPS for distributed IT. The service-free cloud monitoring feature is accessible from any internet-connected device, and maximizes the life and performance of your UPS by providing proactive advice and life-cycle recommendations so you can remotely monitor your power infrastructure from anywhere.
An Overview of Smart-UPS and the SmartConnect App
APC SmartConnect makes Smart-UPS more adaptable and easier to deploy than ever before, enabling you to view the status of your UPS through a secure web portal. Through this intuitive remote management interface, you’ll receive automatic notifications, firmware updates, and advanced support; providing you with added value – and more importantly – added peace of mind.
Secure, remote monitoring
Connected Smart-UPS support remote monitoring through a secure web portal, so you can always be up to date on the status of your power infrastructure.
Proactive lifecycle alerts
Maximize the life span of the UPS and protect your investment with proactive alerts for firmware upgrade, device maintenance, and warranty protection.
Cloud enabled as standard
Smart-UPS models with SmartConnect are cloud-enabled and have a built-in Ethernet port, making it easy and cost effective to monitor your UPS online.
Simple to Use Interface
Our simple web interface is designed to support both system administrators and non-tech users alike, with clear notifications in plain language.
Specifications
| Power | |
|---|---|
| Output frequency | 50/60 Hz |
| Output power | 1980 W |
| Input operation voltage (min) | 75 V |
| Input operation voltage (max) | 154 V |
| Output operation voltage (min) | 110 V |
| Output operation voltage (max) | 127 V |
| Surge energy rating | 530 J |
| Emergency Power Off (EPO) | Yes |
| Output voltage Total Harmonic Distortion (THD) | 5% |
| Output power capacity | 2.2 kVA |
| Input frequency | 50/60 Hz |
| Ports & interfaces | |
| Cable length | 96.1" (2.44 m) |
| USB port | Yes |
| Serial interface | Yes |
| Serial interface type | RJ-45 |
| SmartSlot | Yes |
| AC outlets quantity | 8 AC outlet(s) |
| AC outlet types | NEMA 5-15R,NEMA 5–20R |
| Power plug | NEMA 5-20P |
| Ethernet LAN (RJ-45) ports | 1 |
| Performance | |
| Audible alarm modes | Alarm when on battery, Low battery alarm, Overload alarm |
| UPS topology | Line-Interactive |
| Waveform | Sine |
| Automatic Voltage Regulation (AVR) | Yes |
| LED indicators | Status |
| Noise level | 55 dB |
| Audible alarm(s) | Yes |
| Temperature voltage compensation | Yes |
| Features | |
| Output frequency | 50/60 Hz |
| Web-based management | Yes |
| Audible alarm modes | Alarm when on battery, Low battery alarm, Overload alarm |
| UPS topology | Line-Interactive |
| Waveform | Sine |
| Automatic Voltage Regulation (AVR) | Yes |
| Output power | 1980 W |
| Input operation voltage (min) | 75 V |
| Input operation voltage (max) | 154 V |
| Output operation voltage (min) | 110 V |
| Output operation voltage (max) | 127 V |
| Surge energy rating | 530 J |
| Emergency Power Off (EPO) | Yes |
| Output voltage Total Harmonic Distortion (THD) | 5% |
| Noise level | 55 dB |
| Audible alarm(s) | Yes |
| Output power capacity | 2.2 kVA |
| Temperature voltage compensation | Yes |
| Input frequency | 50/60 Hz |
| Battery | |
| Battery life (max) | 5 year(s) |
| Number of batteries supported | 1 |
| Battery technology | Sealed Lead Acid (VRLA) |
| Battery recharge time | 3 h |
| Hot-swap battery | Yes |
| Cold start | Yes |
| Automatic battery test | Yes |
| Design | |
| Rack capacity | 2U |
| Form factor | Rackmount |
| LED indicators | Status |
| Product colour | Black |
| Certification | CSA, FCC, UL |
| Cable length | 96.1" (2.44 m) |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -15 - 45 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 118110.2" (0 - 3000 m) |
| Non-operating altitude | 0 - 590551.2" (0 - 15000 m) |
| Technical details | |
| Output frequency | 50/60 Hz |
| Sustainability certificates | ENERGY STAR |
| Management features | |
| Web-based management | Yes |
| Weight & dimensions | |
| Weight | 95.2 lbs (43.2 kg) |
| Width | 18.9" (480 mm) |
| Height | 3.39" (86 mm) |
| Depth | 26.9" (683 mm) |
| Package width | 23.6" (600 mm) |
| Package depth | 38.6" (980 mm) |
| Package height | 10" (254 mm) |
| Package weight | 109.6 lbs (49.7 kg) |
| Packaging data | |
| Package width | 23.6" (600 mm) |
| Package depth | 38.6" (980 mm) |
| Package height | 10" (254 mm) |
| Package weight | 109.6 lbs (49.7 kg) |
| Logistics data | |
| Products per pallet | 8 pc(s) |
| Certificates | |
| Certification | CSA, FCC, UL |
