APC SRT2200RMXLA-NC uninterruptible power supply (UPS) Double-conversion (Online) 2.2 kVA 1800 W, 74 in distributor/wholesale stock for resellers to sell

APC SRT2200RMXLA-NC uninterruptible power supply (UPS) Double-conversion (Online) 2.2 kVA 1800 W

Brand: APC
Category:
- Uninterruptible Power Supplies (UPSs)
SKU: SRT2200RMXLA-NC
EAN: 0731304325154
Sell Price:
Contract No:
Account price:

Smart-UPS On-Line, 2200VA, Rackmount 2U, 120V, 6x 5-20R+1x L5-20R NEMA outlets, Network Card, Extended runtime, W/ rail kit

Trade Prices

Product	SKU	Stock
NETWORK CARD	APCSRT2200RMXLA-NC	Register free see stock
SMART-UPS SRT D/CON 2200VA2U, (6)5-20R, (1)L5-20R, 120VR/M, NET CARD L5-20P	928518
UPS SRT2200RMXLA-NC Smart-UPS SRT 2200VA RM 120V Network Card Retail	194511
Smart UPS SRT 2200VA RM 120V	SRT2200RMXLANC
APC SMART-UPS SRT 2200VA RM	4T3698
APC Smart-UPS SRT 2200VA RM 120V N. Card	APC-SRT2200RMXLANC
APC Smart-UPS SRT 2200VA RM	4657981

Reasons To Buy

Text and mimic diagrams that display modes of operation, system parameters and alarms.

Mini slot supports various optional management cards which provide basic or essential monitoring, management and control features for the UPS.

Operating mode that by-passes unused electrical components in good power conditions to achieve high operating efficiency without sacrificing protection.

Full color text and mimic diagrams that easily display modes of operation, systems parameters and alarms.

Provides early-warning fault analysis on batteries enabling timely preventive maintenance

Protects the initial investment in the UPS when migrating from tower to rack-mount environment.

Rack/Tower convertible

Protects the initial investment in the UPS when migrating from tower to rack-mount environment.

Description

This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. This 2200VA on-line 2U rackmount UPS provides pure sine wave power and extended runtime to support critical electronics during power disruptions. It comes with NEMA 5-15P input and 6x NEMA 5-15R and 1x NEMA L5-20R outlets. The UPS has a preinstalled Network Management Card for UPS network-based monitoring and management. This On-Line UPS features Unity Power Factor for best-in-class power density. With 7 outlets and a compatibility with external battery packs, this server UPS provides uninterrupted and scalable battery power to connected electronics. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. This UPS includes a pre-installed Network Management Card (model AP9631) via the SmartSlot, to remotely monitor and control the UPS by connecting it directly to the network. The UPS has a 3-year warranty, and the built-in lead-acid battery has a 2-year warranty. Use the intuitive LCD interface and PowerChute Business software to configure settings and monitor usage. Audible alarms also provide notification of changing utility power and UPS conditions. The SRT2200RMXLA-NC converts from a tower or stand-alone UPS to a rack mount UPS, offering flexibility in various installations. This 1800 watt UPS offers a green mode to ensure you are operating at the highest level of efficiency while it’s smart battery management maximizes performance. Two switchable outlet groups are included for individual load management. Predictive battery management provides an estimated date of when battery replacement is recommended. Package Contains UPS, CD with software, Documentation CD, Installation guide, Network management card, Rack mounting brackets, Rack mounting hardware, Rack mounting support rails, USB cable, Warranty card.

Specifications

Power
Output frequency	50/60 Hz
Output power	1800 W
Input operation voltage (min)	120 V
Input operation voltage (max)	120 V
Output operation voltage (min)	120 V
Output operation voltage (max)	120 V
Surge energy rating	340 J
Emergency Power Off (EPO)	Yes
Output voltage Total Harmonic Distortion (THD)	2%
Crest factor	3:1
Output power capacity	2.2 kVA
Single-phase input voltage supported	120 V
Input frequency	40/70 Hz
Ports & interfaces
Cable length	70.9" (1.8 m)
USB port	Yes
Serial interface	Yes
Serial interface type	RJ-45
SmartSlot	Yes
AC outlet types	NEMA 5–20R, NEMA L5-20R
Power plug	NEMA 5-20P
Performance
UPS topology	Double-conversion (Online)
Waveform	Sine
Auto-restart	Yes
Number of output phases	1
Number of input phases	1
LED indicators	Alarm, Status
Surge protection	Yes
Noise level	55 dB
Audible alarm(s)	Yes
Features
Output frequency	50/60 Hz
UPS topology	Double-conversion (Online)
Waveform	Sine
Auto-restart	Yes
Number of output phases	1
Number of input phases	1
Output power	1800 W
Input operation voltage (min)	120 V
Input operation voltage (max)	120 V
Output operation voltage (min)	120 V
Output operation voltage (max)	120 V
Surge energy rating	340 J
Surge protection	Yes
Emergency Power Off (EPO)	Yes
Output voltage Total Harmonic Distortion (THD)	2%
Noise level	55 dB
Crest factor	3:1
Audible alarm(s)	Yes
Output power capacity	2.2 kVA
Single-phase input voltage supported	120 V
Input frequency	40/70 Hz
Battery
Battery life (max)	5 year(s)
Battery capacity	306 Ah
Battery technology	Sealed Lead Acid (VRLA)
Battery recharge time	3 h
Hot-swap battery	Yes
Cold start	Yes
Automatic battery test	Yes
Replacement battery cartridge	APCRBC141
Battery replacement accessibility	End-user
Design
International Protection (IP) code	IP20
Rack capacity	2U
Form factor	Rackmount/Tower
LED indicators	Alarm, Status
Product colour	Black
Certification	ENERGY STAR V2.0 (USA)
Cable length	70.9" (1.8 m)
Display type	LCD
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95%
Storage relative humidity (H-H)	0 - 95%
Operating altitude	0 - 118110.2" (0 - 3000 m)
Technical details
Output voltage	120 V
Output frequency	50/60 Hz
Mounting	front; horizontal
Sustainability certificates	ENERGY STAR
Total carbon footprint (kg of CO2e)	5956.2860008137
Compliance certificates	RoHS, REACH, WEEE
Certificates
Certification	ENERGY STAR V2.0 (USA)
Waste Electrical and Electronic Equipment (WEEE) compliance	Yes
Compliance certificates	RoHS, REACH, WEEE
Certification
Waste Electrical and Electronic Equipment (WEEE) compliance	Yes
Sustainability
Sustainability certificates	ENERGY STAR
Weight & dimensions
Package width	23.6" (599 mm)
Package depth	31.9" (810 mm)
Package height	9.69" (246 mm)
Weight	55.1 lbs (25 kg)
Width	17" (432 mm)
Package weight	75 lbs (34 kg)
Height	3.35" (85 mm)
Depth	23" (584 mm)
Packaging data
Package width	23.6" (599 mm)
Package depth	31.9" (810 mm)
Package height	9.69" (246 mm)
Package weight	75 lbs (34 kg)
Logistics data
Products per pallet	12 pc(s)
Customs product code (TARIC)	8504409590
Total carbon footprint (kg of CO2e)	5956.2860008137
Other features
Output voltage	120 V
Mounting	front; horizontal
Input connection type	NEMA 5-20P
Output connection type	6 NEMA5-20R; 1 NEMAL5-20R
