APC Smart-UPS X 3000VA uninterruptible power supply (UPS) Line-Interactive 3 kVA 2700 W 7 AC outlet(s)

APC Smart-UPS X 3000VA uninterruptible power supply (UPS) Line-Interactive 3 kVA 2700 W 7 AC outlet(s)

Smart-UPS X 3000VA Rack/Tower LCD 100-127V

Trade Prices

Distributor Product SKU Stock Updated Price
Accutech Data Supplies

UPS

APCSMX3000RMLV2U Register free see stock
Anixter

SMART-UPS X LINE INTER 3000VA2U (3)5-20R,(1)L5-30R,(3)5-15R100-127V,R/T, L6-30P

427483
D&H

3kVA Smart UPS X LCD

SMX3000RMLV2U
Ingram Micro

SMART UPS X 3000VA RACK/TOWER

DX4707
ScanSource

APC Smart-UPS X 3000VA Rack/ Tower LCD 1

APC-SMX3000RMLV2U
TD Synnex

APC Smart-UPS X 3000VA Rack/Tower

2838552

Description

Intelligent and efficient network power protection from entry level to scalable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices.

This APC Smart-UPS is designed for IT managers or network administrators to maintain business uptime, data transfer and continuity during prolonged power outages. The 2880VA line interactive 2U rack/tower UPS provides pure sine wave power to support critical electronics during power disruptions. The SMX comes with NEMA L5-30P input, 3x NEMA 5-15R, 3x NEMA 5-20R and 1x NEMA L5-30R outlets. The UPS has a SmartSlot for optional Network Management Card that enables graceful shutdown of physical servers, virtual machines & HCI Clusters via PowerChute Network Shutdown. This uninterrupted power supply can connect to EcoStruxure IT or third-party centralized management platforms. The SMX UPS has a 3-year warranty, and the built-in lead-acid battery has a 2-year warranty. This is compatible with dedicated user-replaceable battery, and the APC replacement battery cartridge helps restore UPS performance to the original specifications. The Smart-UPS comes with a pair of tower-mounting stabilizing feet and rack-mounting brackets. The 3 switchable outlet groups allow more granular management of the power supplied to your devices. The Emergency Power Off feature enables the UPS to remotely shutdown during emergencies.

Specifications

Power
Output frequency50/60 Hz
Output power2700 W
Input operation voltage (min)100 V
Input operation voltage (max)127 V
Output operation voltage (min)100 V
Output operation voltage (max)127 V
Surge energy rating540 J
Efficiency98%
Output voltage Total Harmonic Distortion (THD)5%
Output power capacity3 kVA
Input frequency50/60 Hz
Ports & interfaces
Cable length94.5" (2.4 m)
USB portYes
Serial interfaceYes
SmartSlotYes
AC outlets quantity7 AC outlet(s)
AC outlet typesNEMA 5–15R, NEMA 5–20R, NEMA L5-30R
Ethernet LAN (RJ-45) ports1
Battery
Battery typeRBC117
Battery technologyLead-Acid
Battery recharge time3 h
Typical backup time at full load6.15 min
Performance
Audible alarm modesAlarm when on battery, Low battery alarm
UPS topologyLine-Interactive
WaveformSine
Number of output phases1
LED indicatorsYes
Surge protectionYes
Surge protection featuresNetwork
Noise level55 dB
Audible alarm(s)Yes
Features
Output frequency50/60 Hz
Audible alarm modesAlarm when on battery, Low battery alarm
UPS topologyLine-Interactive
WaveformSine
Number of output phases1
Output power2700 W
Input operation voltage (min)100 V
Input operation voltage (max)127 V
Output operation voltage (min)100 V
Output operation voltage (max)127 V
Surge energy rating540 J
Efficiency98%
Surge protectionYes
Surge protection featuresNetwork
Output voltage Total Harmonic Distortion (THD)5%
Noise level55 dB
Audible alarm(s)Yes
Output power capacity3 kVA
Input frequency50/60 Hz
Heat dissipation276 BTU/h
Design
Rack capacity2U
Form factorRackmount/Tower
LED indicatorsYes
Product colourBlack
CertificationBSMI,CSA,EN 50091-2,EN 55022 A,FCC 15 A,NOM,TUV,UL 1778,VCCI A
Cable length94.5" (2.4 m)
Control typeButtons
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 45 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 118110.2" (0 - 3000 m)
Non-operating altitude0 - 600000" (0 - 15240 m)
Technical details
Output frequency50/60 Hz
Harmonized System (HS) code8504.40
Compliance certificatesRoHS
Certificates
CertificationBSMI,CSA,EN 50091-2,EN 55022 A,FCC 15 A,NOM,TUV,UL 1778,VCCI A
Compliance certificatesRoHS
Weight & dimensions
Package width34.2" (869 mm)
Package depth23.5" (596 mm)
Package height9.57" (243 mm)
Weight84.9 lbs (38.5 kg)
Width17" (432 mm)
Package weight100.1 lbs (45.4 kg)
Height3.35" (85 mm)
Depth26.3" (667 mm)
Packaging data
Package width34.2" (869 mm)
Package depth23.5" (596 mm)
Package height9.57" (243 mm)
Package weight100.1 lbs (45.4 kg)
Logistics data
Export Control Classification Number (ECCN)EAR99
Harmonized System (HS) code8504.40
Other features
Battery typeRBC117
