AirLive AC-1200R wireless router Gigabit Ethernet Dual-band (2.4 GHz / 5 GHz) White
- Brand: AirLive
- Category:
- SKU: AC-1200R
- EAN: 4719869617705 14719869617702
1200Mbps 802.11ac, WAN/4xLAN, 5Ghz/2.4GHz, White
Offer details
Trade Prices
| Distributor | Product | SKU | Stock | Updated | Price |
|---|---|---|---|---|---|
|
- 1200Mbps 802.11AC AP Router AC1200R |
AC-1200R |
Description
802.11ac 1200Mbps Concurrent Dual Band
The AC-1200R use the next generation WiFi technology that allows the router to connect with both 5Ghz and 2.4GHz wireless device at speed up to 1200Mbps. It is also completely compatible with legacy 11n, 11a, 11g, and 11b devices.
50% Greater Coverage
Hi-Power radios and MIMO antennas enable the AC-1200R to provide up to 1.5 times the coverage comparing to normal wireless routers. That means faster speed at further distance.
Digital Home Network
The AC-1200R’s dual radio system is designed for digital home applications. The 5GHz network is less vulnerable to interference; therefore, it is suitable for video streaming and game networks. The 2.4GHz radio provides a separate network for computers, tablet PC, and smart phones.
In addition, the AC-1200R includes 5 Gigabit LAN ports which allow maximum speed connection with NAS or PC.
Free Central management software
The free AirLive Central software can discover your router automatically, let you change settings, or even upgrade firmware in a very easy to use interface. You can even do group configuration and firmware upgrades multiple AirLive products such as AC-1200Rs, AC.TOP, and N.TOP. Please check the video below for details.
Independent Radio Operation
The AC-1200R inherited the capability of our popular G.DUO and A.DUO access points. Each radio can operate in different modes for up to 5 different wireless modes. You can configure the AC-1200R to suit different operation environment.
Detachable Antennas
5 operations with detachable antennas allow the AC-1200R to use in various indoor + outdoor application, such as sharing a remote internet connection signal from outside.
The AC-1200R use the next generation WiFi technology that allows the router to connect with both 5Ghz and 2.4GHz wireless device at speed up to 1200Mbps. It is also completely compatible with legacy 11n, 11a, 11g, and 11b devices.
50% Greater Coverage
Hi-Power radios and MIMO antennas enable the AC-1200R to provide up to 1.5 times the coverage comparing to normal wireless routers. That means faster speed at further distance.
Digital Home Network
The AC-1200R’s dual radio system is designed for digital home applications. The 5GHz network is less vulnerable to interference; therefore, it is suitable for video streaming and game networks. The 2.4GHz radio provides a separate network for computers, tablet PC, and smart phones.
In addition, the AC-1200R includes 5 Gigabit LAN ports which allow maximum speed connection with NAS or PC.
Free Central management software
The free AirLive Central software can discover your router automatically, let you change settings, or even upgrade firmware in a very easy to use interface. You can even do group configuration and firmware upgrades multiple AirLive products such as AC-1200Rs, AC.TOP, and N.TOP. Please check the video below for details.
Independent Radio Operation
The AC-1200R inherited the capability of our popular G.DUO and A.DUO access points. Each radio can operate in different modes for up to 5 different wireless modes. You can configure the AC-1200R to suit different operation environment.
Detachable Antennas
5 operations with detachable antennas allow the AC-1200R to use in various indoor + outdoor application, such as sharing a remote internet connection signal from outside.
Specifications
| Wireless LAN features | |
|---|---|
| WLAN data transfer rates supported | 866,11,54,300 Mbit/s |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| WLAN data transfer rate (max) | 300 Mbit/s |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Wi-Fi standards | Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Ethernet LAN features | |
| Ethernet WAN | Yes |
| Ethernet LAN interface type | Gigabit Ethernet |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
| Mobile network | |
| Mobile network connection | No |
| 3G | No |
| 4G | No |
| Performance | |
| Built-in processor | Yes |
| Internal memory | 64 MB |
| Flash memory | 8 MB |
| Processor model | MediaTek MT7620A |
| WAN connection | |
| Ethernet WAN | Yes |
| Network | |
| Ethernet LAN interface type | Gigabit Ethernet |
| Ethernet LAN | Yes |
| Networking standards | IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 4 |
| DC-in jack | Yes |
| Management features | |
| Web-based management | Yes |
| Reset button | Yes |
| Security | |
| Security algorithms | 802.1x RADIUS, WPA2-PSK, WEP, WPA-PSK |
| MAC address filtering | Yes |
| Filtering | Yes |
| Design | |
| Product colour | White |
| Certificates | |
| Certification | CE, FCC |
| Other features | |
| Internal memory | 64 MB |
| Flash memory | 8 MB |
| Mobile network connection | No |
| WLAN data transfer rates supported | 866,11,54,300 Mbit/s |
| Input current | 1 A |
| Frequency band | 2.4 & 5 |
| Features | |
| Certification | CE, FCC |
| Built-in processor | Yes |
| Internal memory | 64 MB |
| Flash memory | 8 MB |
| Processor model | MediaTek MT7620A |
| Operational conditions | |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Weight & dimensions | |
| Width | 6.18" (157 mm) |
| Weight | 10.8 oz (305 g) |
| Height | 1.18" (30 mm) |
| Depth | 5" (127 mm) |
