Fluke TL175E Test lead
- Brand: Fluke
- Category:
- SKU: TL175E
- EAN: 0095969528887 0768724934635
TL175 TwistGuard Test Leads
Offer details
Trade Prices
| Distributor | Product | SKU | Stock | Updated | Price |
|---|---|---|---|---|---|
|
TEST LEAD SET, ADJUSTABLE,CAT II 1000 VOLT, CAT III1000 VOLT, CAT IV |
937662 | |||
|
TWISTGUARDTM TEST LEADS 2MM DIA |
02NL81 |
Related Products
-
Category: Test Probes
Description
The Fluke TL175 TwistGuard™ Test Leads offer adjustable length test tips for use in different measurement environments. The TwistGuard™ adjustable tips enhance safety and versatility length. The WearGuard™ indicator shows damage to leads and provides heavy duty strain relief to withstand over 30,000 bends.
- Patented TwistGuard™ extendable tip shroud meets the highest electrical safety requirements to reduce tip exposure while providing the versatility needed for most measurements
- New WearGuard™ lead wire wear indication. Each test lead is covered by two layers of silicone insulation; inner contrasting color is exposed when the leads are nicked, scuffed, or otherwise damaged and in need of replacement
- Double insulated silicone leads. TL175 test leads withstand high temperatures and remain flexible in cold temperatures
- Extra-heavy duty strain relief on both probe-end and plug-end, tested beyond 30,000 bends without failure
- Universal input plugs are compatible with all instruments that accept standard 4 mm shrouded banana plugs
- Ratings: CAT II 1000 V, CAT III 1000 V, CAT IV 600 V, 10 A max., Pollution Degree 2
- TL175E also available. Includes removable 4 mm lantern tips that thread onto the lead tip
- Probes always show correct category rating for tip being used
- Environmental ratings: -20°C to 55°C (-4°F to 131°F), altitude: 2000 m (6,562 ft)
- Conforms to EN61010-031
- One-year warranty
- Patented TwistGuard™ extendable tip shroud meets the highest electrical safety requirements to reduce tip exposure while providing the versatility needed for most measurements
- New WearGuard™ lead wire wear indication. Each test lead is covered by two layers of silicone insulation; inner contrasting color is exposed when the leads are nicked, scuffed, or otherwise damaged and in need of replacement
- Double insulated silicone leads. TL175 test leads withstand high temperatures and remain flexible in cold temperatures
- Extra-heavy duty strain relief on both probe-end and plug-end, tested beyond 30,000 bends without failure
- Universal input plugs are compatible with all instruments that accept standard 4 mm shrouded banana plugs
- Ratings: CAT II 1000 V, CAT III 1000 V, CAT IV 600 V, 10 A max., Pollution Degree 2
- TL175E also available. Includes removable 4 mm lantern tips that thread onto the lead tip
- Probes always show correct category rating for tip being used
- Environmental ratings: -20°C to 55°C (-4°F to 131°F), altitude: 2000 m (6,562 ft)
- Conforms to EN61010-031
- One-year warranty
Specifications
| Features | |
|---|---|
| Product type | Test lead |
| Measurement category supported | CAT II, CAT III, CAT IV |
| Exposed probe tip length (min) | 0.157" (4 mm) |
| Exposed probe tip length (max) | 0.748" (1.9 cm) |
| Certification | EN61010-031 |
| Compatible products | Fluke 110 Plus, 113, 114, 115, 116, 117, 175, 177, 179 True RMS, 190-062/S, 190-102, 190-102/S, 190-104, 190-104/S, 190-202, 190-202/S, 190-204, 190-204/S, 190-504, 190-504/S, 233, 28 II Ex, 287, 289, 3000 FC GM, 3000 FC HVAC, 3000 FC IND, 3000 FC,323, 324, 345, 373, 381, 7 IV, FLK-A3000 FC Kit, FLK-A3001 FC Kit, CNX 3000 HVAC, CNX 3000 IND, CNX a3000, CNX v3000 |
| Operational conditions | |
| Operating temperature (T-T) | -20 - 55 °C |
| Maximum operating altitude | 78740.2" (2000 m) |
