Globalsat BU-353-S4 GPS receiver module USB 48 channels Black

Globalsat BU-353-S4 GPS receiver module USB 48 channels Black

  • Brand: Globalsat
  • Category:
  • SKU: BU353-S4
  • EAN: 0795945023206 0754262049467 06 ...2049467 0611101598527 0702071325548 7129985186516 7387809162942 0795945995251 0172302620955 0132017983387 7802880555501 6902809211721 0531479635252 7445803218468 0600978771089 0168141414367 0172304218709 7262318388192 0803983012479 0780411581540 0610098743460 5054894644180 0872182764687 0807320378532 5057665076388 5057643517766 0763551823091 5055147583577 7340004674870more
SiRF Star IV, Built-in SuperCap, USB interface, WAAS ENGOS

Trade Prices

Distributor Product SKU Stock Updated Price
TeleDynamics

USG SiRFIV USB GPS Receiver

USG-BU353-S4 Register free see stock

Description

The BU-353-S4 is a USB magnet mount GPS receiver that features a highly sensitive, low power consumption chipset in a ultra compact form factor compatible with Microsoft Windows 8. The BU-353-S4 is powered by a SiRF Star IV GPS chipset, and will provide you with superior performance in urban canyons, and in dense foliage. With the SiRF CGEE (Client Generated Extended Ephemeris) technology, has the capability of predicting satellite positions for up to 3 days in advance, and will deliver a CGEE-start time of less than 15 seconds under most conditions without any network assistance. The Bu-353-S4's MicroPower mode allows the receiver to stay in a hot start-like condition almost continuously while consuming very little power.

Specifications

GPS Performance
InterfaceUSB
Frequency1575.42 MHz
Sensitivity-163 dBmW
Channels quantity48 channels
Acquisition times - cold35 s
Acquisition times - hot1 s
Acquisition times - warm35 s
GPS accuracy - position98.4" (2.5 m)
Update rate1 Hz
Reacquisition0.1 s
Navigation protocolsNMEA 0183
Technical details
Product colourBlack
Weight & dimensions
Weight2.2 oz (62.4 g)
Software
Windows operating systems supportedYes
Mac operating systems supportedYes
Operational conditions
Operating temperature (T-T)-40 - 85 °C
Storage temperature (T-T)-40 - 85 °C
Operating relative humidity (H-H)0 - 95%
