HPE Aruba Networking AP-635 (RW) Tri Radio 2x2 Wi-Fi 6E Internal Antennas 5-pack Campus Access Point

HPE Aruba Networking AP-635 (RW) Tri Radio 2x2 Wi-Fi 6E Internal Antennas 5-pack Campus Access Point

HPE Aruba Networking AP-635 (RW) Tri Radio 2x2 Wi-Fi 6E Internal Antennas 5-pack Campus Access Point, 2.4 GHz, 5 GHz, 6 GHz, 2400 Mbit/s, WPA, WPA2, WPA3, 2500,5000 Mbit/s

Trade Prices

Distributor Product SKU Stock Updated Price
D&H

HPE ANW AP-635 (RW) 5pk Campus

 S3J35A Register free see stock
Ingram Micro

HPE ANW AP-635 RW 5PK CAMPUS AP

 NJ5159
ScanSource

HPE ANW AP-635 (RW) 5pk Campus AP

 HPE-S3J35A
TD Synnex

HPE ANW AP-635 (RW) 5pk Campus AP

 9805476
TD Synnex

LA HPE Aruba Networking AP-635 (RW) Tri Radio 2x2 Wi-Fi 6E Internal Antennas 5-pack Campus Access Point

 14007534

Related Products

Reasons To Buy

More Capacity and Wider Channels with Wi-Fi 6E

The HPE Aruba Networking 630 Series Campus Access Points deliver a maximum aggregate 3.9 Gbps data rate for higher throughput and faster speeds.
With up to seven 160 MHz channels, the APs help maximize performance for low-latency, bandwidth-hungry applications.
It is designed for low power indoor (LPI) environments.

Less Interference and Fewer Coverage Gaps

The HPE Aruba Networking 630 Series Campus Access Points provide comprehensive tri-band coverage using three radios.
The unique ultra tri-band (UTB) filtering mitigates interference among 5 GHz and 6 GHz radios and prevents gaps in channel coverage.
Since only Wi-Fi 6E devices can operate in the 6 GHz band, it is less congested with no interference from legacy devices.

Extends capabilities of Wi-Fi 6 (802.11ax) APs

HPE Aruba Networking 630 Series Campus Access Points are based on the 802.11ax standard so multiuser efficiency and security features are applied to Wi-Fi 6E.
Unique capabilities include HPE Aruba Networking ClientMatch, advanced cellular coexistence (ACC), and intelligent power monitoring (IPM) to optimize user experience and energy use.

Ensures Business Continuity and High Availability

High availability with two HPE Smart Rate Ethernet ports offer true hitless failover for both data and power.
Cloud, controller, or controllerless operation modes address all campus, branch, and remote use cases.

Description

HPE Aruba Networking AP-635 (RW) Tri Radio 2x2 Wi-Fi 6E Internal Antennas 5-pack Campus Access Point. 2.4 GHz, 5 GHz, 6 GHz, Maximum data transfer rate: 2400 Mbit/s. Security algorithms: WPA, WPA2, WPA3. Ethernet LAN data rates: 2500,5000 Mbit/s. Power over Ethernet (PoE). Product color: White

Specifications

Data transmission
Ethernet LAN data rates2500,5000 Mbit/s
Maximum data transfer rate2400 Mbit/s
Performance
2.4 GHzYes
5 GHzYes
GPS (satellite)Yes
Frequency band20/40 (2.4 GHz), 20/40/80 (5 GHz), 20/40/80/160 (6 GHz), and maximum peak data rate 3.9 Gbps
Networking standardsIEEE 802.11ax, IEEE 802.11mc
Modulation16-QAM, 64-QAM, 256-QAM, 1024-QAM, BPSK, CCK, QPSK
Ethernet LAN data rates2500,5000 Mbit/s
CertificationUL2043 plenum rating Wi‑Fi Alliance: Wi-Fi CERTIFIED a, b, g, n, ac Wi-Fi CERTIFIED 6E (ax, 6 GHz) WPA, WPA2 and WPA3—Enterprise with CNSA option, Personal (SAE), Enhanced Open (OWE) WMM, WMM-PS, W-Fi Agile Multiband Bluetooth SIG Ethernet Alliance (PoE, PD device, class 5)
Maximum data transfer rate2400 Mbit/s
MIMOYes
Compatible operating systemsAP-634 (excluding 6 GHz support): HPE Aruba Networking Wireless Operating System and HPE Aruba Networking Instant OS 8.11.2.0, HPE Aruba Networking Wireless Operating System 10.6.0.0 AP-634 (including 6 GHz support): HPE Aruba Networking Wireless Operating System and HPE Aruba Networking Instant OS 8.12.0.0, HPE Aruba Networking Wireless Operating System 10.7.0.03 AP-635: HPE Aruba Networking Wireless Operating System and HPE Aruba Networking Instant OS 8.9.0.0, HPE Aruba Networking Wireless Operating System 10.4.0.0 Standard power product class operation of the AP-634 is only supported on HPE Aruba Networking OS 10.7.0.0 and later deployments and HPE Aruba Networking OS 8.12.0.0 and later deployments that include a HPE Aruba Networking Mobility Conductor. Standard power operation is not supported on Instant OS deployments or 8.x HPE Aruba Networking OS deployments without a HPE Aruba Networking Mobility Conductor.
Wireless LAN features
Frequency band20/40 (2.4 GHz), 20/40/80 (5 GHz), 20/40/80/160 (6 GHz), and maximum peak data rate 3.9 Gbps
Modulation16-QAM, 64-QAM, 256-QAM, 1024-QAM, BPSK, CCK, QPSK
Network
Networking standardsIEEE 802.11ax, IEEE 802.11mc
Ports & interfaces
I/O portsE0, E1: Two Ethernet wired network ports (RJ-45) USB 2.0 host interface (Type A connector) Serial console interface (proprietary, micro-B USB physical jack) Kensington security slot
USB 2.0 ports quantity1
Ethernet LAN (RJ-45) ports2
Features
6 GHzYes
2.4 GHzYes
5 GHzYes
GPS (satellite)Yes
Frequency band20/40 (2.4 GHz), 20/40/80 (5 GHz), 20/40/80/160 (6 GHz), and maximum peak data rate 3.9 Gbps
Networking standardsIEEE 802.11ax, IEEE 802.11mc
Modulation16-QAM, 64-QAM, 256-QAM, 1024-QAM, BPSK, CCK, QPSK
Ethernet LAN data rates2500,5000 Mbit/s
Maximum data transfer rate2400 Mbit/s
BluetoothYes
Bluetooth version5.0
MIMOYes
Compatible operating systemsAP-634 (excluding 6 GHz support): HPE Aruba Networking Wireless Operating System and HPE Aruba Networking Instant OS 8.11.2.0, HPE Aruba Networking Wireless Operating System 10.6.0.0 AP-634 (including 6 GHz support): HPE Aruba Networking Wireless Operating System and HPE Aruba Networking Instant OS 8.12.0.0, HPE Aruba Networking Wireless Operating System 10.7.0.03 AP-635: HPE Aruba Networking Wireless Operating System and HPE Aruba Networking Instant OS 8.9.0.0, HPE Aruba Networking Wireless Operating System 10.4.0.0 Standard power product class operation of the AP-634 is only supported on HPE Aruba Networking OS 10.7.0.0 and later deployments and HPE Aruba Networking OS 8.12.0.0 and later deployments that include a HPE Aruba Networking Mobility Conductor. Standard power operation is not supported on Instant OS deployments or 8.x HPE Aruba Networking OS deployments without a HPE Aruba Networking Mobility Conductor.
Security
Security algorithmsWPA, WPA2, WPA3
Power
Power over Ethernet (PoE)Yes
Design
PlacementCeiling
Product colourWhite
CertificationUL2043 plenum rating Wi‑Fi Alliance: Wi-Fi CERTIFIED a, b, g, n, ac Wi-Fi CERTIFIED 6E (ax, 6 GHz) WPA, WPA2 and WPA3—Enterprise with CNSA option, Personal (SAE), Enhanced Open (OWE) WMM, WMM-PS, W-Fi Agile Multiband Bluetooth SIG Ethernet Alliance (PoE, PD device, class 5)
Recommended usageIndoor
Antenna
Antenna typeInternal
Antenna gain level (max)7 dBi
Antenna direction typeOmni-directional
Antenna featuresIntegrated antenna
Technical details
MountingThe AP-635 built-in antennas are optimized for horizontal orientation of the AP, mounted at a typical ceiling height.
Weight (imperial)2.86 lbs
Compliance certificatesFederal Communications Commission (FCC), ISED, CE, Electromagnetic Compatibility (EMC), Low Voltage Directive (LVD)
Certificates
CertificationUL2043 plenum rating Wi‑Fi Alliance: Wi-Fi CERTIFIED a, b, g, n, ac Wi-Fi CERTIFIED 6E (ax, 6 GHz) WPA, WPA2 and WPA3—Enterprise with CNSA option, Personal (SAE), Enhanced Open (OWE) WMM, WMM-PS, W-Fi Agile Multiband Bluetooth SIG Ethernet Alliance (PoE, PD device, class 5)
Compliance certificatesFederal Communications Commission (FCC), ISED, CE, Electromagnetic Compatibility (EMC), Low Voltage Directive (LVD)
Weight & dimensions
Width8.66" (220 mm)
Depth1.97" (50 mm)
Weight2.87 lbs (1.3 kg)
Height8.66" (220 mm)
Other features
MountingThe AP-635 built-in antennas are optimized for horizontal orientation of the AP, mounted at a typical ceiling height.
I/O portsE0, E1: Two Ethernet wired network ports (RJ-45) USB 2.0 host interface (Type A connector) Serial console interface (proprietary, micro-B USB physical jack) Kensington security slot
Weight (imperial)2.86 lbs
Operational conditions
Operating relative humidity (H-H)5 - 95%
Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-40 - 70 °C
Storage relative humidity (H-H)10 - 100%
System requirements
Compatible operating systemsAP-634 (excluding 6 GHz support): HPE Aruba Networking Wireless Operating System and HPE Aruba Networking Instant OS 8.11.2.0, HPE Aruba Networking Wireless Operating System 10.6.0.0 AP-634 (including 6 GHz support): HPE Aruba Networking Wireless Operating System and HPE Aruba Networking Instant OS 8.12.0.0, HPE Aruba Networking Wireless Operating System 10.7.0.03 AP-635: HPE Aruba Networking Wireless Operating System and HPE Aruba Networking Instant OS 8.9.0.0, HPE Aruba Networking Wireless Operating System 10.4.0.0 Standard power product class operation of the AP-634 is only supported on HPE Aruba Networking OS 10.7.0.0 and later deployments and HPE Aruba Networking OS 8.12.0.0 and later deployments that include a HPE Aruba Networking Mobility Conductor. Standard power operation is not supported on Instant OS deployments or 8.x HPE Aruba Networking OS deployments without a HPE Aruba Networking Mobility Conductor.
