HPE V 1410-8G Unmanaged Gigabit Ethernet (10/100/1000) Gray

HPE V 1410-8G Unmanaged Gigabit Ethernet (10/100/1000) Gray

  • Brand: HPE
  • Category:
  • SKU: J9559-61001
  • EAN:
HP 1410-8G Switch

Trade Prices

Distributor Product SKU Stock Updated Price
Depot International

HP STOCK, NEEDS APPROVAL PRIOR TO PURCHASE. EMAIL FOR QUOTE

 J9559-61001 Register free see stock

Related Products

Description

HP 1410 series switches are unmanaged Gigabit Ethernet and Fast Ethernet switches designed for small businesses looking for entry-level, low-cost networking solutions with a lifetime warranty. The HP 1410 switch series consists of seven models with flexible mounting options that allow customers to choose the best switch to meet their network switching needs. All models have QoS support and IEEE 802.3x flow control features to provide outstanding data efficiency. Simplified plug-and-play operation is enabled by features like Auto-MDIX and auto-speed negotiation. HP has innovated and combined the latest advances in silicon technology to provide some of the most power-efficient switches: 16- and 24-port Fast Ethernet models are the industry's first IEEE 802.3az compliant unmanaged Fast Ethernet switches. The available green features, along with the lifetime warranty, make the HP 1410 switch series ideal for customers seeking low-cost and reliable networking solutions.

Quality of Service (QoS)

• IEEE 802.1p prioritization: delivers data to devices based on the priority and type of traffic


Connectivity

• Auto-MDIX: automatically adjusts for straight-through or crossover cables on all 10/100 and 10/100/1000 ports


Performance

• Energy-efficient Ethernet support (J9662A and J9663A only): supports new IEEE 802.3az standard; allows lower power consumption when operated with IEEE-compliant client devices in 100 Mb/s mode only


Ease of use

• Unmanaged: provides plug-and-play simplicity


Flexibility

• Fanless design: enables quiet operation for deployment in open spaces (selected models)


Warranty and support

• Lifetime warranty: for as long as you own the product with advance replacement and next-business-day delivery (available in most countries)†

Specifications

Management features
Switch typeUnmanaged
Quality of Service (QoS) supportYes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity8
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Network
Auto-sensingYes
Networking standardsIEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Full duplexYes
Flow control supportYes
Auto MDI/MDI-XYes
10G supportNo
Data transmission
Throughput11.9 Mpps
Latency (10-100 Mbps)3.6 µs
Latency (1 Gbps)1.2 µs
Packet buffer memory0.192 MB
MAC address table4096 entries
Switching capacity16 Gbit/s
Design
Product colourGray
Power
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (typical)12 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)No
Operational conditions
Operating temperature (T-T)0 - 40 °C
Heat dissipation41 BTU/h
Weight & dimensions
Width6.14" (156 mm)
Depth3.8" (96.5 mm)
Height0.965" (24.5 mm)
Weight12 oz (340 g)
Performance
Packet buffer memory0.192 MB
Technical details
Product colourGray
Memory
Packet buffer memory0.192 MB
