ServeRAID MR10M SAS/SATA Controller Low Profile with Battery (FRU: 43W4341) - Refurbished |
44E8825-LP-06 |
Description
ServeRAID-MR10M SAS/SATA Controller is a high-performance PCIe RAID Controller for
External Direct Attached Storage RAID 0, 1, 10, 5, 50, 6, and 60. This small form factor
(MD2) adapter with battery-backed DDR2 cache (BBU) utilizes an LSI 1078 controller with
an x8 PCI Express host interface and eight external SAS/SATA II 3 Gb/s ports. MegaRAID
Storage Manager (MSM), included with ServeRAID-MR10M, is a robust RAID management,
configuration, and reporting application.
While the adapter is identical to ServeRAID-MR10M SAS/SATA Controller (43W4339), this new
option includes a battery cable which enables the remote mounting of the battery within the system chassis, thus expanding the usage of ServeRAID-MR10M across additional System x
servers.
ServeRAID-MR10M SAS/SATA Controller with Remote Battery Kit is supported on x3350,
x3550, x3650, and x3655 systems.
External Direct Attached Storage RAID 0, 1, 10, 5, 50, 6, and 60. This small form factor
(MD2) adapter with battery-backed DDR2 cache (BBU) utilizes an LSI 1078 controller with
an x8 PCI Express host interface and eight external SAS/SATA II 3 Gb/s ports. MegaRAID
Storage Manager (MSM), included with ServeRAID-MR10M, is a robust RAID management,
configuration, and reporting application.
While the adapter is identical to ServeRAID-MR10M SAS/SATA Controller (43W4339), this new
option includes a battery cable which enables the remote mounting of the battery within the system chassis, thus expanding the usage of ServeRAID-MR10M across additional System x
servers.
ServeRAID-MR10M SAS/SATA Controller with Remote Battery Kit is supported on x3350,
x3550, x3650, and x3655 systems.
Specifications
| Technical details | |
|---|---|
| Weight | 21.8 oz (619 g) |
| Ports quantity | 8 |
| Operating temperature (T-T) | 10 - 35 °C |
| Operating relative humidity (H-H) | 8 - 80% |
| Mac compatibility | No |
| Dimensions (WxDxH) | 6.67 x 0.654 x 2.71" (169.5 x 16.6 x 68.8 mm) |
| Data transfer rate | 2.5 Gbit/s |
| Compatible operating systems | Microsoft Windows 2000 Server, 2003 Server, 2003 R2 Server, Server 2008, Server 2008 R2 x64/x86 NetWare 6.5 Red Hat Enterprise Linux 3/4 AS/ES/WS/HPC for AMD64/EM64T/x86, 5 Server Edition/with Xen & x64 SUSE LINUX Enterprise Server 9/10/11 (with Xen) for AMD64/EM64T/x86 VMware ESX 3.5/4.0/Server 2.5/Server 3.0, ESXi 3.5/4.0 |
| Compatibility | ServeRAID-MR10M |
| RAID controller type | HDD |
| Cache internal | 256 MB |
| Ports & interfaces | |
| Controller interface type | HDD RAID |
