Panorama Antennas WMM4G-6-60-5SP network antenna MIMO directional antenna SMA 9 dBi
- Brand: PANORAMA ANTENNAS
- Category:
- SKU: WMM4G-6-60-5SP
- EAN: 5055416036612
4x4 4G/5G LTE (617-960/1710-6000MHz)
Offer details
Trade Prices
| Distributor | Product | SKU | Stock | Updated | Price |
|---|---|---|---|---|---|
|
PANORAMA ANTENNAS, WALL MNT 4X4 MIMO GAIN ANT 4G/5G 5M SMA(M) |
WMM4G-6-60-5SP | |||
|
WALL MNT 4X4 MIMO GAIN ANT |
8FD492 | |||
|
Wall MNT 4x4 MiMo GAIN ANT 4G/5G 5m |
5935912 |
Description
The WMM4G-6-60 is a high directional gain 4x4 MiMo signal boosting antenna for 4G and 5G networks. Incorporating four separately fed wideband element assemblies in a single housing the WMM4G-6-60 is equipped to provide client side MiMo support for 4G and 5G networks offering 6dBi of peak gain at 617- 960MHz and 9dBi peak gain at 1710-6000MHz.
The weather resistant housing is designed for wall mounting and wall and mast mount brackets are provided. Supplied with fitted low loss double shielded cable for cellular/LTE the WMM4G-6-60 minimises exposed connector joints and simplifies cable management for easy installation.
The weather resistant housing is designed for wall mounting and wall and mast mount brackets are provided. Supplied with fitted low loss double shielded cable for cellular/LTE the WMM4G-6-60 minimises exposed connector joints and simplifies cable management for easy installation.
Specifications
| Performance | |
|---|---|
| Antenna gain level (max) | 9 dBi |
| Frequency band | 0.617-0.960/1.710-6 GHz |
| Gain | 9 dBi |
| Features | |
| International Protection (IP) code | IP66 |
| Antenna gain level (max) | 9 dBi |
| Frequency band | 0.617-0.960/1.710-6 GHz |
| Antenna type | MIMO directional antenna |
| Power handling | 50 W |
| Mounting | Wall |
| Gain | 9 dBi |
| Product colour | White |
| Cable type | 4x 5m (16') CS32 |
| Antenna connector type | SMA |
| Power | |
| Power consumption (max) | 50 W |
| Technical details | |
| Antenna gain level (max) | 9 dBi |
| Frequency band | 0.617-0.960/1.710-6 GHz |
| Antenna type | MIMO directional antenna |
| Power handling | 50 W |
| Mounting | Wall |
| Gain | 9 dBi |
| Cable type | 4x 5m (16') CS32 |
| Antenna connector type | SMA |
| Colour | |
| Product colour | White |
| Operational conditions | |
| Operating temperature (T-T) | -40 - 80 °C |
| Weight & dimensions | |
| Width | 12.1" (307 mm) |
| Depth | 20" (507 mm) |
| Height | 3.43" (87 mm) |
| Packaging content | |
| Quantity per pack | 1 pc(s) |
| Logistics data | |
| Quantity per pack | 1 pc(s) |
