StarTech.com SV431DVIUAHR KVM switch Black
- Brand: StarTech.com
- Category:
- SKU: SV431DVIUAHR
- EAN: 0065030831369 0778889465837 50 ...9465837 5054629202715 5052584552821 0132017927794 5054484276050 5054533276055 0163121153021 0617407485479 0960613373185 0132017909479 0898029631844 0168141487163more
StarTech.com 4 Port High Resolution USB DVI Dual Link KVM Switch with Audio and USB 2.0 Hub
Offer details
Trade Prices
| Distributor | Product | SKU | Stock | Updated | Price |
|---|---|---|---|---|---|
|
4 Port USB DVI KVM Switch | SV431DVIUAHR | |||
|
4 Port High Res USB DVI Audio KVM Switch | 2296968 |
Related Products
Description
Control up to 4 high resolution multimedia computers from a single console
The SV431DVIUAHR 4 Port High Resolution USB DVI Dual Link KVM Switch with Audio provides simple, yet comprehensive KVM control of up to 4 directly connected computers with dual link DVI output and USB keyboard and mouse connections.
Audio switching capability and support for high resolution dual link DVI applications up to 2560x1600 @ 60Hz (up to 3840x2400 at lower refresh rates), make this KVM a superior switching solution that integrates perfectly into multimedia environments.
The DVI USB KVM Switch is compatible with all USB supported operating systems with no software or drivers to install, and features a built-in USB 2.0 hub that allows you to share up to 3 high speed USB devices between computers.
Backed by a StarTech.com 3-year warranty and free lifetime technical support.
The StarTech.com Advantage
- Dual Link DVI interface supports higher resolution applications, allowing you to take full advantage of your larger high resolution monitor’s workspace
- Integrated USB 2.0 hub allows the user to have full multimedia control and share USB peripherals eliminating the expense of duplicate devices
- Supports even higher resolutions (exceeding 2560x1600) by using a lower refresh rate. Example 3840x2400 @30Hz
The SV431DVIUAHR 4 Port High Resolution USB DVI Dual Link KVM Switch with Audio provides simple, yet comprehensive KVM control of up to 4 directly connected computers with dual link DVI output and USB keyboard and mouse connections.
Audio switching capability and support for high resolution dual link DVI applications up to 2560x1600 @ 60Hz (up to 3840x2400 at lower refresh rates), make this KVM a superior switching solution that integrates perfectly into multimedia environments.
The DVI USB KVM Switch is compatible with all USB supported operating systems with no software or drivers to install, and features a built-in USB 2.0 hub that allows you to share up to 3 high speed USB devices between computers.
Backed by a StarTech.com 3-year warranty and free lifetime technical support.
The StarTech.com Advantage
- Dual Link DVI interface supports higher resolution applications, allowing you to take full advantage of your larger high resolution monitor’s workspace
- Integrated USB 2.0 hub allows the user to have full multimedia control and share USB peripherals eliminating the expense of duplicate devices
- Supports even higher resolutions (exceeding 2560x1600) by using a lower refresh rate. Example 3840x2400 @30Hz
Specifications
| Ports & interfaces | |
|---|---|
| Console ports | 3.5mm headphone, 3.5mm mic, DVI-I, USB A |
| Number of computers controlled | 4 |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | DVI-I |
| Audio connections | Yes |
| USB 2.0 ports quantity | 4 |
| DVI-I ports quantity | 5 |
| DC-in jack | Yes |
| HDCP | Yes |
| Performance | |
| Daisy chain | No |
| HDCP | Yes |
| Maximum resolution | 3840 x 2400 pixels |
| Number of users | 1 user(s) |
| Maximum digital resolution | 2560 x 1600 pixels |
| Technical details | |
| Product colour | Black |
| Number of users | 1 user(s) |
| IP control | No |
| Audio support | Yes |
| Compliance certificates | RoHS |
| Design | |
| Mean time between failures (MTBF) | 64000 h |
| Product colour | Black |
| Certification | CE, FCC |
| Display | |
| Built-in display | No |
| Power | |
| Input current | 0.4 A |
| Output current | 2 A |
| Power plug type | Type M |
| Output voltage | 5 V |
| Input voltage | 110-240 V |
| Video | |
| Maximum resolution | 3840 x 2400 pixels |
| Maximum digital resolution | 2560 x 1600 pixels |
| Sustainability | |
| Compliance certificates | RoHS |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Weight & dimensions | |
| Width | 8.66" (220 mm) |
| Depth | 5.12" (130 mm) |
| Height | 1.73" (44 mm) |
| Weight | 3.86 lbs (1.75 kg) |
| Package width | 3.74" (95 mm) |
| Package depth | 16.2" (411 mm) |
| Package height | 8.43" (214 mm) |
| Package weight | 2.73 lbs (1.24 kg) |
| Packaging data | |
| Package width | 3.74" (95 mm) |
| Package depth | 16.2" (411 mm) |
| Package height | 8.43" (214 mm) |
| Package weight | 2.73 lbs (1.24 kg) |
| Packaging content | |
| Rubber feet | Yes |
| Manual | Yes |
| AC adapter included | Yes |
| Certificates | |
| Certification | CE, FCC |
| Other features | |
| IP control | No |
| Audio support | Yes |
| Logistics data | |
| Harmonized System (HS) code | 85176200 |
