TP-Link EAP215-Bridge KIT 867 Mbit/s White Power over Ethernet (PoE)
- Brand: TP-Link
- Category:
- SKU: EAP215-BRIDGE KIT
- EAN: 0840460601542 0810142823388 08 ...2823388 0840030709159 4895252502572 1210002603744 4895252502565 1210002603751 8885020627084 8885020627077more
5 GHz / 867 Mbps, 3x Gigabit LAN, 12V DC / 24V Passive PoE, 224 x 79 x 60 mm
Offer details
Trade Prices
| Distributor | Product | SKU | Stock | Updated | Price |
|---|---|---|---|---|---|
|
AC867 5GHz LR Access Point |
EAP215BRIDGEKIT | |||
|
5GHZ 867MBPS LR I/O WLESS BRDGE |
JR8654 | |||
|
Wireless Bridge 5 GHz 867 Mbps Long-Range Indoor/Outdoor Access Point |
EAP215BRIDGEKIT | |||
|
5GHz AC867 Long-range Indoor/Outdoor Ac |
TPL-EAP215BRIDGEKIT | |||
|
5GHZ AC867 LONG-RANGE IN/OUTDOOR AP |
9353615 | |||
|
|
Omada 5 GHz 867 Mbps Long-Range Indoor/Outdoor Access Point |
14305770 |
Description
Wireless Bridge 5 GH 867 Mbps Long-Range Indoor/Outdoor Access Point
- Long-Distance Transmission
- Auto-Pairing
- Agile LEDs for Easy Deployment
- 3× Fast Ethernet Ports
- 12V DC/Passive PoE
- IP65 Weatherproof & 6 KV Lightning Protection
- Omada Centralized Cloud Management
- Passive PoE Adapter Included
5-km Long-Distance Wi-Fi Transmission
Easy and Simple Deployment
Point-to-Point Connection, Perfect for Surveillance
Seamless Integration into Omada SDN
- Long-Distance Transmission
- Auto-Pairing
- Agile LEDs for Easy Deployment
- 3× Fast Ethernet Ports
- 12V DC/Passive PoE
- IP65 Weatherproof & 6 KV Lightning Protection
- Omada Centralized Cloud Management
- Passive PoE Adapter Included
5-km Long-Distance Wi-Fi Transmission
Easy and Simple Deployment
Point-to-Point Connection, Perfect for Surveillance
Seamless Integration into Omada SDN
Specifications
| Data transmission | |
|---|---|
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Maximum data transfer rate | 867 Mbit/s |
| Performance | |
| 2.4 GHz | No |
| 5 GHz | Yes |
| Syslog | Yes |
| Reset button | Yes |
| Web-based management | Yes |
| VLAN support | Yes |
| Rate limiting | Yes |
| Quality of Service (QoS) support | Yes |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11be, IEEE 802.11g, IEEE 802.11n |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Certification | CE, FCC, RoHS |
| Maximum data transfer rate | 867 Mbit/s |
| MIMO type | Multi User MIMO |
| MIMO | Yes |
| Remote Authentication Dial-In User Service (RADIUS) | Yes |
| Network | |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11be, IEEE 802.11g, IEEE 802.11n |
| Management features | |
| VLAN support | Yes |
| Rate limiting | Yes |
| Quality of Service (QoS) support | Yes |
| Syslog | Yes |
| Web-based management | Yes |
| Features | |
| 6 GHz | No |
| 2.4 GHz | No |
| 5 GHz | Yes |
| VLAN support | Yes |
| Rate limiting | Yes |
| Quality of Service (QoS) support | Yes |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11be, IEEE 802.11g, IEEE 802.11n |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
| Maximum data transfer rate | 867 Mbit/s |
| Transmitting power (FCC) | <22dBm (5 GHz band1/4) |
| Transmitting power (CE) | <23dBm (5 GHz, band 1/2, EIRP); <30dBm (5 GHz band3, EIRP) |
| MIMO type | Multi User MIMO |
| MIMO | Yes |
| Maximum data transfer rate (5 GHz) | 867 Mbit/s |
| BeamForming | Yes |
| Security | |
| Security algorithms | SNMP, SNMPv2, SNMPv3, SSH |
| MAC address filtering | Yes |
| Access Control List (ACL) | Yes |
| Remote Authentication Dial-In User Service (RADIUS) | Yes |
| Ports & interfaces | |
| USB 2.0 ports quantity | 0 |
| Ethernet LAN (RJ-45) ports | 3 |
| Cabling technology | 10/100/1000Base-T(X) |
| Power | |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) type supported | Passive PoE |
| DC voltage range | 12 V |
| Design | |
| Placement | Pole |
| Product colour | White |
| Reset button | Yes |
| LED indicators | Yes |
| Certification | CE, FCC, RoHS |
| Antenna | |
| Antenna type | Internal |
| Polarization | Dual polarization |
| Antenna gain level (max) | 11 dBi |
| Antenna direction type | Directional |
| Antenna features | Integrated antenna |
| Technical details | |
| Reset button | Yes |
| Polarization | Dual polarization |
| Certificates | |
| Certification | CE, FCC, RoHS |
| Indication | |
| LED indicators | Yes |
| Software | |
| Access Control List (ACL) | Yes |
| Weight & dimensions | |
| Width | 8.82" (224 mm) |
| Depth | 3.11" (79 mm) |
| Weight | 11.7 oz (330.9 g) |
| Height | 2.36" (60 mm) |
| Packaging data | |
| Quick start guide | Yes |
| Packaging content | |
| Quick start guide | Yes |
| Operational conditions | |
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | -40 - 70 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 5 - 90% |
| Other features | |
| Polarization | Dual polarization |
