Tripp Lite AVR550U uninterruptible power supply (UPS) Line-Interactive 0.55 kVA 300 W 8 AC outlet(s)

Tripp Lite AVR550U uninterruptible power supply (UPS) Line-Interactive 0.55 kVA 300 W 8 AC outlet(s)

Tripp Lite AVR550U, Line-Interactive, 0.55 kVA, 300 W, Pure sine, 110 V, 120 V

Trade Prices

Distributor Product SKU Stock Updated Price
Accutech Data Supplies

UPS

 TRPAVR550U Register free see stock
Anixter

550VA UPS SYSTEMLOW PROFILE, LINE INTERACTIVEMODEM/FAX PROTECTION

 381540
Arlington Industries

8-OUTLET LINE INTERACTIVE UPS SYSTEM

 TRPAVR550U
ASI Corp

TRIPPLITE 550VA UPS ultra-compact line-interactive UPS single-line TEL DSL surge

 45877
BlueStar

EATON, 550VA UPS LOW PROFILE AVR LINE-INTERACTIVE 8 OUTLETS

 AVR550U

Description

Tripp Lite AVR550U. UPS topology: Line-Interactive, Output power capacity: 0.55 kVA, Output power: 300 W. AC outlet types: NEMA 5–15R, Power plug: NEMA 5-15P, AC outlets quantity: 8 AC outlet(s). Battery voltage: 12 V, Typical backup time at half load: 9 min, Battery recharge time: 9 h. Form factor: Tower, Product color: Black, Housing material: Acrylonitrile butadiene styrene (ABS). Compliance certificates: RoHS, Certification: UL1778, CSA, NOM, FCC

Specifications

Power
Output frequency50/60 Hz
Output power300 W
Input operation voltage (min)110 V
Input operation voltage (max)120 V
Output operation voltage (min)110 V
Output operation voltage (max)120 V
Surge energy rating316 J
Maximum current15 A
Output power capacity0.55 kVA
Ports & interfaces
Cable length59.1" (1.5 m)
USB portYes
AC outlets quantity8 AC outlet(s)
AC outlet typesNEMA 5–15R
Power plugNEMA 5-15P
USB 2.0 ports quantity1
Performance
UPS topologyLine-Interactive
WaveformPure sine
LED indicatorsYes
EMI/RFI noise filteringYes
Surge protectionYes
Audible alarm(s)Yes
Features
Output frequency50/60 Hz
Country of originChina
UPS topologyLine-Interactive
WaveformPure sine
Output power300 W
Input operation voltage (min)110 V
Input operation voltage (max)120 V
Output operation voltage (min)110 V
Output operation voltage (max)120 V
Surge energy rating316 J
Maximum current15 A
EMI/RFI noise filteringYes
Surge protectionYes
Audible alarm(s)Yes
Output power capacity0.55 kVA
Battery
Battery voltage12 V
Battery recharge time9 h
Typical backup time at half load9 min
Cold startYes
Design
Country of originChina
Form factorTower
LED indicatorsYes
Product colourBlack
CertificationUL1778, CSA, NOM, FCC
Cable length59.1" (1.5 m)
Housing materialAcrylonitrile butadiene styrene (ABS)
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 45 °C
Operating relative humidity (H-H)0 - 90%
Operating altitude0 - 120000" (0 - 3048 m)
Technical details
Output frequency50/60 Hz
Compliance certificatesRoHS
Certificates
CertificationUL1778, CSA, NOM, FCC
Compliance certificatesRoHS
Packaging content
ManualYes
Cables includedUSB cable
Weight & dimensions
Package width9.3" (236.2 mm)
Package depth14.7" (373.4 mm)
Package height6" (152.4 mm)
Weight13.7 lbs (6.21 kg)
Width6.4" (162.6 mm)
Package weight14 lbs (6.35 kg)
Height4.33" (110 mm)
Depth12" (304.8 mm)
Packaging data
ManualYes
Cables includedUSB cable
Package width9.3" (236.2 mm)
Package depth14.7" (373.4 mm)
Package height6" (152.4 mm)
Package weight14 lbs (6.35 kg)
Logistics data
Country of originChina
Products per master (outer) case3 pc(s)
Master (outer) case width15.3" (388.6 mm)
Master (outer) case length19.1" (485.1 mm)
Master (outer) case height10.2" (259.1 mm)
Master (outer) case gross weight39 lbs (17.7 kg)
Master (outer) case GTIN (EAN/UPC)10037332211450
