Tripp Lite B002-DUA4 KVM switch Black

Tripp Lite B002-DUA4 KVM switch Black

  • Brand: Tripp Lite
  • Category:
  • SKU: B002-DUA4
  • EAN: 0132017816739 0037332167682 03 ...2167682 0373321676828 0757807394671more
4-Port Secure KVM Switch DVI / USB with Audio NIAP-Certified (EAL 2+)

Trade Prices

Distributor Product SKU Stock Updated Price
Anixter 4-PORT NIAP-CERTIFIED (EAL 2+)SECURE DVI / USB KVM SWITCHWITH AUDIO 506935 Register free see stock

Related Products

Description

The Tripp Lite B002-DUA4 4 Port DVI / USB Secure KVM Switch with Audio offers secure and reliable access for any government/military desktop environment where security is required, by providing safe switching between computers operating on different networks. NIAP-certified to comply with Common Criteria EAL2+ security requirements. Hardware security includes: tamper-evident tape, chassis intrusion detection, and tamper-proof hardware, while software security includes restricted USB connectivity — non HIDs (Human Interface Devices) are ignored when switching — an isolated channel per port that makes it impossible for data to be transferred between secure and unsecured computers, and automatic clearing of the keyboard buffer. CAC ( Common Access Card ) support*By combining physical security with controlled USB connectivity, the B002-DUA4 gives you the means to consolidate multiple workstations of various security classification levels with one keyboard, monitor and mouse (KVM) console.* CAC support not validated by NIAP

- 4-Port NIAP-Certified Secure DVI / USB KVM Switch with Audio
- Tested to comply with Common Criteria EAL2+ security requirements
- Multi-platform support: Windows, Linux, MAC, and SUN
- CAC Support*"
- National Information Assurance Partnership (NIAP) certified to comply with Common Criteria EAL2+ security requirements.
- Safely switch between computers with varying security levels.
- Isolated Channels – Each port is its own channel, making it impossible for data to be transferred between connected computers.
- Tamper-Warning Labels – Tamper-Warning labels will be placed on each side of the KVM, providing visual evidence if the unit has been tampered with or compromised.
- Housing Intrusion Protection Technology – Housing Intrusion Protection technology disables the KVM if the housing is opened, causing it to become inoperable. When disabled, the front panel LEDs will flash repeatedly.
- Tamper-Proof Components – All internal circuitry is soldered directly to the board, preventing the components from being tampered with.
- Fixed Firmware – Firmware is non-reprogrammable, securing against attempts to alter the logic of the KVM.
- Automatic Keyboard Buffer Clearing – The keyboard buffer is automatically cleared after data transmission, leaving no information stored in the switch.
- No Memory Buffer – The only way to access connected computers is via push button. Port switching methods such as On-Screen Display (OSD) and Hot key Commands, which require memory, have been excluded to further ensure data integrity.
- Compatible with all major operating systems: Windows, Linux, MAC, and SUN
- DVI-I Dual-Link signal supports digital video resolutions up to 2560 x 1600, and analog video resolutions up to 2048 x 1536.
- Supports transfer of EDID information, allowing for optimal display performance.
- Audio support for both speaker and microphone
- CAC Support ( CAC support not validated by NIAP )

Specifications

Ports & interfaces
Number of microphone inputs5
Keyboard port typeUSB
Mouse port typeUSB
Video port typeDVI-I
Headphone outputs5
DC-in jackYes
Performance
Maximum resolution2560 x 1600 pixels
Technical details
Product colourBlack
Weight (imperial)3.70 lbs
Design
Product colourBlack
CertificationFCC, CE, RoHS, NIAP EAL2+, TAA
Power
Power consumption (typical)5.1 W
External power adapterYes
Video
Maximum resolution2560 x 1600 pixels
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 80%
Weight & dimensions
Width13.3" (336.6 mm)
Depth6" (152.4 mm)
Height1.75" (44.5 mm)
Weight3.7 lbs (1.68 kg)
Package width16.3" (414 mm)
Package depth8.5" (215.9 mm)
Package height4.6" (116.8 mm)
Package weight5.69 lbs (2.58 kg)
Packaging data
Package width16.3" (414 mm)
Package depth8.5" (215.9 mm)
Package height4.6" (116.8 mm)
Package weight5.69 lbs (2.58 kg)
Packaging content
Cables includedAC
ManualYes
Certificates
CertificationFCC, CE, RoHS, NIAP EAL2+, TAA
Other features
Connectivity technologyWired
Power requirements0.5A
Compatible operating systemsWindows, Linux, MAC, SUN
Weight (imperial)3.70 lbs
Logistics data
Master (outer) case width16.8" (426.7 mm)
Master (outer) case length14.6" (370.8 mm)
Master (outer) case height9.1" (231.1 mm)
Master (outer) case gross weight19.4 lbs (8.8 kg)
Products per master (outer) case3 pc(s)
Master (outer) case GTIN (EAN/UPC)10037332167689
