Tripp Lite IS300HGDV isolation transformer

Tripp Lite IS300HGDV isolation transformer

Isolator Series Dual-Voltage 115/230V 300W 60601-1 Medical-Grade Isolation Transformer, C14 Inlet, 4 C13 Outlets

Trade Prices

Distributor Product SKU Stock Updated Price
Anixter ISOLATOR SERIES DUAL-VOLTAGE115/230V 300W 60601-1MEDICAL-GRADE 9810326 Register free see stock
Ingram Micro ISOLATION TRANSFORMER HOSPITAL 3BU438
ScanSource Isolation Transformer Hospital POW-IS300HGDV
TD Synnex ISOLATION TRANSFORMER HOSPITAL 300W 8C13 5174760

Description





Specifications

Features
AC inlet typeC20 coupler
AC outlet typesC13
AC outlets quantity4 AC outlet(s)
AC input voltage115 - 230 V
AC input frequency50 - 60 Hz
Load capacity300 VA
Input current (max)3.15 A
Housing colourWhite
CertificationANSI/AAMI ES60601-1:2005+A2+A1, IEC60601-1 3RD EDITION +A1, cAN/CSA-C22.2 NO. 60601-1:14, CE, NOM
Short circuit protectionYes
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 50 °C
Operating relative humidity (H-H)5 - 95%
Operating altitude0 - 118110.2" (0 - 3000 m)
Weight & dimensions
Width5.91" (150.1 mm)
Depth7.87" (199.9 mm)
Height4.33" (110 mm)
Weight12.3 lbs (5.6 kg)
Package width9.84" (249.9 mm)
Package depth12.8" (325.1 mm)
Package height8.27" (210.1 mm)
Package weight13.6 lbs (6.18 kg)
Technical details
Products per master (outer) case1 pc(s)
Master (outer) case width9.84" (249.9 mm)
Master (outer) case gross weight13.6 lbs (6.18 kg)
Master (outer) case length12.8" (325.1 mm)
Master (outer) case height8.27" (210.1 mm)
Logistics data
Country of originChina
Products per master (outer) case1 pc(s)
Master (outer) case width9.84" (249.9 mm)
Master (outer) case gross weight13.6 lbs (6.18 kg)
Master (outer) case length12.8" (325.1 mm)
Master (outer) case height8.27" (210.1 mm)
