Tripp Lite OMNIVSINT1000 uninterruptible power supply (UPS) Line-Interactive 1 kVA 500 W 6 AC outlet(s)

Tripp Lite OMNIVSINT1000 uninterruptible power supply (UPS) Line-Interactive 1 kVA 500 W 6 AC outlet(s)

OmniVS 230V 1000VA 500W Line-Interactive UPS, Tower, USB port, C13 Outlets

Trade Prices

Distributor Product SKU Stock Updated Price
Anixter

1000VA INTERNATIONAL UPSSYSTEM OMNISMART TOWER VS

 565288 Register free see stock

Description

Tripp Lite's OMNIVSINT1000 line interactive UPS system offers voltage regulation, surge suppression and long lasting battery support for personal computers, internetworking equipment and other sensitive electronics. Internal UPS circuits support entry level PC systems for up to 60 minutes during power failures so that connected equipment can be shut down without data loss. Automatic Voltage Regulation (AVR) circuits regulate brownouts as low as 159 volts back to usable levels without using battery power. Offers complete desktop power protection in an attractive black tower configuration. Includes 6 outlets with battery support and AC surge suppression. USB port enables optional unattended system shutdown without data loss in the case of extended power failure, USB cable included. PowerAlert software available via free download. Built-in single line RJ phone surge suppression jacks protect modem, fax machine, cordless phone or other peripheral with a standard dialup/DSL phone connection. Built-in audible alarm and 4 front panel LEDs indicate line power status, battery power status, battery low/replace status and load status. 1000VA power handling ability supports entry-level PCs, network workstations, point-of-sale equipment, small business phone systems, audio/video equipment and home theater systems. Offers 5 minutes battery runtime with a full load of 1000VA and 12 minutes with a half load of 500VA. Supports battery replacement via built-in access panel.
● OMNIVSINT1000 Uninterruptible Power Supply offers voltage regulation, surge suppression and long lasting battery support
● Supports entry level PCs up to 60 minutes during blackouts to enable shutdown without data loss
● Regulates brownouts as low as 159 volts back to usable levels without using battery power
● 6 IEC320 C13 outlets with complete AC surge suppression
● C14 accepts user-supplied AC power cord with country-specific plug
● USB port enables data-saving unattended shutdown when used with Tripp Lite's PowerAlert software, available via FREE download from www.tripplite.com/poweralert
● Single line phone surge suppression protects standard dialup/DSL phone connection
● Audible alarm and 4 front panel LEDs offer complete UPS and line power status information
● 1000VA power handling ability supports a variety of sensitive electronic equipment
● 5 minutes full load runtime (1000VA), 12 minutes half load runtime (500VA)
● Supports battery replacement via built-in access panel
● Attractive full color retail packaging

● 1000VA / 1kVA tower 230V line interactive UPS
● Corrects brownouts as low as 159V without using battery power
● USB port, TEL/DSL/ethernet protection
● C14 input and 6 C13 outlets

Package Includes

● OMNIVSINT1000 line interactive UPS
● 2 C13 to C14 interconnection cables
● USB and phone line cables
● Owner's manual with warranty information

Specifications

Power
Output voltage regulation5%
Output power500 W
Input operation voltage (min)159 V
Input operation voltage (max)230 V
Output operation voltage (min)220 V
Output operation voltage (max)240 V
Surge energy rating508 J
Maximum current2.4 A
Efficiency92%
Output power capacity1 kVA
Input frequency50/60 Hz
Ports & interfaces
Cable length7.87" (0.2 m)
AC outlets quantity6 AC outlet(s)
AC outlet typesC13 coupler
Power plugC14 coupler
USB 2.0 ports quantity1
Battery
Battery typeRBC51
Battery recharge time9 h
Typical backup time at half load12 min
Typical backup time at full load5 min
Hot-swap batteryYes
Cold startYes
Performance
UPS topologyLine-Interactive
WaveformSine
Automatic Voltage Regulation (AVR)Yes
Number of input phases1
LED indicatorsYes
EMI/RFI noise filteringYes
Surge protectionYes
Surge protection featuresNetwork, Telephone
Power protection featuresUnder voltage
Audible alarm(s)Yes
Features
UPS topologyLine-Interactive
WaveformSine
Output voltage regulation5%
Automatic Voltage Regulation (AVR)Yes
Number of input phases1
Output power500 W
Input operation voltage (min)159 V
Input operation voltage (max)230 V
Output operation voltage (min)220 V
Output operation voltage (max)240 V
Surge energy rating508 J
Maximum current2.4 A
Efficiency92%
EMI/RFI noise filteringYes
Surge protectionYes
Surge protection featuresNetwork, Telephone
Power protection featuresUnder voltage
Audible alarm(s)Yes
Output power capacity1 kVA
Input frequency50/60 Hz
Design
Rack capacity2U
Form factorTower
LED indicatorsYes
Product colourBlack
CertificationGOST, SASO, IRAM, FCC, CE IEC62040
Cable length7.87" (0.2 m)
Housing materialPolyvinyl chloride (PVC)
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 50 °C
Operating relative humidity (H-H)0 - 95%
Technical details
Compliance certificatesRoHS
Certificates
CertificationGOST, SASO, IRAM, FCC, CE IEC62040
Compliance certificatesRoHS
Weight & dimensions
Package width13.8" (350.5 mm)
Package depth9.6" (243.8 mm)
Package height8.1" (205.7 mm)
Weight16.8 lbs (7.6 kg)
Width5.24" (133 mm)
Package weight21.5 lbs (9.75 kg)
Height10.7" (273 mm)
Depth7.48" (190 mm)
Packaging data
Package width13.8" (350.5 mm)
Package depth9.6" (243.8 mm)
Package height8.1" (205.7 mm)
Package weight21.5 lbs (9.75 kg)
Logistics data
Products per master (outer) case2 pc(s)
Master (outer) case width16.5" (419.1 mm)
Master (outer) case length11.1" (281.9 mm)
Master (outer) case height14.9" (378.5 mm)
Master (outer) case gross weight44.1 lbs (20 kg)
Other features
Battery typeRBC51
