Tripp Lite SU5000RT4UTF uninterruptible power supply (UPS) Double-conversion (Online) 5 kVA 4500 W 16 AC outlet(s)

Tripp Lite SU5000RT4UTF uninterruptible power supply (UPS) Double-conversion (Online) 5 kVA 4500 W 16 AC outlet(s)

SmartOnline 208/120V 5kVA 4.5kW On-Line Double-Conversion UPS, Extended Run, SNMP, Webcard, 6U Rack/Tower, USB, DB9 Serial

Trade Prices

Distributor Product SKU Stock Updated Price
Anixter 5000VA ONLINE UPS6U ALL-IN-ONE RACK/TOWER UPSDOUBLE-CONVERSION 423397 Register free see stock
BlueStar TRIPP LITE, UPS SMART ONLINE HIGH EFFICIENCY 6U RM 5KVA 208-240V, (NON RET/CANC) SU5000RT4UTF
Ingram Micro SMART ONLINE UPS 5KVA DA1045

Related Products

Description

Tripp Lite SU5000RT4UTF 5000VA / 5kVA / 4500 watt on-line, double-conversion UPS system offers complete power protection for critical server, network and telecommunications equipment in a 6U rack/tower configuration. Full-time active power conditioning provides clean, continuous dual-conversion AC output free of voltage fluctuations, power interruptions and line noise. Fault-tolerant auto-bypass prevents unexpected service interruptions during UPS overload or internal fault conditions. 4U UPS power module with internal batteries and 2U step-down transformer installs in a total of 6 rack spaces (6U) with a maximum installed depth of only 20.75 in. / 52.7 cm. Maintains full-time sine wave output within 2% of 208 and 120V nominal at 60Hz during brownouts as low 100V and overvoltages as high as 300V. Expandable runtime is supported with optional BP192V12-3U external battery packs. Battery independent restart ensures automatic UPS power-up without user interaction after lengthy power outages, even when batteries are expired and require replacement. Double-conversion operation converts raw input from AC to DC, then resynthesizes output power back to perfect sine wave AC with enhanced protection from harmonic distortion, fast electrical impulses and other hard-to-solve power problems not addressed by other UPS types. Highly efficient operation in optional economy mode significantly reduces BTU heat output and operating energy costs. Network-grade AC surge and noise suppression. Supports detailed monitoring of equipment load levels, self-test data and utility power conditions via built-in RS-232 and USB interfaces. Optional SNMP/Web and contact-closure communications card accessories available. HID-compliant USB interface enables integration with built-in power management and auto shutdown features of Windows and Mac OS X. Included PowerAlert monitoring software offers detailed site power and UPS updates with support for safe auto-shutdown of connected systems as UPS batteries become depleted. Included software packages include PowerAlert Local, PowerAlert Network Shutdown Agent and PowerAlert Network Management System for complete support for a wide variety of application types. Supports Emergency Power Off (EPO) via built-in interface. Front panel LEDs and LCD readout with scroll controls support front-panel visual monitoring of all major UPS functions with support for a variety of control options to support advanced UPS settings and configurations. LED / LCD display panel rotates for viewing in rackmount or tower configurations. L6-30P input, plus 2 L6-30R, 2 L6-20R and 12 5-15/20R outlets. External battery packs are field replaceable and hot swappable. $250,000 connected equipment insurance;
- Tripp Lite SU5000RT4UTF 5000VA / 5kVA / 4500 watt on-line, double-conversion UPS system in a 6U rack/tower configuration (4U UPS power module with internal batteries + 2U step-down transformer)
- Full-time active power conditioning maintains clean, continuous dual-conversion AC output free of voltage fluctuations, power interruptions and line noise
- Fault tolerant electronic bypass maintains utility output during a variety of UPS fault conditions
- L6-30P input plug, plus 2 L6-30R, 2 L6-20R and 12 5-15/20R outlets
- Included rail kits support rackmount installation of both included modules in 4 post racks
- Optional 2POSTRMKITHD supports installation in 2 post 19 inch racks (2 required for SU5000RT4UTF)
- Optional 2-9USTAND supports upright tower placement (1 required for SU5000RT4UTF)
- Maximum installed rack depth of only 20.75 in. / 52.7 cm
- Maintains full-time sine wave output within 2% of 208V & 120V at 60Hz nominal in double conversion mode
- Corrects brownouts to 156V at full load (100V at 50% load or less)
- Corrects overvoltages to 290V at full load (300V at 90% load or less)
- Double-conversion operation offers full-time AC to DC, then DC to AC conversion to maintain perfectly regulated sine wave AC output with enhanced protection from harmonic distortion, fast electrical impulses and other hard-to-solve power problems not addressed by other UPS types
- High efficiency ECONOMY MODE operation significantly reduces BTU heat output and operating energy costs
- Network-grade AC surge and noise suppression
- Supports detailed monitoring of equipment load levels, self-test data and utility power conditions via built-in RS-232, USB and optional SNMP card slot interfaces
- UPS card slot supports one card-based network interface option (part # SNMPWEBCARD) or dry-contact monitoring accessory (part # RELAYIOCARD)
- Optional SNMPWEBCARD offers communications and control via secure remote web and network interfaces
- Optional RELAYIOCARD supports six configurable hard contact closure outputs for custom event notification
- Optional RELAYIOMINI interface module offers three configurable hard contact closure outputs for custom event notification (requires removal of USB interface module)
- HID-compliant USB interface enables integration with built-in power management and auto shutdown features of Windows and Mac OS X
- Includes Free PowerAlert monitoring software packages; PowerAlert LOCAL for desktops and small business networks, PowerAlert NSA (Network Shutdown Agent) for larger networks and PowerAlert NMS (Network Management System) for monitoring up to 250 SNMP-enabled UPS, PDU and other networking devices
- Front panel LEDs and LCD readout with scroll controls support front-panel visual monitoring of all major UPS functions with support for a variety of control options to support advanced UPS settings and configurations
- LED/LCD display panel rotates for viewing in rackmount or tower configurations
- Supports Emergency Power Off (EPO) via built-in interface
- Battery independent restart ensures automatic UPS power-up without user interaction after lengthy power outages, even when batteries are expired and require replacement
- External battery packs are field replaceable and hot swappable
- Some external battery configurations require the use of Tripp Lite's External Battery Configuration Software (see manual)
- $250,000 connected equipment insurance

Specifications

Power
Output power4500 W
Output operation voltage (min)120 V
Output operation voltage (max)208 V
Maximum current30 A
Emergency Power Off (EPO)Yes
Power factor0.9
Crest factor3:1
Output power capacity5 kVA
Input frequency60 Hz
Ports & interfaces
Cable length118.1" (3 m)
AC outlets quantity16 AC outlet(s)
AC outlet typesNEMA 5–15R, NEMA 5–20R, NEMA L6-20R, NEMA L6-30R
Power plugNEMA L6-30P
Performance
UPS topologyDouble-conversion (Online)
LED indicatorsYes
EMI/RFI noise filteringYes
Power protection featuresOver voltage, Under voltage
Noise level65 dB
Audible alarm(s)Yes
Features
Country of originChina
UPS topologyDouble-conversion (Online)
Output power4500 W
Output operation voltage (min)120 V
Output operation voltage (max)208 V
Maximum current30 A
EMI/RFI noise filteringYes
Emergency Power Off (EPO)Yes
Power protection featuresOver voltage, Under voltage
Power factor0.9
Noise level65 dB
Crest factor3:1
Audible alarm(s)Yes
Output power capacity5 kVA
Input frequency60 Hz
Battery
Typical backup time at half load11 min
Typical backup time at full load3.5 min
Hot-swap batteryYes
Cold startYes
Design
Country of originChina
Rack capacity6U
Form factorRackmount/Tower
LED indicatorsYes
Product colourBlack
CertificationUL1778 IEC 61000-4-5 1995 B
Cable length118.1" (3 m)
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 50 °C
Operating relative humidity (H-H)5 - 90%
Storage relative humidity (H-H)0 - 95%
Operating altitude0 - 78740.2" (0 - 2000 m)
Technical details
Compliance certificatesRoHS
Weight & dimensions
Package width23.6" (599.4 mm)
Package depth29.1" (739.1 mm)
Package height22.2" (563.9 mm)
Package weight227.7 lbs (103.3 kg)
Packaging data
Package width23.6" (599.4 mm)
Package depth29.1" (739.1 mm)
Package height22.2" (563.9 mm)
Package weight227.7 lbs (103.3 kg)
Logistics data
Products per master (outer) case1 pc(s)
Master (outer) case width23.6" (599.4 mm)
Master (outer) case length29.1" (739.1 mm)
Master (outer) case height22.2" (563.9 mm)
Master (outer) case gross weight227.7 lbs (103.3 kg)
Certificates
CertificationUL1778 IEC 61000-4-5 1995 B
Other features
InterfaceUSB; DB9
