Offer details
Trade Prices
| Distributor | Product | SKU | Stock | Updated | Price |
|---|---|---|---|---|---|
|
UISP-CONSOLE designed small to moderate UISP deployments 8Gb Ports |
UISP-CONSOLE | |||
|
UISP HOST CONSOLE W/ AN INT |
JN0348 | |||
|
UISPCONSOLE | ||||
|
UISP host console with an integrated |
UBI-UISPCONSOLE |
Description
The UISP® Console is designed to support small to moderate UISP deployments with its built-in switch equipped with (8) GbE RJ45 LAN ports. The UISP Console also serves as a high-performance gateway with (1) 10G SFP+ LAN port and (2) WAN ports (10G SFP+ and GbE RJ45) that provide an ample connectivity range capable of supporting the most data-intensive deployments.
Specifications
| Design | |
|---|---|
| LED indicators | Yes |
| Certification | CE, FCC, IC |
| Rack capacity | 1U |
| Product colour | White |
| Enclosure material | Metal |
| Performance | |
| Built-in processor | Yes |
| Processor frequency | 1700 MHz |
| Number of processors installed | 1 |
| Internal memory type | DDR4 |
| Internal memory | 4 MB |
| Flash memory | 16000 MB |
| Control display unit | No |
| Processor model | Cortex-A57 |
| Processor family | ARM Cortex |
| SSD capacity | 128 GB |
| Certification | CE, FCC, IC |
| Rack capacity | 1U |
| Product colour | White |
| Enclosure material | Metal |
| Network | |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ports & interfaces | |
| WAN connection | Ethernet (RJ-45) |
| Ethernet LAN (RJ-45) ports | 8 |
| Power | |
| Input voltage | 24 - 28 V |
| Power consumption (max) | 30 W |
| Weight & dimensions | |
| Weight | 3.2 lbs (1.45 kg) |
| Width | 8.28" (210.4 mm) |
| Height | 1.72" (43.7 mm) |
| Depth | 5.52" (140.2 mm) |
| Operational conditions | |
| Operating temperature (T-T) | -10 - 50 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Technical details | |
| Built-in processor | Yes |
| Processor frequency | 1700 MHz |
| Number of processors installed | 1 |
| Indication | |
| LED indicators | Yes |
| Memory | |
| Internal memory type | DDR4 |
| Internal memory | 4 MB |
| Flash memory | 16000 MB |
| Display | |
| Control display unit | No |
| Certificates | |
| Certification | CE, FCC, IC |
| Features | |
| Built-in processor | Yes |
| Processor frequency | 1700 MHz |
| Number of processors installed | 1 |
