Ubiquiti UAP-NANOHD-US wireless access point 1733 Mbit/s White Power over Ethernet (PoE)

Ubiquiti UAP-NANOHD-US wireless access point 1733 Mbit/s White Power over Ethernet (PoE)

2x2 MIMO on 2.4GHz (300Mbps max PHY rate), 4x4 MU-MIMO on 5GHz (1733Mbps max PHY rate), 802.3af

Trade Prices

Distributor Product SKU Stock Updated Price
Flytec Computers

US VERSION UniFi UAP-NanoHD Wave2 11ac Dual Band PoE gigabit 200+ Users

UAP-NanoHD-US Register free see stock
Ingram Micro

UNIFI AC AP COMPACT WAVE2

3FP130
Microcom Technologies

UniFi nanoHD Access Point

UAPNANOHD
ScanSource

Compact UniFi Wave2 AC AP, PoE Inclu

UBI-UAPNANOHDUS

Description

Scalable Enterprise Wi-Fi Management
UniFi® is the revolutionary Wi-Fi system that combines enterprise performance, unlimited scalability, and a central management controller. The UniFi nanoHD AP has a refined industrial design and can be easily installed using the included mounting hardware. Easily accessible through any standard web browser and the UniFi mobile app (iOS or Android), the UniFi Controller software is a powerful software engine ideal for high-density client deployments requiring low latency and high uptime performance. Use the UniFi Controller software to quickly configure and administer an enterprise Wi-Fi network – no special training required. RF map and performance features, real-time status, automatic UAP device detection, and advanced security options are all seamlessly integrated.

Save Money and Save Time
UniFi comes bundled with a non-dedicated software controller that can be deployed
on an on-site PC, Mac, or Linux machine; in a private cloud; or using a public cloud service. You also have the
option of deploying the compact UniFi Cloud Key with built-in software.

Powerful Hardware
The UniFi nanoHD AP features the latest in Wi-Fi 802.11ac Wave 2 MU-MIMO technology.

Intuitive UniFi Controller Software
Configure and manage your APs with the easy-to-learn user interface.

Expandable
Unlimited scalability: build wireless networks as big or small as needed. Start with one (or
upgrade to a five‑pack) and expand to thousands while maintaining a single unified management system.

Specifications

Data transmission
Ethernet LAN data rates10,100,1000 Mbit/s
Maximum data transfer rate1733 Mbit/s
Performance
2.4 GHzYes
5 GHzYes
Wireless isolationYes
Wi-Fi Multimedia (WMM)/(WME)Yes
Reset buttonYes
Number of users200 user(s)
VLAN supportYes
Quality of Service (QoS) supportYes
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q
Ethernet LAN data rates10,100,1000 Mbit/s
CertificationCE, FCC, IC
Maximum data transfer rate1733 Mbit/s
MIMO typeMulti User MIMO
MIMOYes
Network
Number of users200 user(s)
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q
Management features
VLAN supportYes
Quality of Service (QoS) supportYes
Features
2.4 GHzYes
5 GHzYes
Wireless isolationYes
Wi-Fi Multimedia (WMM)/(WME)Yes
Number of users200 user(s)
VLAN supportYes
Quality of Service (QoS) supportYes
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q
Ethernet LAN data rates10,100,1000 Mbit/s
Maximum data transfer rate1733 Mbit/s
MIMO typeMulti User MIMO
MIMOYes
Throughput data rate1733 Mbit/s
Security
Number of SSID supported8
Security algorithmsAES, TKIP, WEP, WPA, WPA-Enterprise, WPA-PSK, WPA2
Service Set Identifier (SSID) featuresSSID broadcast on/off
Ports & interfaces
Ethernet LAN (RJ-45) ports1
DC-in jackYes
Power
Power consumption (typical)10.5 W
Power over Ethernet (PoE)Yes
AC input voltage44 - 57 V
Design
PlacementCeiling, Wall
Product colourWhite
Reset buttonYes
CertificationCE, FCC, IC
Antenna
Antenna typeInternal
Antenna gain level (max)3 dBi
Antenna featuresIntegrated antenna
Technical details
Reset buttonYes
Certificates
CertificationCE, FCC, IC
Weight & dimensions
Width6.3" (160 mm)
Depth6.3" (160 mm)
Weight10.6 oz (300 g)
Height1.29" (32.6 mm)
Packaging data
PoE adapter includedYes
Packaging content
PoE adapter includedYes
Operational conditions
Operating relative humidity (H-H)5 - 95%
Operating temperature (T-T)-10 - 70 °C
