Ubiquiti UniFi Pro 24-Port PoE Managed L2/L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Silver

Ubiquiti UniFi Pro 24-Port PoE Managed L2/L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Silver

  • Brand: Ubiquiti
  • Category:
  • SKU: USW-PRO-24-POE
  • EAN: 0817882028349 0817882027649 81 ...2027649 8178820276492more
USW-Pro-24-POE Gen 2, AC/DC, Internal, 450W, (24) 10/100/1000 RJ45 Ports, (2) 1/10G SFP+, 442.4 x 285.4 x 43.7 mm

Trade Prices

Distributor Product SKU Stock Updated Price
D&H

UniFi 24 Port Gigabit PoE Swit

 USWPRO24POE Register free see stock
Flytec Computers

- UniFi Pro 24-Port 400W budget 802.3at/802.3at 2-Port SFP+ PoE++ Switch Gen2

 USW-Pro-24-PoE
Ingram Micro

UNIFI 24PORT GB SWITCH PRO

 7AY307
Microcom Technologies

Pro 24 PoE

 USWPRO24POE
ScanSource

Gigabit Layer2 and Layer3 switch

 UBI-USWPRO24POE

Description

Second-Generation UniFi Switching
We’ve redesigned our UniFi Switches from the ground up.

Near Silent Cooling
Our new airflow design reduces the need for fan usage.

Powerful Hardware and Software
UniFi Switches offer a variety of features, including 10G SFP+ ports, PoE+ or PoE++ support, and Layer 3* switching capabilities.

Redundant Power System
UniFi SmartPower RPS, USP-RPS, is our PSU failover system.

Power Supply Failure
In the event of a UniFi switch power supply failure, the USP-RPS automatically supplies redundant power to the failed device.

UniFi SmartPower
One UniFi SmartPower device can support up to 6 devices until the failed device is replaced.

Touchscreen Display
The 1.3" touchscreen display allows easy monitoring and quick troubleshooting.

Specifications

Management features
Reset buttonYes
Switch typeManaged
Web-based managementYes
System event logYes
Quality of Service (QoS) supportYes
Switch layerL2/L3
Ports & interfaces
SFP+ module slots quantity2
Basic switching RJ-45 Ethernet ports quantity24
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Power connectorAC-in jack
Network
Networking standardsIEEE 802.3af, IEEE 802.3at
Full duplexYes
VLAN supportYes
Rate limitingYes
Port mirroringYes
Number of VLANs1000
Link aggregationYes
Flow control supportYes
Broadcast storm controlYes
10G supportYes
IPv4 routes64
IGMP snoopingYes
Data transmission
Throughput44000 Mpps
Packet buffer memory2 MB
MAC address table16000 entries
Switching capacity88 Gbit/s
Jumbo frames supportYes
Static routeYes
Forwarding rate65.472 Mpps
Number of VLANs1000
Security
IGMP snoopingYes
Authentication typeIEEE 802.1x, RADIUS
DHCP featuresDHCP relay, DHCP server, DHCP snooping
Design
Reset buttonYes
Display typeLCM
Form factor1U
Product colourSilver
LED indicatorsActivity, Link, PoE, Speed, System
Rack mountingYes
CertificationCE, FCC, IC
Power
Power consumption (max)450 W
Power supply includedYes
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Redundant power supply (RPS) supportYes
Number of power supply units1
Power sourceAC
Power connectorAC-in jack
Power over Ethernet (PoE)
Power over Ethernet (PoE) power per port64 W
Power over Ethernet plus (PoE+) ports quantity16
Total Power over Ethernet (PoE) budget400 W
Power over Ethernet (PoE)Yes
Power over Ethernet 4PPoE (PoE++) ports quantity8
Operational conditions
Operating temperature (T-T)-5 - 40 °C
Operating relative humidity (H-H)10 - 90%
Virtual LAN features
VLAN supportYes
Number of VLANs1000
Weight & dimensions
Width17.4" (442.4 mm)
Depth11.2" (285.4 mm)
Height1.72" (43.7 mm)
Weight9.48 lbs (4.3 kg)
Performance
Packet buffer memory2 MB
Harmonized System (HS) code85176990
Technical details
Form factor1U
Product colourSilver
Rack mountingYes
Memory
Packet buffer memory2 MB
Certificates
CertificationCE, FCC, IC
Indication
LED indicatorsActivity, Link, PoE, Speed, System
Logistics data
Harmonized System (HS) code85176990
