Vertiv Geist AG01X1R1-12CF13-3PS6PS6B211-D power distribution unit (PDU) 12 AC outlet(s) 0U Black
- Brand: Vertiv
- Category:
- SKU: VA1G9100
- EAN:
rPDU, Rack Transfer Switch Basic Upgradable, 32A, 230V, 7.3kW, Horizontal, (12) Combination C13/C19, 10ft / 3m power cord with 1P+N+E (IP44), Black Powder Coat.
Offer details
Trade Prices
| Distributor | Product | SKU | Stock | Updated | Price |
|---|---|---|---|---|---|
|
RPDU RACK TRANSFER SWITCH BASIC |
01RL48 |
Description
Rack Transfer Switch (RTS) delivers redundant power to single corded devices. The RTS automatically detects the loss of power and switches the power load (no phase-syncronization required) to the alternative power source in less than 4-8 milliseconds without the need for human intervention.
Specifications
| Design | |
|---|---|
| Type | Single-phase |
| PDU types | Basic |
| Mounting | Horizontal |
| Product colour | Black |
| Certification | CE Marked UKCA Marked Complies with IEC 62368-1 (DOC Available) Complies with EN 55032 and EN 55035 RoHS Compliant Cم Mark |
| Rack capacity | 0U |
| Ports & interfaces | |
| AC outlets quantity | 12 AC outlet(s) |
| AC outlet types | C13 coupler, C19 coupler |
| Power plug | IEC 60309 |
| Features | |
| Cable length | 118.1" (3 m) |
| Certification | CE Marked UKCA Marked Complies with IEC 62368-1 (DOC Available) Complies with EN 55032 and EN 55035 RoHS Compliant Cم Mark |
| Ergonomics | |
| Cable length | 118.1" (3 m) |
| Power | |
| Nominal input voltage | 200-240 V |
| Power protection features | Over current |
| Maximum current | 32 A |
| Load capacity | 230 VA |
| AC input frequency | 50/60 Hz |
| Number of phases | 1 |
| Weight & dimensions | |
| Width | 17" (432 mm) |
| Depth | 18" (457 mm) |
| Height | 1.73" (44 mm) |
| Package weight | 16 lbs (7.26 kg) |
| Packaging data | |
| Package weight | 16 lbs (7.26 kg) |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 60 °C |
