Vertiv Liebert GXT5-6KL630RT5UXLN uninterruptible power supply (UPS) Double-conversion (Online) 4.9 kVA 4600 W 4 AC outlet(s)
- Brand: Vertiv
- Category:
- SKU: GXT5-6KL630RT5UXLN
- EAN: 0767041026665
4900VA /4600W, 175-280V, 2x L6-15R, 2x L6-30R
Offer details
Description
The full range of single-phase Vertiv Liebert GXT5 UPS systems are easy to deploy with convertible rack/tower design that offers installation flexibility. Its gravity-sensing, color LCD provides a user-friendly interface for local configuration and management. Setup and integration are also easy with auto-detection of matching external battery cabinets for additional runtime solutions. With available network interface card (NIC), the Vertiv suite of management solutions including Trellis Power Insight and Vertiv LIFE Services are available to support your critical infrastructure. Designed for high availability and capacity, these compact UPS models with output power factors up to unity provide more usable power for connected equipment. High efficiency operation of this Energy Star 2.0 certified UPS means you get protection while supporting sustainability. Increased efficiency is also achieved with Active ECO operating mode.
Specifications
| Power | |
|---|---|
| Output power | 4600 W |
| Input operation voltage (min) | 175 V |
| Input operation voltage (max) | 280 V |
| Output operation voltage (min) | 200 V |
| Output operation voltage (max) | 240 V |
| Output power capacity | 4.9 kVA |
| Efficiency (On-line mode) | 95% |
| Efficiency (ECO mode) | 98% |
| Input frequency | 50/60 Hz |
| Performance | |
| UPS topology | Double-conversion (Online) |
| Waveform | Sine |
| Features | |
| UPS topology | Double-conversion (Online) |
| Waveform | Sine |
| Output power | 4600 W |
| Input operation voltage (min) | 175 V |
| Input operation voltage (max) | 280 V |
| Output operation voltage (min) | 200 V |
| Output operation voltage (max) | 240 V |
| Output power capacity | 4.9 kVA |
| Efficiency (On-line mode) | 95% |
| Efficiency (ECO mode) | 98% |
| Input frequency | 50/60 Hz |
| Ports & interfaces | |
| USB port | Yes |
| Serial interface | Yes |
| Serial interface type | RS-232, RS-485 |
| AC outlets quantity | 4 AC outlet(s) |
| AC outlet types | NEMA L6-20R, NEMA L6-30R |
| RS-232 ports | 1 |
| Design | |
| Form factor | Rackmount/Tower |
| Product colour | Black |
| Display type | LCD |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -15 - 40 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 118110.2" (0 - 3000 m) |
| Technical details | |
| Sustainability certificates | ENERGY STAR |
| Compliance certificates | REACH, RoHS |
| Certificates | |
| Compliance certificates | REACH, RoHS |
| Sustainability | |
| Sustainability certificates | ENERGY STAR |
| Weight & dimensions | |
| Weight | 149.9 lbs (68 kg) |
| Width | 16.9" (430 mm) |
| Height | 8.54" (217 mm) |
| Depth | 23.6" (600 mm) |
