Vertiv Liebert GXT5LI-2000LVRT2UXL uninterruptible power supply (UPS) Double-conversion (Online) 2 kVA 1800 W 7 AC outlet(s)
- Brand: Vertiv
- Category:
- SKU: GXT5LI-2000LVRT2UXL
- EAN: 0767041034905
Vertiv Liebert GXT5LI-2000LVRT2UXL, Double-conversion (Online), 2 kVA, 1800 W, Pure sine, 102 V, 150 V
Offer details
Trade Prices
| Distributor | Product | SKU | Stock | Updated | Price |
|---|---|---|---|---|---|
|
GXT5 Lithium Ion 2000VA UPS |
GXT5LI2000LVRT | |||
|
GXT5 LITHIUM-ION 2000VA UPS |
01RP77 | |||
|
GXT5 Lithium-Ion 2000VA UPS, 120VAC, 2U Rack/Tower |
6503979 |
Description
Vertiv Liebert GXT5LI-2000LVRT2UXL. UPS topology: Double-conversion (Online), Output power capacity: 2 kVA, Output power: 1800 W. AC outlet types: NEMA 5–15, NEMA 5–20R, NEMA L5-20R, Power plug: NEMA 5-20P, AC outlets quantity: 7 AC outlet(s). Battery technology: Lithium-Ion (Li-Ion), Typical backup time at full load: 10.5 min, Typical backup time at half load: 22.5 min. Form factor: Rackmount, Product color: Black, Rack capacity: 2U. Compliance certificates: REACH, RoHS, WEEE
Specifications
| Power | |
|---|---|
| Output power | 1800 W |
| Input operation voltage (min) | 102 V |
| Input operation voltage (max) | 150 V |
| Output operation voltage (min) | 100 V |
| Output operation voltage (max) | 125 V |
| Output power capacity | 2 kVA |
| Input frequency | 40 - 70 Hz |
| Ports & interfaces | |
| Cable length | 118.1" (3 m) |
| AC outlets quantity | 7 AC outlet(s) |
| AC outlet types | NEMA 5–15, NEMA 5–20R, NEMA L5-20R |
| Power plug | NEMA 5-20P |
| Performance | |
| UPS topology | Double-conversion (Online) |
| Waveform | Pure sine |
| Noise level | 48 dB |
| Features | |
| UPS topology | Double-conversion (Online) |
| Waveform | Pure sine |
| Output power | 1800 W |
| Input operation voltage (min) | 102 V |
| Input operation voltage (max) | 150 V |
| Output operation voltage (min) | 100 V |
| Output operation voltage (max) | 125 V |
| Noise level | 48 dB |
| Output power capacity | 2 kVA |
| Input frequency | 40 - 70 Hz |
| Battery | |
| Battery technology | Lithium-Ion (Li-Ion) |
| Battery recharge time | 2 h |
| Typical backup time at half load | 22.5 min |
| Typical backup time at full load | 10.5 min |
| Design | |
| Rack capacity | 2U |
| Form factor | Rackmount |
| Product colour | Black |
| Safety | UL 1642 (Li-Ion Battery Cells), UL 1973 (Li-Ion Battery Pack w/UPS), UL 1778, CSA 22.2 No. 107.3 |
| Cable length | 118.1" (3 m) |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 10 - 50% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 118110.2" (0 - 3000 m) |
| Technical details | |
| Compliance certificates | REACH, RoHS, WEEE |
| Certificates | |
| Compliance certificates | REACH, RoHS, WEEE |
| Safety | UL 1642 (Li-Ion Battery Cells), UL 1973 (Li-Ion Battery Pack w/UPS), UL 1778, CSA 22.2 No. 107.3 |
| Safety regulation & standards | |
| Safety | UL 1642 (Li-Ion Battery Cells), UL 1973 (Li-Ion Battery Pack w/UPS), UL 1778, CSA 22.2 No. 107.3 |
| Weight & dimensions | |
| Package width | 22.4" (570 mm) |
| Package depth | 23.5" (597 mm) |
| Package height | 9.53" (242 mm) |
| Weight | 39.7 lbs (18 kg) |
| Width | 16.9" (430 mm) |
| Package weight | 52.9 lbs (24 kg) |
| Height | 3.35" (85 mm) |
| Depth | 18.7" (475 mm) |
| Packaging data | |
| Package width | 22.4" (570 mm) |
| Package depth | 23.5" (597 mm) |
| Package height | 9.53" (242 mm) |
| Package weight | 52.9 lbs (24 kg) |
