Viewsonic IFP5550 interactive whiteboard 55" 3840 x 2160 pixels Touchscreen Black
- Brand: Viewsonic
- Category:
- SKU: IFP5550
- EAN:
55", 3840 x 2160, 16:9, 8ms, LED, ARM Mali450 MP4 1.2GHz, 2GB, 16GB, 2x 16 W RMS, LAN, 2x HDMI 1.4, HDMI 2.0, VGA, DP, RCA, 3.5mm, SPDIF, 3x USB 3.0, 3x USB 2.0, 2x USB B, RS-232, 1304x800x97 mm
Offer details
Related Products
Description
Featuring 4K Ultra HD resolution and an immersive 20-point touch screen, the ViewSonic ViewBoard IFP5550 delivers incredible collaborative capabilities for 21st century boardrooms and classrooms. With vBoard Embedded software, this 55” interactive flat panel lets multiple users write or draw on the screen with their fingers and styluses. For more robust annotation options, ViewBoard Interactive Annotation Software for Windows PC is available via a free download. With a built-in quad-core processor, as well as versatile connectivity options including multiple HDMI, VGA, RS232, RJ45, and USB ports, this display provides powerful computing for annotation and multimedia playback without the need for a PC. This display delivers optional slot-in PC capability for more computing-intensive interactive applications. The IFP5550 features a VESA-compatible design and can be placed on a wall mount, or on an optional trolley cart for flexible installation in classrooms and corporate meeting rooms.
Ultra HD Resolution
With four-times the resolution of Full HD, this Ultra HD 3840x2160 display delivers a breathtaking viewing experience with immersive images that are vibrant, clear, and as large as life.
20-point Multi-touch Interactive Screen
With a 20-point touch-enabled panel, this display encourages multiple users to simultaneously write or draw on the display's surface using styluses or their fingers – or both at the same time.
Add-on Qwizdom Software
Qwizdom's award-winning Oktopus collaboration software allows users to annotate and work over or alongside any application, existing content, or over a web browser. Qwizdom Ximbus is a whiteboarding and collaboration solution for Google and features Google Drive and Contacts integration. For more powerful teaching and enriched learning, these Qwizdom solutions can be purchased as separate add-ons to the ViewBoard.
Out-of-Box Collaboration
Integrated with ViewSonic vBoard embedded software and ViewBoard Cast, as well as Zoom software, this display delivers out-of-the-box annotation and content sharing capabilities.
ViewBoard Interactive Annotation Software
For more robust annotation options beyond the embedded vBoard software, ViewSonic ViewBoard Interactive Annotation Software can be installed via a free download.
Ultra HD Resolution
With four-times the resolution of Full HD, this Ultra HD 3840x2160 display delivers a breathtaking viewing experience with immersive images that are vibrant, clear, and as large as life.
20-point Multi-touch Interactive Screen
With a 20-point touch-enabled panel, this display encourages multiple users to simultaneously write or draw on the display's surface using styluses or their fingers – or both at the same time.
Add-on Qwizdom Software
Qwizdom's award-winning Oktopus collaboration software allows users to annotate and work over or alongside any application, existing content, or over a web browser. Qwizdom Ximbus is a whiteboarding and collaboration solution for Google and features Google Drive and Contacts integration. For more powerful teaching and enriched learning, these Qwizdom solutions can be purchased as separate add-ons to the ViewBoard.
Out-of-Box Collaboration
Integrated with ViewSonic vBoard embedded software and ViewBoard Cast, as well as Zoom software, this display delivers out-of-the-box annotation and content sharing capabilities.
ViewBoard Interactive Annotation Software
For more robust annotation options beyond the embedded vBoard software, ViewSonic ViewBoard Interactive Annotation Software can be installed via a free download.
Specifications
| Display | |
|---|---|
| Display diagonal | 55" |
| Contrast ratio (typical) | 1200:1 |
| Touchscreen | Yes |
| Number of simultaneous touchpoints | 20 |
| Viewing angle, vertical | 178° |
| Viewing angle, horizontal | 178° |
| Response time | 8 ms |
| Touch technology | Multi-touch |
| Display brightness | 350 cd/m² |
| Display resolution | 3840 x 2160 pixels |
| Features | |
| Display diagonal | 55" |
| Contrast ratio (typical) | 1200:1 |
| Touchscreen | Yes |
| Number of simultaneous touchpoints | 20 |
| Viewing angle, vertical | 178° |
| Viewing angle, horizontal | 178° |
| Response time | 8 ms |
| Touch technology | Multi-touch |
| Display brightness | 350 cd/m² |
| Display resolution | 3840 x 2160 pixels |
| Product colour | Black |
| Operating system installed | Android |
| Computer system | |
| Operating system installed | Android |
| Processor frequency | 1.2 GHz |
| Processor cores | 4 |
| Operating system version | 5.1 |
| Audio | |
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 2 |
| Network | |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Ethernet LAN | Yes |
| Ports & interfaces | |
| USB connector type | USB Type-A, USB Type-B |
| HDMI ports quantity | 3 |
| Composite video in | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| HDMI version | 1.4/2.0 |
| DisplayPorts quantity | 1 |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Ethernet LAN | Yes |
| Ergonomics | |
| Product colour | Black |
| Certification | cTUVus, FCC, Mexico Energy, CE, CB, ErP, WEEE |
| VESA mounting | Yes |
| Panel mounting interface | 400 x 400 mm |
| Power | |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (typical) | 350 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (off) | 0.5 W |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage temperature (T-T) | -20 - 60 °C |
| Storage relative humidity (H-H) | 10 - 90% |
| Performance | |
| Remote control included | Yes |
| Technical details | |
| Touchscreen | Yes |
| Viewing angle, vertical | 178° |
| Viewing angle, horizontal | 178° |
| Response time | 8 ms |
| Compliance certificates | RoHS |
| Remote control included | Yes |
| Weight & dimensions | |
| Width | 51.3" (1304 mm) |
| Depth | 3.82" (97 mm) |
| Height | 31.5" (800 mm) |
| Weight | 71.7 lbs (32.5 kg) |
| Packaging data | |
| Package width | 57.4" (1458 mm) |
| Package depth | 8.66" (220 mm) |
| Package height | 36.7" (932 mm) |
| Package weight | 92.6 lbs (42 kg) |
| Projector | |
| Contrast ratio (typical) | 1200:1 |
| Packaging content | |
| Cables included | AC, AV, Audio (3.5mm), USB, VGA |
| Quick start guide | Yes |
| Remote control included | Yes |
| Processor | |
| Processor frequency | 1.2 GHz |
| Processor cores | 4 |
| Sustainability | |
| Compliance certificates | RoHS |
| Certificates | |
| Certification | cTUVus, FCC, Mexico Energy, CE, CB, ErP, WEEE |
| Colour | |
| Product colour | Black |
