APC SMT2200C uninterruptible power supply (UPS) Line-Interactive 2.2 kVA 1980 W 10 AC outlet(s)
- Brand: APC
- Category:
- SKU: SMT2200C
- EAN: 0731304331049
2.2 kVA, 1.98 kW, 75-154V, 50/60Hz. 530J, 196x544x432mm, 50.9kg, Black
Offer details
Trade Prices
| Distributor | Product | SKU | Stock | Updated | Price |
|---|---|---|---|---|---|
|
UPS |
APCSMT2200C | |||
|
SMART-UPS SMARTCONNECT,2200VAREMOTE MONT, (8)5-15R,(2)5-20RTWR, 5-20P - 6FT |
956062 | |||
|
Smart-UPS SMT2200C 2200VA LCD 120V with SmartConnect Brown Box |
219459 | |||
|
2200VA Smart UPS C LCD 120V |
SMT2200C | |||
|
SMART UPS 2200VA LCD 120V WITH |
2MZ146 | |||
|
APC Smart-UPS 2200VA LCD 120V with SC |
APC-SMT2200C | |||
|
2200VA LCD 120V WITH SMARTCONNECT |
5080458 |
Related Products
- Temperature Transmitters
- Temperature & Humidity Sensors
- UPS Batteries
- Installation Services
- Warranty & Support Extensions
- Interface Cards/Adapters
- Networking Cables
- Power Distribution Units (PDUs)
- UPS Accessories
- Network Cards
- Software Licenses/Upgrades
-
Category: Installation Services -
Category: Installation Services
-
Category: Warranty & Support Extensions -
Category: Warranty & Support Extensions -
Category: Warranty & Support Extensions -
Category: Warranty & Support Extensions
-
Category: Warranty & Support Extensions -
Category: Warranty & Support Extensions
-
Category: Warranty & Support Extensions -
Category: Warranty & Support Extensions -
Category: Warranty & Support Extensions
-
Category: Power Distribution Units (PDUs) -
Category: Power Distribution Units (PDUs)
-
Category: UPS Accessories -
Category: UPS Accessories
-
Category: Software Licenses/Upgrades -
Category: Software Licenses/Upgrades
-
Category: Software Licenses/Upgrades
-
Category: Software Licenses/Upgrades
-
Category: Software Licenses/Upgrades -
Category: Software Licenses/Upgrades
Description
Smart-UPS 2200VA with APC SmartConnect
Protect your servers, switches, routers and networking devices while providing battery backup power with Smart-UPS SMT2200C with APC SmartConnect, the first cloud-enabled UPS for distributed IT. The service-free cloud monitoring feature is accessible from any internet-connected device, and maximizes the life and performance of your UPS by providing proactive advice and life-cycle recommendations so you can remotely monitor your power infrastructure from anywhere.
An Overview of Smart-UPS and the SmartConnect App
APC SmartConnect makes Smart-UPS more adaptable and easier to deploy than ever before, enabling you to view the status of your UPS through a secure web portal. Through this intuitive remote management interface, you’ll receive automatic notifications, firmware updates, and advanced support; providing you with added value – and more importantly – added peace of mind.
Secure, remote monitoring
Connected Smart-UPS support remote monitoring through a secure web portal, so you can always be up to date on the status of your power infrastructure.
Proactive lifecycle alerts
Maximize the life span of the UPS and protect your investment with proactive alerts for firmware upgrade, device maintenance, and warranty protection.
Cloud enabled as standard
Smart-UPS models with SmartConnect are cloud-enabled and have a built-in Ethernet port, making it easy and cost effective to monitor your UPS online.
Simple to Use Interface
Our simple web interface is designed to support both system administrators and non-tech users alike, with clear notifications in plain language.
Protect your servers, switches, routers and networking devices while providing battery backup power with Smart-UPS SMT2200C with APC SmartConnect, the first cloud-enabled UPS for distributed IT. The service-free cloud monitoring feature is accessible from any internet-connected device, and maximizes the life and performance of your UPS by providing proactive advice and life-cycle recommendations so you can remotely monitor your power infrastructure from anywhere.
An Overview of Smart-UPS and the SmartConnect App
APC SmartConnect makes Smart-UPS more adaptable and easier to deploy than ever before, enabling you to view the status of your UPS through a secure web portal. Through this intuitive remote management interface, you’ll receive automatic notifications, firmware updates, and advanced support; providing you with added value – and more importantly – added peace of mind.
Secure, remote monitoring
Connected Smart-UPS support remote monitoring through a secure web portal, so you can always be up to date on the status of your power infrastructure.
Proactive lifecycle alerts
Maximize the life span of the UPS and protect your investment with proactive alerts for firmware upgrade, device maintenance, and warranty protection.
Cloud enabled as standard
Smart-UPS models with SmartConnect are cloud-enabled and have a built-in Ethernet port, making it easy and cost effective to monitor your UPS online.
Simple to Use Interface
Our simple web interface is designed to support both system administrators and non-tech users alike, with clear notifications in plain language.
Specifications
| Power | |
|---|---|
| Output frequency | 50/60 Hz |
| Output power | 1980 W |
| Input operation voltage (min) | 75 V |
| Input operation voltage (max) | 154 V |
| Output operation voltage (min) | 110 V |
| Output operation voltage (max) | 127 V |
| Surge energy rating | 530 J |
| Emergency Power Off (EPO) | Yes |
| Output voltage Total Harmonic Distortion (THD) | 5% |
| Output power capacity | 2.2 kVA |
| Input frequency | 50/60 Hz |
| Ports & interfaces | |
| Cable length | 72" (1.83 m) |
| USB port | Yes |
| Serial interface | Yes |
| Serial interface type | RS-232 |
| SmartSlot | Yes |
| AC outlets quantity | 10 AC outlet(s) |
| AC outlet types | NEMA 5–15R, NEMA 5–20R |
| Power plug | NEMA 5-20P |
| USB 2.0 ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Performance | |
| Audible alarm modes | Alarm when on battery, Low battery alarm, Overload alarm |
| UPS topology | Line-Interactive |
| Waveform | Sine |
| Auto-restart | Yes |
| Automatic Voltage Regulation (AVR) | Yes |
| LED indicators | Yes |
| Surge protection | No |
| Noise level | 45 dB |
| Audible alarm(s) | Yes |
| Temperature voltage compensation | Yes |
| Features | |
| Output frequency | 50/60 Hz |
| Web-based management | Yes |
| Audible alarm modes | Alarm when on battery, Low battery alarm, Overload alarm |
| UPS topology | Line-Interactive |
| Waveform | Sine |
| Auto-restart | Yes |
| Automatic Voltage Regulation (AVR) | Yes |
| Output power | 1980 W |
| Input operation voltage (min) | 75 V |
| Input operation voltage (max) | 154 V |
| Output operation voltage (min) | 110 V |
| Output operation voltage (max) | 127 V |
| Surge energy rating | 530 J |
| Surge protection | No |
| Emergency Power Off (EPO) | Yes |
| Output voltage Total Harmonic Distortion (THD) | 5% |
| Noise level | 45 dB |
| Audible alarm(s) | Yes |
| Output power capacity | 2.2 kVA |
| Temperature voltage compensation | Yes |
| Input frequency | 50/60 Hz |
| Battery | |
| Battery life (max) | 5 year(s) |
| Number of batteries supported | 1 |
| Battery technology | Sealed Lead Acid (VRLA) |
| Battery recharge time | 3 h |
| Hot-swap battery | Yes |
| Automatic battery test | Yes |
| Design | |
| Form factor | Tower |
| LED indicators | Yes |
| Product colour | Black |
| Certification | CSA, FCC, UL |
| Cable length | 72" (1.83 m) |
| Display type | LCD |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -15 - 45 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 118110.2" (0 - 3000 m) |
| Non-operating altitude | 0 - 590551.2" (0 - 15000 m) |
| Technical details | |
| Output frequency | 50/60 Hz |
| Sustainability certificates | ENERGY STAR |
| Certificates | |
| Certification | CSA, FCC, UL |
| Management features | |
| Web-based management | Yes |
| Sustainability | |
| Sustainability certificates | ENERGY STAR |
| Weight & dimensions | |
| Package width | 15" (381 mm) |
| Package depth | 30" (762 mm) |
| Package height | 22" (559 mm) |
| Weight | 112.2 lbs (50.9 kg) |
| Width | 7.72" (196 mm) |
| Package weight | 134.3 lbs (60.9 kg) |
| Height | 17" (432 mm) |
| Depth | 21.4" (544 mm) |
| Packaging data | |
| Package width | 15" (381 mm) |
| Package depth | 30" (762 mm) |
| Package height | 22" (559 mm) |
| Package weight | 134.3 lbs (60.9 kg) |
| Logistics data | |
| Products per pallet | 9 pc(s) |
