Lenovo IdeaCentre Mini Intel® Core™ i7 i7-13620H 16 GB DDR4-SDRAM 1 TB SSD Windows 11 Pro Mini PC Gray
- Brand: Lenovo
- Category:
- SKU: 90W2006PCM
- EAN: 0198154135928
Intel Core i7-13620H (24MB Cache), 16GB DDR4-SDRAM, 1000GB SSD, Intel UHD Graphics, LAN, WLAN, Bluetooth, Windows 11 Pro 64-bit
Offer details
Trade Prices
| Distributor | Product | SKU | Stock | Updated | Price |
|---|---|---|---|---|---|
|
Mini 01IRH8 |
90W2006PCMSCS |
Related Products
- Video Cable Adapters
- Soundbar Speakers
- HDMI Cables
- Mice
- USB Cables
- Headphones & Headsets
- Numeric Keypads
- Keyboards
- Mouse Pads
- Webcams
- Network Cards
- Warranty & Support Extensions
-
Category: HDMI Cables
-
Category: USB Cables -
Category: USB Cables -
Category: USB Cables -
Category: USB Cables
-
Category: Headphones & Headsets -
Category: Headphones & Headsets -
Category: Headphones & Headsets -
Category: Headphones & Headsets -
Category: Headphones & Headsets -
Category: Headphones & Headsets -
Category: Headphones & Headsets -
Category: Headphones & Headsets -
Category: Headphones & Headsets -
Category: Headphones & Headsets -
Category: Headphones & Headsets -
Category: Headphones & Headsets -
Category: Headphones & Headsets -
Category: Headphones & Headsets -
Category: Headphones & Headsets -
Category: Headphones & Headsets -
Category: Headphones & Headsets -
Category: Headphones & Headsets -
Category: Headphones & Headsets
-
Category: Mouse Pads -
Category: Mouse Pads -
Category: Mouse Pads -
Category: Mouse Pads -
Category: Mouse Pads
-
Category: Network Cards -
Category: Network Cards
-
Category: Warranty & Support Extensions -
Category: Warranty & Support Extensions
-
Category: Warranty & Support Extensions
Description
Mini 01IRH8
Specifications
| Processor | |
|---|---|
| Processor generation | 13th gen Intel® Core™ i7 |
| Configurable TDP-down | 35 W |
| Processor cache type | Smart Cache |
| Processor cache | 24 MB |
| Processor model | i7-13620H |
| Number of processors installed | 1 |
| Processor manufacturer | Intel |
| Processor boost frequency | 4.9 GHz |
| Processor threads | 16 |
| Processor cores | 10 |
| Processor family | Intel® Core™ i7 |
| Performance cores | 6 |
| Efficient cores | 4 |
| Processor base power | 45 W |
| Maximum turbo power | 115 W |
| Efficient-core Max Turbo Frequency | 3.6 GHz |
| Performance-core Max Turbo Frequency | 4.9 GHz |
| Memory | |
| Internal memory | 16 GB |
| Memory layout (slots x size) | 1 x 16 GB |
| Maximum internal memory | 32 GB |
| Memory slots | 2x SO-DIMM |
| Internal memory type | DDR4-SDRAM |
| Memory clock speed | 3200 MHz |
| Memory channels | Dual-channel |
| Storage | |
| Intel® Optane™ Memory module installed | No |
| Storage media | SSD |
| Number of storage drives installed | 1 |
| Optical drive type | No |
| SSD interface | PCI Express 4.0 |
| SSD capacity | 1 TB |
| Number of SSDs installed | 1 |
| Card reader integrated | No |
| Total storage capacity | 1 TB |
| SSD form factor | M.2 |
| Total SSDs capacity | 1 TB |
| NVMe | Yes |
| Graphics | |
| Discrete graphics card | No |
| On-board graphics card family | Intel® UHD Graphics |
| On-board graphics card | Yes |
| Discrete graphics card model | Not available |
| On-board graphics card model | Intel® UHD Graphics |
| On-board GPU manufacturer | Intel |
| Optical drive | |
| Optical drive type | No |
| Network | |
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Bluetooth | Yes |
| Bluetooth version | 5.1 |
| Wi-Fi standards | Wi-Fi 6 (802.11ax) |
| Ethernet LAN data rates | 10,100,1000,2500 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
| Bluetooth Low Energy (BLE) | No |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Antenna type | 2x2 |
| Ports & interfaces | |
| Combo headphone/mic port | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| TV-out | No |
| Thunderbolt 2 ports quantity | 0 |
| HDMI version | 2.1 |
| VGA (D-Sub) ports quantity | 0 |
| USB 2.0 ports quantity | 1 |
| Mini DisplayPorts quantity | 0 |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| DVI port | No |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.4 |
| USB 3.2 Gen 2x2 Type-C ports quantity | 0 |
| USB4 Gen 2x2 ports quantity | 0 |
| USB4 Gen 3x2 ports quantity | 0 |
| Intel® Thunderbolt 4 | Yes |
| Thunderbolt 4 ports quantity | 1 |
| Number of rear USB ports | 0 |
| Number of front USB ports | 0 |
| Technical details | |
| Product type | Mini PC |
| Trusted Platform Module (TPM) | Yes |
| Product colour | Gray |
| Chassis type | Mini PC |
| Audio system | High Definition Audio |
| Placement supported | Horizontal/Vertical |
| Motherboard chipset | Intel SoC |
| Sustainability certificates | ENERGY STAR |
| Warranty period | 2 year(s) |
| Compliance certificates | RoHS |
| Design | |
| Volume | 1 L |
| Product colour | Gray |
| Chassis type | Mini PC |
| Placement supported | Horizontal/Vertical |
| Colour name | Cloud Grey |
| Performance | |
| Audio chip | Realtek ALC256 |
| Password protection | Yes |
| Password protection type | HDD, Power on, Supervisor |
| Product type | Mini PC |
| Trusted Platform Module (TPM) | Yes |
| Audio system | High Definition Audio |
| Motherboard chipset | Intel SoC |
| Trusted Platform Module (TPM) version | 2.0 |
| Software | |
| Operating system language | English, French |
| Operating system architecture | 64-bit |
| Operating system installed | Windows 11 Pro |
| Processor special features | |
| CPU configuration (max) | 1 |
| Power | |
| Power supply input frequency | 50 - 60 Hz |
| Power supply input voltage | 100 - 240 V |
| Power supply | 150 W |
| Operational conditions | |
| Operating altitude | 0 - 120000" (0 - 3048 m) |
| Storage temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 10 - 35 °C |
| Non-operating altitude | 0 - 480000" (0 - 12192 m) |
| Certificates | |
| Certification | ENERGY STAR 8.0 ErP Lot 3 RoHS compliant |
| Compliance certificates | RoHS |
| Sustainability | |
| Sustainability certificates | ENERGY STAR |
| Weight & dimensions | |
| Volume | 1 L |
| Package width | 12.4" (315 mm) |
| Package depth | 4.61" (117 mm) |
| Package height | 10.6" (270 mm) |
| Width | 7.54" (191.4 mm) |
| Depth | 7.68" (195 mm) |
| Height | 1.54" (39 mm) |
| Package weight | 4.85 lbs (2.2 kg) |
| Weight | 3.97 lbs (1.8 kg) |
| Packaging data | |
| Package width | 12.4" (315 mm) |
| Package depth | 4.61" (117 mm) |
| Package height | 10.6" (270 mm) |
| Package weight | 4.85 lbs (2.2 kg) |
| Packaging content | |
| Mouse included | No |
| Display included | No |
| Keyboard included | No |
| Display | |
| Display included | No |
| Other features | |
| Trusted Platform Module (TPM) | Yes |
| On-board graphics card | Yes |
| Processor manufacturer | Intel |
| TV tuner integrated | No |
| Built-in microphone | No |
| Warranty period | 2 year(s) |
