Tripp Lite B072-032-IP2-K KVM switch Rack mounting Black
- Brand: Tripp Lite
- Category:
- SKU: B072-032-IP2-K
- EAN: 0037332181442 0373321814428
NetCommander 32-Port Cat5 KVM over IP Switch - 2 Remote + 1 Local User, 16 USB Dongles, 1U Rack-Mount, TAA
Offer details
Trade Prices
Related Products
Description
This B072-032-IP2-K KVM Switch is the optimal solution for controlling up to 32 computers/servers locally from across the room, down the street or around the globe on a network or the Internet.
This KVM switch can be accessed and controlled remotely, so there’s no need to travel to the server room or network closet. A Java-based application allows access via web browser from any secure IP connection. A non-browser client that can bypass browser-related Java Security prompts is available.
The B072-032-IP2-K uses inexpensive, user-supplied Cat5e/6/6a cabling with Server Interface Units (16 included) so you can connect computers/servers located up to 100 feet away from the switch. This switch features dual Ethernet ports and dual power supplies. If one fails, the other takes over, keeping access uninterrupted. Switch easily between the 32 ports using an on-screen display (OSD), hotkey commands or a remote toolbar. Multi-level password protection prohibits unauthorized users from accessing connected computers, and a local user and up to two remote users can each log on and access different ports simultaneously.
Two serial ports allow control of serial-manageable devices such as IP PDUs, firewalls and routers. Individual ports can be assigned to an IP PDU port to power on/off the server connected to that port. This KVM switch is compatible with Windows and Linux operating systems, and provides remote access using a Windows computer. It supports VGA video resolutions up to 1920 x 1080 at 60 Hz. Heavy-duty steel housing stands up to frequent use.
Virtual Media allows an .iso file to be mounted to a target server and accessed as if it were stored directly on it. Virtual Media data transfer rates up to 12 Mbps are supported when using a B078-101-USB2 Server Interface Unit. Other features include RADIUS and LDAP/S authentication, system-sent SNMP messaging and an event log that tracks logins, reboots and network setting changes.
Free NetCommander-AXS Management Software is available to access and control all of your NetCommander IP KVM switches (B070 and B072 series). From a single interface, you can access server ports on any of your KVM switches, power cycle or power on/off outlets of IP PDUs and manage KVM settings. This software can be downloaded free of charge from the model support page for the B072-032-IP2-K.
This KVM switch can be accessed and controlled remotely, so there’s no need to travel to the server room or network closet. A Java-based application allows access via web browser from any secure IP connection. A non-browser client that can bypass browser-related Java Security prompts is available.
The B072-032-IP2-K uses inexpensive, user-supplied Cat5e/6/6a cabling with Server Interface Units (16 included) so you can connect computers/servers located up to 100 feet away from the switch. This switch features dual Ethernet ports and dual power supplies. If one fails, the other takes over, keeping access uninterrupted. Switch easily between the 32 ports using an on-screen display (OSD), hotkey commands or a remote toolbar. Multi-level password protection prohibits unauthorized users from accessing connected computers, and a local user and up to two remote users can each log on and access different ports simultaneously.
Two serial ports allow control of serial-manageable devices such as IP PDUs, firewalls and routers. Individual ports can be assigned to an IP PDU port to power on/off the server connected to that port. This KVM switch is compatible with Windows and Linux operating systems, and provides remote access using a Windows computer. It supports VGA video resolutions up to 1920 x 1080 at 60 Hz. Heavy-duty steel housing stands up to frequent use.
Virtual Media allows an .iso file to be mounted to a target server and accessed as if it were stored directly on it. Virtual Media data transfer rates up to 12 Mbps are supported when using a B078-101-USB2 Server Interface Unit. Other features include RADIUS and LDAP/S authentication, system-sent SNMP messaging and an event log that tracks logins, reboots and network setting changes.
Free NetCommander-AXS Management Software is available to access and control all of your NetCommander IP KVM switches (B070 and B072 series). From a single interface, you can access server ports on any of your KVM switches, power cycle or power on/off outlets of IP PDUs and manage KVM settings. This software can be downloaded free of charge from the model support page for the B072-032-IP2-K.
Specifications
Ports & interfaces | |
---|---|
Keyboard port type | USB, PS/2 |
Mouse port type | USB, PS/2 |
Video port type | VGA |
USB 2.0 ports quantity | 2 |
Network | |
Ethernet LAN | Yes |
Performance | |
Maximum resolution | 1920 x 1080 pixels |
Number of users | 3 user(s) |
Technical details | |
Product colour | Black |
Rack mounting | Yes |
On Screen Display (OSD) | Yes |
Number of users | 3 user(s) |
Compliance certificates | RoHS |
Design | |
Product colour | Black |
Rack mounting | Yes |
Certification | UL 60950-1 (USA), CSA (Canada), FCC Part 15 Class A, CE IEC 60950-1 |
Rack capacity | 1U |
Country of origin | Taiwan |
Display | |
Built-in display | No |
On Screen Display (OSD) | Yes |
Video | |
Maximum resolution | 1920 x 1080 pixels |
Features | |
Country of origin | Taiwan |
Sustainability | |
Compliance certificates | RoHS |
Operational conditions | |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -20 - 60 °C |
Operating relative humidity (H-H) | 0 - 80% |
Weight & dimensions | |
Width | 17.3" (438.9 mm) |
Depth | 11" (279.1 mm) |
Height | 1.71" (43.4 mm) |
Weight | 7.67 lbs (3.48 kg) |
Package width | 14.4" (365.8 mm) |
Package depth | 23" (584.2 mm) |
Package height | 5.7" (144.8 mm) |
Package weight | 14.2 lbs (6.44 kg) |
Packaging data | |
Package width | 14.4" (365.8 mm) |
Package depth | 23" (584.2 mm) |
Package height | 5.7" (144.8 mm) |
Package weight | 14.2 lbs (6.44 kg) |
Certificates | |
Certification | UL 60950-1 (USA), CSA (Canada), FCC Part 15 Class A, CE IEC 60950-1 |
Other features | |
Ports quantity | 32 |
Logistics data | |
Country of origin | Taiwan |
Master (outer) case width | 15.2" (386.1 mm) |
Master (outer) case length | 23.7" (602 mm) |
Master (outer) case height | 12.5" (317.5 mm) |
Master (outer) case gross weight | 31.1 lbs (14.1 kg) |
Products per master (outer) case | 2 pc(s) |
Master (outer) case GTIN (EAN/UPC) | 10037332181449 |
Harmonized System (HS) code | 8471.80.1000 |
