HPE ProLiant DL380p Gen8 server Rack (2U) Intel® Xeon® E5 V2 Family E5-2630V2 2.6 GHz 16 GB DDR3-SDRAM 460 W

HPE ProLiant DL380p Gen8 server Rack (2U) Intel® Xeon® E5 V2 Family E5-2630V2 2.6 GHz 16 GB DDR3-SDRAM 460 W

  • Brand: HPE
  • Category:
  • SKU: 704559-001
  • EAN: 0887111441164 8871114411646
HPE ProLiant DL380p Gen8, 2.6 GHz, E5-2630V2, 16 GB, DDR3-SDRAM, 460 W, Rack (2U)

Trade Prices

Distributor Product SKU Stock Updated Price
Ingram Micro HPE PROLIANT DL380P GEN8 8SFF NQ4959 Register free see stock

Related Products

Description

HPE ProLiant DL380p Gen8. Processor family: Intel® Xeon® E5 V2 Family, Processor frequency: 2.6 GHz, Processor model: E5-2630V2. Internal memory: 16 GB, Internal memory type: DDR3-SDRAM, Memory layout (slots x size): 1 x 16 GB. HDD size: 2.5", HDD interface: Serial ATA, Serial Attached SCSI (SAS). Ethernet LAN, Cabling technology: 10/100/1000Base-T(X). Power supply: 460 W, Redundant power supply (RPS) support. Chassis type: Rack (2U)

Specifications

Processor
Thermal Monitoring TechnologiesYes
Thermal Design Power (TDP)80 W
Tcase71 °C
Supported instruction setsAVX
Scalability2S
Processor threads12
Processor package size52.5 x 45 mm
Processor operating modes64-bit
Processor lithography22 nm
Processor codenameIvy Bridge EP
Physical Address Extension (PAE)46 bit
PCI Express configurationsx4, x8, x16
Number of QPI links2
Memory types supported by processorDDR3-SDRAM
Memory clock speeds supported by processor800,1066,1333,1600 MHz
Memory channels supported by processorQuad
Memory bandwidth supported by processor (max)51.2 GB/s
Maximum number of PCI Express lanes40
Maximum internal memory supported by processor768 GB
Idle StatesYes
FSB ParityNo
Execute Disable BitYes
Embedded options availableYes
ECC supported by processorYes
Bus typeQPI
Processor cache typeSmart Cache
Processor cache15 MB
Conflict-Free processorNo
Processor seriesIntel Xeon E5-2600 v2
Processor frequency2.6 GHz
Number of processors installed1
Processor modelE5-2630V2
Processor boost frequency3.1 GHz
System bus rate7.2 GT/s
Processor socketLGA 2011 (Socket R)
Processor cores6
Processor manufacturerIntel
Motherboard chipsetIntel C600
Maximum number of SMP processors2
Processor familyIntel® Xeon® E5 V2 Family
Memory
Internal memory16 GB
Memory layout (slots x size)1 x 16 GB
Memory slots24x DIMM
Memory clock speed1600 MHz
Maximum internal memory384 GB
Internal memory typeDDR3-SDRAM
ECCYes
Storage
RAID supportYes
RAID levels0, 1, 1+0, 5, 5+0, 6
Optical drive typeNo
Number of HDDs supported8
Hot-Plug supportYes
HDD size2.5"
HDD interfaceSerial ATA, Serial Attached SCSI (SAS)
Network
LAN controllerHP 331FLR
Ethernet LANYes
Ethernet interface typeGigabit Ethernet
Cabling technology10/100/1000Base-T(X)
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity0
VGA (D-Sub) ports quantity2
USB 2.0 ports quantity6
Serial ports quantity1
Ethernet LAN (RJ-45) ports4
Expansion slots
PCI Express x8 (Gen 2.x) slots1
PCI Express x16 (Gen 3.x) slots1
PCI Express slots version3.0
PCI Express x8 (Gen 3.x) slots1
Optical drive
Optical drive typeNo
Design
Rack mountingYes
Optical drive typeNo
Chassis typeRack (2U)
Graphics
Graphics card familyMatrox
Graphics cardG200
Performance
Compatible operating systemsMicrosoft Windows Server Canonical Ubuntu Red Hat Enterprise Linux (RHEL) SUSE Linux Enterprise Server (SLES) Oracle Solaris VMware Citrix XenServer
Operating system installedNo
Software
Compatible operating systemsMicrosoft Windows Server Canonical Ubuntu Red Hat Enterprise Linux (RHEL) SUSE Linux Enterprise Server (SLES) Oracle Solaris VMware Citrix XenServer
Operating system installedNo
Processor special features
Intel® Wireless Display (Intel® WiDi)No
Intel® Identity Protection Technology (Intel® IPT)No
Enhanced Intel SpeedStep TechnologyYes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel® OS GuardYes
Intel VT-x with Extended Page Tables (EPT)Yes
Intel® Turbo Boost Technology2.0
Intel TSX-NINo
Intel Trusted Execution TechnologyYes
Intel® Secure KeyYes
Intel® Quick Sync Video TechnologyNo
Intel® My WiFi Technology (Intel® MWT)No
Intel® InTru™ 3D TechnologyNo
Intel® Insider™No
Intel® Hyper Threading Technology (Intel® HT Technology)Yes
Intel Flex Memory AccessNo
Intel Enhanced Halt StateYes
Intel Demand Based SwitchingYes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)No
Intel Clear Video TechnologyNo
Intel® Clear Video HD Technology (Intel® CVT HD)No
Intel® Anti-Theft Technology (Intel® AT)No
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel 64Yes
Intel Virtualization Technology (VT-x)Yes
Intel TSX-NI version0.00
Intel Secure Key Technology version1.00
Intel Identity Protection Technology version0.00
Intel FDI TechnologyNo
Intel Dual Display Capable TechnologyNo
Intel Fast Memory AccessNo
Processor ARK ID75790
Intel Rapid Storage TechnologyNo
CPU configuration (max)2
Power
Number of main power supplies1
Redundant power supply (RPS) supportYes
Power supply460 W
Technical details
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel Rapid Storage TechnologyNo
Rack mountingYes
Hot-Plug supportYes
Ethernet interface typeGigabit Ethernet
CPU configuration (max)2
Chassis typeRack (2U)
PCI Express x8 (Gen 3.x) slots1
Weight & dimensions
Width17.5" (445.5 mm)
Weight41 lbs (18.6 kg)
Height3.44" (87.4 mm)
Depth27.5" (698.5 mm)
Other features
Graphics card familyMatrox
Graphics cardG200
CPU configuration (max)2
