Tripp Lite IS1000HGDV isolation transformer

Tripp Lite IS1000HGDV isolation transformer

Isolator Series Dual-Voltage 115/230V 1000W 60601-1 Medical-Grade Isolation Transformer, C14 Inlet, 8 C13 Outlets

Trade Prices

Distributor Product SKU Stock Updated Price
Anixter ISOLATOR SERIES DUAL-VOLTAGE115/230V 1000W 60601-1MEDICAL-GRADE 9810325 Register free see stock
Ingram Micro ISOLATION TRANSFORMER HOSPITAL 3BU436
ScanSource Isolation Transformer Hospital POW-IS1000HGDV
TD Synnex ISOLATION TRANSFORMER HOSPITAL 1000W 5117275

Description





Specifications

Features
AC inlet typeC20 coupler
AC outlet typesC13
AC outlets quantity8 AC outlet(s)
AC input voltage115 - 230 V
AC input frequency50 - 60 Hz
Load capacity1000 VA
Input current (max)10 A
Housing colourWhite
CertificationANSI/AAMI ES60601-1:2005+A2+A1, IEC60601-1 3RD EDITION +A1, cAN/CSA-C22.2 NO. 60601-1:14, CE, NOM
Short circuit protectionYes
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 50 °C
Operating relative humidity (H-H)5 - 95%
Operating altitude0 - 118110.2" (0 - 3000 m)
Weight & dimensions
Width9.84" (249.9 mm)
Depth11.8" (300 mm)
Height5.13" (130.3 mm)
Weight30.2 lbs (13.7 kg)
Package width15" (380 mm)
Package depth17.1" (435.1 mm)
Package height10.2" (260.1 mm)
Package weight32.4 lbs (14.7 kg)
Technical details
Products per master (outer) case1 pc(s)
Master (outer) case width15" (380 mm)
Master (outer) case gross weight32.4 lbs (14.7 kg)
Master (outer) case length17.1" (435.1 mm)
Master (outer) case height10.2" (260.1 mm)
Logistics data
Country of originTaiwan
Products per master (outer) case1 pc(s)
Master (outer) case width15" (380 mm)
Master (outer) case gross weight32.4 lbs (14.7 kg)
Master (outer) case length17.1" (435.1 mm)
Master (outer) case height10.2" (260.1 mm)
