Tripp Lite IS1800HGDV isolation transformer

Tripp Lite IS1800HGDV isolation transformer

Isolator Series Dual-Voltage 115/230V 1800W 60601-1 Medical-Grade Isolation Transformer, C20 Inlet, 8 C13 Outlets

Trade Prices

Distributor Product SKU Stock Updated Price
Anixter ISOLATOR SERIES 15/230V 1800W60601-1 MEDICAL-GRA ISOLATIONTRANSFORMERC20(8)C13 1053905 Register free see stock
Ingram Micro ISOLATION TRANSFORMER HOSPITAL 3BU437
ScanSource Isolation Transformer Hospital POW-IS1800HGDV
TD Synnex ISOLATION TRANSFORMER HOSPITAL 1800W 5174759

Description





Specifications

Features
AC inlet typeC20 coupler
AC outlet typesC13
AC outlets quantity8 AC outlet(s)
AC input voltage115 - 230 V
AC input frequency50 - 60 Hz
Load capacity1800 VA
Input current (max)15 A
Housing colourWhite
CertificationANSI/AAMI ES60601-1:2005+A2+A1, IEC60601-1 3RD EDITION +A1, cAN/CSA-C22.2 NO. 60601-1:14, CE, NOM
Short circuit protectionYes
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 50 °C
Operating relative humidity (H-H)5 - 95%
Operating altitude0 - 118110.2" (0 - 3000 m)
Weight & dimensions
Width11.8" (300 mm)
Depth13.8" (350 mm)
Height5.51" (140 mm)
Weight51.8 lbs (23.5 kg)
Package width17.5" (445 mm)
Package depth19.7" (500.1 mm)
Package height11" (279.9 mm)
Package weight51.8 lbs (23.5 kg)
Technical details
Products per master (outer) case1 pc(s)
Master (outer) case width17.5" (445 mm)
Master (outer) case gross weight51.1 lbs (23.2 kg)
Master (outer) case length19.7" (500.1 mm)
Master (outer) case height11" (279.9 mm)
Logistics data
Country of originTaiwan
Products per master (outer) case1 pc(s)
Master (outer) case width17.5" (445 mm)
Master (outer) case gross weight51.1 lbs (23.2 kg)
Master (outer) case length19.7" (500.1 mm)
Master (outer) case height11" (279.9 mm)
