Tripp Lite N286-01GLX-SLX network transceiver module Fiber optic 10000 Mbit/s SFP+ 1310 nm
- Brand: Tripp Lite
- Category:
- SKU: N286-01GLX-SLX
- EAN: 0037332197436
HP J4859C Compatible SFP Transceiver, 1000Base-LX, DDM, Singlemode LC, 1310 nm, 10 km
Offer details
Trade Prices
| Distributor | Product | SKU | Stock | Updated | Price |
|---|---|---|---|---|---|
|
SFP NETWORK TRANSCEIVER, DDM,SINGLE-MODE, COMPATIBLE1000BASE-LX LC |
931785 | |||
|
HP J4859C Compatible SFP Trans |
POW-N28601GLXSLX | |||
|
Tripp Lite Series HP J4859C Compatible SFP Transceiver, 1000Base-LX, DDM, Singlemode LC, 1310 nm, 10 km |
4778064 |
Related Products
- InfiniBand & Fibre Optic Cables
- Network Transceiver Modules
- Network Switches
- Network Media Converters
-
Category: InfiniBand & Fibre Optic Cables -
Category: InfiniBand & Fibre Optic Cables
-
Category: InfiniBand & Fibre Optic Cables
-
Category: InfiniBand & Fibre Optic Cables
-
Category: InfiniBand & Fibre Optic Cables -
Category: InfiniBand & Fibre Optic Cables
-
Category: Network Transceiver Modules -
Category: Network Transceiver Modules -
Category: Network Transceiver Modules -
Category: Network Transceiver Modules -
Category: Network Transceiver Modules -
Category: Network Transceiver Modules -
Category: Network Transceiver Modules -
Category: Network Transceiver Modules -
Category: Network Transceiver Modules
-
Category: Network Switches -
Category: Network Switches
-
Category: Network Media Converters -
Category: Network Media Converters -
Category: Network Media Converters
Description
The N286-01GLX-SLX HP J4859C Compatible 1000Base-LX LC SFP Transceiver with a duplex LC female connector functions just like the HP J4859C transceiver module and is designed to operate with HP networking equipment. It also meets or exceeds the J4859C’s original specifications and complies with MSA (Multi-Source Agreement) standards.
This 1000Base-LX transceiver is fully hot-pluggable, so you can install it without shutting down the network or rebooting your device. It supports data transfer rates up to 1 Gbps with 1310 nm wavelength signaling. It transmits across six miles (10 kilometers) of 9/125 SMF cabling.
The N286-01GLX-SLX also supports DDM, so you can monitor optical output power, optical input power, temperature, laser bias current and transceiver supply voltage. It is electrical interface-compliant with SFF-8431 specification.
This 1000Base-LX transceiver is fully hot-pluggable, so you can install it without shutting down the network or rebooting your device. It supports data transfer rates up to 1 Gbps with 1310 nm wavelength signaling. It transmits across six miles (10 kilometers) of 9/125 SMF cabling.
The N286-01GLX-SLX also supports DDM, so you can monitor optical output power, optical input power, temperature, laser bias current and transceiver supply voltage. It is electrical interface-compliant with SFF-8431 specification.
Specifications
| Performance | |
|---|---|
| SFP transceiver type | Fiber optic |
| Interface type | SFP+ |
| Maximum data transfer rate | 10000 Mbit/s |
| Fiber optic connector | LC |
| Maximum transfer distance | 393700.8" (10000 m) |
| Wavelength | 1310 nm |
| Fiber cable diameters supported (core/cladding) | 9/125 µm |
| Cabling technology | 1000Base |
| Single-mode fiber (SMF) supported | Yes |
| Country of origin | China |
| Easy to install | Yes |
| Product colour | Metallic |
| Harmonized System (HS) code | 8517.62.0090 |
| Features | |
| Easy to install | Yes |
| Product colour | Metallic |
| Country of origin | China |
| Certificates | |
| Compliance certificates | RoHS |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 10 - 85% |
| Network | |
| SFP transceiver type | Fiber optic |
| Interface type | SFP+ |
| Maximum data transfer rate | 10000 Mbit/s |
| Fiber optic connector | LC |
| Cabling technology | 1000Base |
| Weight & dimensions | |
| Width | 0.52" (13.2 mm) |
| Depth | 2.24" (56.9 mm) |
| Height | 0.331" (8.4 mm) |
| Weight | 0.705 oz (20 g) |
| Package depth | 1.77" (45 mm) |
| Package width | 4.49" (114 mm) |
| Package height | 0.85" (21.6 mm) |
| Package weight | 1.06 oz (30 g) |
| Packaging content | |
| Quantity per pack | 1 pc(s) |
| Packaging data | |
| Package depth | 1.77" (45 mm) |
| Package width | 4.49" (114 mm) |
| Package height | 0.85" (21.6 mm) |
| Package weight | 1.06 oz (30 g) |
| Technical details | |
| Master (outer) case GTIN (EAN/UPC) | 10037332197433 |
| Compliance certificates | RoHS |
| Logistics data | |
| Quantity per pack | 1 pc(s) |
| Country of origin | China |
| Master (outer) case width | 9.06" (230.1 mm) |
| Master (outer) case length | 5.12" (130 mm) |
| Master (outer) case height | 2.95" (74.9 mm) |
| Master (outer) case gross weight | 15.2 oz (430 g) |
| Products per master (outer) case | 10 pc(s) |
| Harmonized System (HS) code | 8517.62.0090 |
| Master (outer) case GTIN (EAN/UPC) | 10037332197433 |
