Tripp Lite N286-10GLR-SLC network transceiver module Fiber optic 10000 Mbit/s SFP+ 1310 nm
- Brand: Tripp Lite
- Category:
- SKU: N286-10GLR-SLC
- EAN: 0037332197429
Cisco-Compatible SFP-10G-LR SFP+ Transceiver, 10GBase-LR, DDM, Singlemode LC , 1310 nm, 10 km
Offer details
Description
The N286-10GLR-SLC Cisco SFP-10G-LR Compatible 10GBase-LR LC SFP+ Transceiver with a duplex LC female connector functions just like the Cisco® SFP-10G-LR transceiver module and is designed to operate with Cisco networking equipment. It also meets or exceeds the SFP-10G-LR’s original specifications and complies with MSA standards.
This 10GBase-LR transceiver is fully hot-pluggable, so you can install it without shutting down the network or rebooting your device. It supports data transfer rates up to 10 Gbps with 1310 nm wavelength signaling. It transmits across six miles (10 kilometers) of 9/125 SMF cabling. Its metallic housing allows low EMI.
The N286-10GLR-SLC also supports DDM, so you can monitor optical output power, optical input power, temperature, laser bias current and transceiver supply voltage. It is electrical interface-compliant with SFF-8431 specification, and supports up to 11.1 Gbps bi-directional communication.
This 10GBase-LR transceiver is fully hot-pluggable, so you can install it without shutting down the network or rebooting your device. It supports data transfer rates up to 10 Gbps with 1310 nm wavelength signaling. It transmits across six miles (10 kilometers) of 9/125 SMF cabling. Its metallic housing allows low EMI.
The N286-10GLR-SLC also supports DDM, so you can monitor optical output power, optical input power, temperature, laser bias current and transceiver supply voltage. It is electrical interface-compliant with SFF-8431 specification, and supports up to 11.1 Gbps bi-directional communication.
Specifications
Network | |
---|---|
SFP transceiver type | Fiber optic |
Interface type | SFP+ |
Maximum data transfer rate | 10000 Mbit/s |
Fiber optic connector | LC |
Cabling technology | 10GBase |
Performance | |
Country of origin | China |
Easy to install | Yes |
Product colour | Metallic |
SFP transceiver type | Fiber optic |
Interface type | SFP+ |
Maximum data transfer rate | 10000 Mbit/s |
Fiber optic connector | LC |
Maximum transfer distance | 393700.8" (10000 m) |
Wavelength | 1310 nm |
Fiber cable diameters supported (core/cladding) | 9/125 µm |
Cabling technology | 10GBase |
Single-mode fiber (SMF) supported | Yes |
SFP transceiver standard | LR |
Harmonized System (HS) code | 85369010 |
Features | |
Country of origin | China |
Easy to install | Yes |
Product colour | Metallic |
Operational conditions | |
Operating temperature (T-T) | 0 - 70 °C |
Storage temperature (T-T) | -40 - 85 °C |
Operating relative humidity (H-H) | 10 - 85% |
Weight & dimensions | |
Width | 0.52" (13.2 mm) |
Depth | 2.24" (56.9 mm) |
Height | 0.331" (8.4 mm) |
Weight | 0.705 oz (20 g) |
Package depth | 1.77" (45 mm) |
Package width | 4.49" (114 mm) |
Package height | 0.85" (21.6 mm) |
Package weight | 1.06 oz (30 g) |
Packaging data | |
Package depth | 1.77" (45 mm) |
Package width | 4.49" (114 mm) |
Package height | 0.85" (21.6 mm) |
Package weight | 1.06 oz (30 g) |
Manual | Yes |
Technical details | |
Master (outer) case GTIN (EAN/UPC) | 10037332197426 |
Compliance certificates | RoHS |
Packaging content | |
Manual | Yes |
Logistics data | |
Master (outer) case width | 9.06" (230.1 mm) |
Master (outer) case length | 5.12" (130 mm) |
Master (outer) case height | 2.95" (74.9 mm) |
Master (outer) case gross weight | 15.2 oz (430 g) |
Products per master (outer) case | 10 pc(s) |
Harmonized System (HS) code | 85369010 |
Quantity per pack | 1 pc(s) |
