Tripp Lite SMX750SLT uninterruptible power supply (UPS) 0.75 kVA 500 W 6 AC outlet(s)

Tripp Lite SMX750SLT uninterruptible power supply (UPS) 0.75 kVA 500 W 6 AC outlet(s)

SmartPro 230V 750VA 500W Line-Interactive Sine Wave UPS, Tower, Network Card Options, USB, DB9 Serial

Trade Prices

Distributor Product SKU Stock Updated Price
Anixter

750VA 500W UPS INTERNATIONALSMART TOWER AVR 230V C13 USB

 565448 Register free see stock

Description

Tripp Lite's SMX750SLT intelligent, line-interactive sine wave UPS system protects servers, networking accessories and telecommunications equipment from blackouts, voltage fluctuations and transient surges. Large internal batteries offer 15 minutes half load runtime and 5 minutes full load runtime. 750VA/500 watt power handling capability and full-time sine wave output offers guaranteed compatibility with networking, telecom and other sensitive electronic applications. Includes 6 protected C13 output receptacles total. Network management interfaces support communications via USB, RS-232 and slot for network management card options. HID-compliant USB interface enables integration with built-in power management and auto shutdown features of Windows and Mac OS X. Network communications ports enable detailed monitoring of equipment load levels, self-test data and utility power conditions. PowerAlert UPS monitoring software is available via free download. Single line Tel/DSL and network Ethernet line surge suppression. Built-in audible alarm and 9 LEDs offer status notification for line power, battery power, battery charge level, load level, plus AVR boost and trim operational status information. Network grade AC surge suppression protects equipment from damage and performance problems resulting from transient surges. Attractive, all-black tower housing.

SMX750SLT line-interactive UPS offers battery derived sine wave AC output during power outages, voltage regulation during brownouts and overvoltages, plus network-grade AC surge suppression
750VA/500 watt power handling capability with full-time sine wave output offers guaranteed compatibility with networking, telecom and other sensitive electronic devices
Large internal batteries offer runtimes of 15 minutes at half load (325VA/250 watts) and 5 minutes at full load (750VA/500 watts)
Intelligent battery management system extends battery life
Automatic Voltage Regulation (AVR) circuits maintain user-selectable 220, 230 or 240V nominal output over an input voltage range of 151 to 290
Includes 6 C13 output receptacles
IEC320-C14 input connection accepts a variety of detachable cordsets
Compatible with Tripp Lite UPS management card options WEBCARDLX, RELAYIOCARD, SNMPWEBCARD
Optional WEBCARDLX (sold separately) with the latest version of PowerAlert Device Manager firmware (PADM20) provides enhanced remote management capabilities
PADM20 and PowerAlert Element Manager (PAEM) form a powerful tool for expanding maintenance functions in large installations, including firmware update checks and backup and restoration of device configurations
USB & Serial ports enable data-saving unattended shutdown when used with Tripp Lite's PowerAlert software, available via FREE download fromTripp Lite website.
HID-compliant USB interface enables integration with built-in power management and auto shutdown features of Windows and Mac OS X
Supports Tripp Lite's WatchDog software application (requires optional WATCHDOGSW)
9 LEDs offer continuous status information of UPS operating parameters and site power quality
Hot-swappable batteries allow on-site battery replacement without powering off connected equipment
Single line Tel/DSL and network Ethernet line surge suppression

Specifications

Power
Output power500 W
Input operation voltage (min)220 V
Input operation voltage (max)240 V
Output operation voltage (min)220 V
Output operation voltage (max)240 V
Surge energy rating480 J
Output power capacity0.75 kVA
Performance
Response time4 ms
LED indicatorsYes
Audible alarm(s)Yes
Features
Country of originChina
Response time4 ms
Output power500 W
Input operation voltage (min)220 V
Input operation voltage (max)240 V
Output operation voltage (min)220 V
Output operation voltage (max)240 V
Surge energy rating480 J
Audible alarm(s)Yes
Output power capacity0.75 kVA
Ports & interfaces
AC outlets quantity6 AC outlet(s)
AC outlet typesC13 coupler
Power plugC14 coupler
USB 2.0 ports quantity1
Serial ports quantity1
Battery
Battery recharge time4 h
Typical backup time at half load15 min
Typical backup time at full load5 min
Hot-swap batteryYes
Design
Country of originChina
Form factorTower
LED indicatorsYes
Product colourBlack
CertificationUL1778, CSA, CE, GOST, SASO, FCC Part 68
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 50 °C
Operating relative humidity (H-H)0 - 95%
Technical details
Compliance certificatesRoHS
Certificates
CertificationUL1778, CSA, CE, GOST, SASO, FCC Part 68
Compliance certificatesRoHS
Weight & dimensions
Package width9.75" (247.6 mm)
Package depth18.5" (469.9 mm)
Package height14" (355.6 mm)
Weight34.2 lbs (15.5 kg)
Width6.75" (171.4 mm)
Package weight38.6 lbs (17.5 kg)
Height10.3" (260.4 mm)
Depth13.3" (336.6 mm)
Packaging data
Package width9.75" (247.6 mm)
Package depth18.5" (469.9 mm)
Package height14" (355.6 mm)
Package weight38.6 lbs (17.5 kg)
Logistics data
Country of originChina
Products per master (outer) case1 pc(s)
Master (outer) case width9.75" (247.6 mm)
Master (outer) case length18.5" (469.9 mm)
Master (outer) case height14" (355.6 mm)
Master (outer) case gross weight38.6 lbs (17.5 kg)
