Tripp Lite SmartPro Medical-Grade UPS, Line Interactive, Lithium Battery, 6 Outlets - 230V, 1kVA, 750W, Full Isolation

Tripp Lite SmartPro Medical-Grade UPS, Line Interactive, Lithium Battery, 6 Outlets - 230V, 1kVA, 750W, Full Isolation

Tripp Lite SmartPro Medical-Grade UPS, Line Interactive, Lithium Battery, 6 Outlets - 230V, 1kVA, 750W, Full Isolation, Line-Interactive, 1 kVA, 750 W, 230 V, 230 V, 220 V

Trade Prices

Distributor Product SKU Stock Updated Price
Anixter

SMARTPRO MEDICAL-GRADE UPS,LINE INTERACTIVE, LITHIUMBATTERY, 6 OUTLETS

 9810638 Register free see stock
Ingram Micro

1000VA 750W 230V LITHIUM ION

 5JW792
ScanSource

1000VA 750W 230V Lithium Ion U

 POW-SMX1200XLHGL
TD Synnex

Tripp Lite Series SmartPro Medical-Grade UPS, Line Interactive, Lithium Battery, 6 Outlets - 230V, 1kVA, 750W, Full Isolation

 5392194

Related Products

Description

Tripp Lite SmartPro Medical-Grade UPS, Line Interactive, Lithium Battery, 6 Outlets - 230V, 1kVA, 750W, Full Isolation. UPS topology: Line-Interactive, Output power capacity: 1 kVA, Output power: 750 W. AC outlet types: C13 coupler, Power plug: C14 coupler, AC outlets quantity: 6 AC outlet(s). Battery voltage: 36 V, Typical backup time at full load: 11 min, Typical backup time at half load: 27.5 min. Form factor: Tower, Product color: Gray, Housing material: Polyvinyl chloride (PVC). Width: 7.5" (190.5 mm), Depth: 9.05" (229.9 mm), Height: 12.7" (322.6 mm)

Specifications

Power
Output frequency regulation50 - 60 Hz
Output power750 W
Input operation voltage (min)230 V
Input operation voltage (max)230 V
Output operation voltage (min)220 V
Output operation voltage (max)240 V
Surge energy rating340 J
Output power capacity1 kVA
Performance
UPS topologyLine-Interactive
Number of input phases1
LED indicatorsYes
Features
Country of originChina
UPS topologyLine-Interactive
Output frequency regulation50 - 60 Hz
Number of input phases1
Output power750 W
Input operation voltage (min)230 V
Input operation voltage (max)230 V
Output operation voltage (min)220 V
Output operation voltage (max)240 V
Surge energy rating340 J
Output power capacity1 kVA
Ports & interfaces
USB portYes
Serial interfaceYes
AC outlets quantity6 AC outlet(s)
AC outlet typesC13 coupler
Power plugC14 coupler
Battery
Battery voltage36 V
Typical backup time at half load27.5 min
Typical backup time at full load11 min
Design
Country of originChina
Form factorTower
LED indicatorsYes
Product colourGray
Housing materialPolyvinyl chloride (PVC)
Operational conditions
Operating temperature (T-T)32 - 104 °C
Storage temperature (T-T)5 - 122 °C
Operating relative humidity (H-H)0 - 95%
Technical details
Harmonized System (HS) code85078000
Weight & dimensions
Package width12.2" (309.9 mm)
Package depth13.4" (339.9 mm)
Package height18.5" (469.9 mm)
Weight35.1 lbs (15.9 kg)
Width7.5" (190.5 mm)
Package weight38.4 lbs (17.4 kg)
Height12.7" (322.6 mm)
Depth9.05" (229.9 mm)
Packaging data
Package width12.2" (309.9 mm)
Package depth13.4" (339.9 mm)
Package height18.5" (469.9 mm)
Package weight38.4 lbs (17.4 kg)
Logistics data
Country of originChina
Products per master (outer) case1 pc(s)
Master (outer) case width12.2" (309.9 mm)
Master (outer) case length13.4" (339.9 mm)
Master (outer) case height18.5" (469.9 mm)
Master (outer) case gross weight38.4 lbs (17.4 kg)
Harmonized System (HS) code85078000
