Tripp Lite OMNIVSX650 uninterruptible power supply (UPS) Line-Interactive 0.65 kVA 360 W 2 AC outlet(s)

Tripp Lite OMNIVSX650 uninterruptible power supply (UPS) Line-Interactive 0.65 kVA 360 W 2 AC outlet(s)

Line Interactive UPS, C13 Outlets (4) - 230V, 650VA, 360W, Ultra-Compact Design

Trade Prices

Distributor Product SKU Stock Updated Price
Anixter

LINE INTERACTIVE UPS, C13OUTLETS (4), 230V, 650VA,360W, COMPACT

 9808205 Register free see stock

Related Products

Description

Protect Your Electronics with Voltage Regulation, Surge Suppression and Battery Backup
Line-interactive UPS offers voltage regulation, surge suppression and battery backup support. It regulates brownouts as low as 170V and overvoltages as high as 280V back to usable levels without using battery power. All four IEC320 C13 UPS outlets offer battery backup, automatic voltage regulation and AC surge suppression. Three front-panel LEDs and audible alarm combine to indicate off/on power status, line power availability, battery mode operation, low battery, overload, battery replacement and fault mode.
Operate Your Connected Equipment During Short-Term Outages
This UPS supports an entry-level PC consuming 60W continuous up to 42 minutes during power failure condition and a 50% load of 180W for 6 minutes. It also enables users to operate connected equipment during short-duration outages without interruption and shut down without data loss during longer outages. All the UPS C13 outlets receive battery backup.

Specifications

Power
Output voltage regulation230V (+10% / -26%)
Output power360 W
Output operation voltage (min)220 V
Output operation voltage (max)240 V
Surge energy rating312 J
Maximum current2 A
Efficiency95%
Output power capacity0.65 kVA
Input frequency50/60 Hz
Performance
UPS topologyLine-Interactive
WaveformSine
Automatic Voltage Regulation (AVR)Yes
Number of input phases1
Response time6 ms
LED indicatorsStatus
EMI/RFI noise filteringYes
Power protection featuresOver voltage, Under voltage
Audible alarm(s)Yes
Features
Country of originChina
UPS topologyLine-Interactive
WaveformSine
Output voltage regulation230V (+10% / -26%)
Automatic Voltage Regulation (AVR)Yes
Number of input phases1
Response time6 ms
Output power360 W
Output operation voltage (min)220 V
Output operation voltage (max)240 V
Surge energy rating312 J
Maximum current2 A
Efficiency95%
EMI/RFI noise filteringYes
Power protection featuresOver voltage, Under voltage
Audible alarm(s)Yes
Output power capacity0.65 kVA
Input frequency50/60 Hz
Ports & interfaces
AC outlets quantity2 AC outlet(s)
AC outlet typesC13 coupler
Power plugC14 coupler
Battery
Battery voltage12 V
Typical backup time at half load7 min
Battery recharge time(90%)8 h
Design
Country of originChina
Form factorTower
LED indicatorsStatus
Product colourBlack
CertificationCE
Housing materialPolyvinyl chloride (PVC)
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 45 °C
Operating relative humidity (H-H)0 - 90%
Operating altitude0 - 78740.2" (0 - 2000 m)
Certificates
CertificationCE
Packaging content
ManualYes
Cables includedOutput power cable
Weight & dimensions
Package width5.6" (142.2 mm)
Package depth13.6" (345.4 mm)
Package height8.7" (221 mm)
Weight10.6 lbs (4.81 kg)
Width4" (101.6 mm)
Package weight11.2 lbs (5.08 kg)
Height5.6" (142.2 mm)
Depth11.8" (299.7 mm)
Packaging data
ManualYes
Cables includedOutput power cable
Package width5.6" (142.2 mm)
Package depth13.6" (345.4 mm)
Package height8.7" (221 mm)
Package weight11.2 lbs (5.08 kg)
Logistics data
Country of originChina
Products per master (outer) case4 pc(s)
Master (outer) case width14.2" (360.7 mm)
Master (outer) case length23.6" (599.4 mm)
Master (outer) case height9.8" (248.9 mm)
Master (outer) case gross weight46.3 lbs (21 kg)
Master (outer) case GTIN (EAN/UPC)10037332217940
