Tripp Lite ECO850LCD uninterruptible power supply (UPS) Standby (Offline) 0.85 kVA 425 W 12 AC outlet(s)

Tripp Lite ECO850LCD uninterruptible power supply (UPS) Standby (Offline) 0.85 kVA 425 W 12 AC outlet(s)

Tripp Lite ECO850LCD, Standby (Offline), 0.85 kVA, 425 W, Pure sine, 110 V, 120 V

Trade Prices

Distributor Product SKU Stock Updated Price
Anixter

850VA ENERGY-SAVING 120VSTANDBY UPS WITH ENHANCED LCDAND USB,12 OUT

 444053 Register free see stock
Arlington Industries

12-OUTLET LCD ENERGY-SAVING UPS SURGE

 TRPECO850LCD
BlueStar

EATON, 850VA 425W UPS ECO GREEN BATTERY BACK UP LCD 120V USB RJ11 PC

 ECO850LCD

Related Products

Description

Tripp Lite ECO850LCD. UPS topology: Standby (Offline), Output power capacity: 0.85 kVA, Output power: 425 W. AC outlet types: NEMA 5–15R, Power plug: NEMA 5-15P, AC outlets quantity: 12 AC outlet(s). Typical backup time at full load: 2.3 min, Typical backup time at half load: 9 min. Form factor: Compact, Product color: Black, Cable length: 70.9" (1.8 m). Compliance certificates: RoHS

Specifications

Power
Output frequency50/60 Hz
Output power425 W
Input operation voltage (min)110 V
Input operation voltage (max)120 V
Output operation voltage (min)120 V
Output operation voltage (max)120 V
Surge energy rating316 J
Maximum current15 A
Output power capacity0.85 kVA
ECO modeYes
Input frequency60 Hz
Ports & interfaces
Cable length70.9" (1.8 m)
USB portYes
AC outlets quantity12 AC outlet(s)
AC outlet typesNEMA 5–15R
Power plugNEMA 5-15P
USB 2.0 ports quantity1
Modem (RJ-11) ports1
Ethernet LAN (RJ-45) ports2
Performance
UPS topologyStandby (Offline)
WaveformPure sine
LED indicatorsYes
EMI/RFI noise filteringYes
Surge protectionYes
Surge protection featuresDigital Subscriber Line (DSL), Network, Telephone
Features
Output frequency50/60 Hz
Country of originVietnam
UPS topologyStandby (Offline)
WaveformPure sine
Output power425 W
Input operation voltage (min)110 V
Input operation voltage (max)120 V
Output operation voltage (min)120 V
Output operation voltage (max)120 V
Surge energy rating316 J
Maximum current15 A
EMI/RFI noise filteringYes
Surge protectionYes
Surge protection featuresDigital Subscriber Line (DSL), Network, Telephone
Output power capacity0.85 kVA
ECO modeYes
Input frequency60 Hz
Battery
Typical backup time at half load9 min
Typical backup time at full load2.3 min
Cold startYes
Design
Country of originVietnam
Form factorCompact
LED indicatorsYes
Product colourBlack
Cable length70.9" (1.8 m)
Display typeLCD
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 45 °C
Operating relative humidity (H-H)0 - 90%
Operating altitude0 - 120000" (0 - 3048 m)
Technical details
Output frequency50/60 Hz
Sustainability certificatesENERGY STAR
Compliance certificatesRoHS
Certificates
Compliance certificatesRoHS
Packaging content
ManualYes
Cables includedUSB cable
Sustainability
Sustainability certificatesENERGY STAR
Weight & dimensions
Package width5.98" (151.9 mm)
Package depth14.9" (379 mm)
Package height7.83" (198.9 mm)
Weight6.81 lbs (3.09 kg)
Width5.12" (130 mm)
Package weight7.47 lbs (3.39 kg)
Height3.35" (85.1 mm)
Depth12.2" (309.9 mm)
Packaging data
ManualYes
Cables includedUSB cable
Package width5.98" (151.9 mm)
Package depth14.9" (379 mm)
Package height7.83" (198.9 mm)
Package weight7.47 lbs (3.39 kg)
Logistics data
Country of originVietnam
Products per master (outer) case6 pc(s)
Master (outer) case width15.6" (395 mm)
Master (outer) case length18.7" (475 mm)
Master (outer) case height16.9" (428 mm)
Master (outer) case gross weight47.2 lbs (21.4 kg)
Master (outer) case GTIN (EAN/UPC)10037332211139
