Tripp Lite SR25UBEXP rack cabinet 25U Freestanding rack Black

Tripp Lite SR25UBEXP rack cabinet 25U Freestanding rack Black

  • Brand: Tripp Lite
  • Category:
  • SKU: SR25UBEXP
  • EAN: 0037332178923 0086000219444 03 ...0219444 0373321789238more
25U SmartRack Standard-Depth Half-Height Rack Enclosure, Expansion Version, No Side Panels

Trade Prices

Distributor Product SKU Stock Updated Price
Anixter 25U RACK ENCLOSURE SERVERCABINET DOORS NO SIDES 565455 Register free see stock
Ingram Micro 25U RACK ENCLOSURE CABINET QZ8034
TD Synnex 25U RACK ENCLOSURE W/ DOORS & NO SIDES 3486950

Related Products

Description

The SR25UBEXP is an expansion model used when several cabinets are bayed together. It has doors and a roof but no side panels. Its integrated baying tabs make it easy to combine multiple enclosures in rows fro data center application. The SR25UBEXP is also compatible with hot aisle/cold aisle configurations.

The SR25UBEXP houses 3000 lbs (1360.8 kgs) of standard 19-inch rack equipment in 25U. Offers vendor-neutral square hole/cage nut mounting for guaranteed compatibility with all EIA-310-E compliant 19" equipment. Its front and rear pairs of vertical rails are adjustable in quarter-inch increments from 4 to 37 inches. Adjustment is quick and an easy-view depth index ensures consistent rail placement without requiring time-consuming measurements. Each rack space within the enclosure is numbered for ready reference. Two of these adjustable vertical mounting rails support toolless button-mount 0U installation of up to four compatible PDUs and cable managers. This feature makes it easier to route cabling to rack equipment and reduces cord clutter.

The top panel of the SR25UBEXP is vented to help remove warm air from the enclosure and draw in cool air by convection. The top panel includes ports for cable routing, and can be quickly removed without tools. To facilitate cable access, the SR25UBEXP is open-bottom.

All components of the SR25UBEXP are grounded to the enclosure frame. Front and rear threaded grounding points are provided for connection to the facility earth ground. The removable front and rear doors feature quick-release ground wires.

To simplify deployment, the SR25UBEXP comes with preinstalled casters that enable it to be easily maneuvered into the desired location, where it can be secured by adjusting the preinstalled levelers. Note: the casters are intended for minor position adjustments and are not designed for moving the enclosure over long distances.

Specifications

Weight & dimensions
Package depth45" (1143 mm)
Package width26" (660.4 mm)
Package height55" (1397 mm)
Package weight200 lbs (90.7 kg)
Width23.6" (600.2 mm)
Depth43" (1092.2 mm)
Height49" (1244.6 mm)
Weight162.9 lbs (73.9 kg)
Maximum weight capacity3000.5 lbs (1361 kg)
Features
Rack capacity25U
TypeFreestanding rack
Maximum weight capacity3000.5 lbs (1361 kg)
Product colourBlack
CertificationUL60950; RoHS; CE
Packaging data
Package depth45" (1143 mm)
Package width26" (660.4 mm)
Package height55" (1397 mm)
Package weight200 lbs (90.7 kg)
Technical details
Package width26" (660.4 mm)
Package height55" (1397 mm)
TypeFreestanding rack
Harmonized System (HS) code8517.79.0000
Rack capacity25U
Colour
Product colourBlack
Certificates
CertificationUL60950; RoHS; CE
Logistics data
Master (outer) case width26" (660.4 mm)
Master (outer) case length45" (1143 mm)
Master (outer) case height55" (1397 mm)
Master (outer) case gross weight200 lbs (90.7 kg)
Products per master (outer) case1 pc(s)
Country of originChina
Harmonized System (HS) code8517.79.0000
