Tripp Lite SR2POST rack cabinet 45U Freestanding rack Black

Tripp Lite SR2POST rack cabinet 45U Freestanding rack Black

  • Brand: Tripp Lite
  • Category:
  • SKU: SR2POST
  • EAN: 0037332127563 0729198239534 07 ...8239534 0754082020622 0778888139166 0373321275632 7426701576560 0611101307303 0132017655260more
45U SmartRack 2-Post Open Frame Rack, 800 lbs (362.9 kgs) Capacity - Organize and Secure Network Rack Equipment

Trade Prices

Distributor Product SKU Stock Updated Price
Anixter

RACK 2-POST OPEN FRAME84 X 20.3 X 4.7545U BLACK

363095 Register free see stock
Arlington Industries

SMARTRACK 45U 2-POST OPEN FRAME RACK

TRPSR2POST
BlueStar

TRIPP LITE, 45U SMARTRACK 2-POST OPEN FRAME RACK, 800-LB. CAPACITY - ORGANIZE AND SECURE NETWORK RACK EQUIPMENT

SR2POST
D&H

45U 2 Post SmartRack Black

SR2POST
Flytec Computers

SR2POSTTripp Lite SmartRack 2-Post - Open frame rack - black - 45U

SR2POST
ScanSource

Tripp Lite 45U Smart Rack

POW-SR2POST
TD Synnex

Tripp Lite Series 45U SmartRack 2-Post Open Frame Rack, 800 lbs (362.9 kgs) Capacity - Organize and Secure Network Rack Equipment

1121450

Related Products

Description

SR2POST 2-Post SmartRack Open Frame Rack is an economical way to accommodate 45U of rack space for 19-inch rack-mount applications where space is at a premium. Its heavy-duty, aluminum construction can safely support 800 pounds (362.9 kilograms) of rack-mount equipment. The black, textured power coat finish makes it resistant to scratching while giving it a classic, attractive appearance. The SR2POST is easy to install due to a self-squaring design combined with 12-24 threaded and numbered mounting holes, and bolt down provisions. Only standard hand tools are required for installation (9/16" wrench and 9/16" socket/ratchet). Multiple units can be bolted together side by side for easy expansion or customization when required. The SR2POST 2-Post SmartRack Open Frame Rack has been approved by EIA-310-D, IEC 60297-3-100, and RoHS.

Specifications

Weight & dimensions
Package depth88" (2235.2 mm)
Package width6.3" (160 mm)
Package height4.9" (124.5 mm)
Package weight33.1 lbs (15 kg)
Width20.3" (515.6 mm)
Depth13.5" (342.9 mm)
Height84" (2133.9 mm)
Weight29.1 lbs (13.2 kg)
Maximum weight capacity800.1 lbs (362.9 kg)
Features
Rack capacity45U
TypeFreestanding rack
Maximum weight capacity800.1 lbs (362.9 kg)
Product colourBlack
CertificationEIA-310-D, IEC 60297-3-100, RoHS
Packaging data
Package depth88" (2235.2 mm)
Package width6.3" (160 mm)
Package height4.9" (124.5 mm)
Package weight33.1 lbs (15 kg)
Technical details
Package width6.3" (160 mm)
Package height4.9" (124.5 mm)
TypeFreestanding rack
Master (outer) case GTIN (EAN/UPC)10037332127560
Harmonized System (HS) code8517.79.0000
Rack capacity45U
Colour
Product colourBlack
Certificates
CertificationEIA-310-D, IEC 60297-3-100, RoHS
Logistics data
Master (outer) case width19.6" (497.8 mm)
Master (outer) case length89" (2260.6 mm)
Master (outer) case height18.9" (480.1 mm)
Master (outer) case gross weight233.9 lbs (106.1 kg)
Products per master (outer) case9 pc(s)
Country of originChina
Harmonized System (HS) code8517.79.0000
