Tripp Lite OMNIVSINT800 uninterruptible power supply (UPS) Line-Interactive 0.8 kVA 475 W 4 AC outlet(s)

Tripp Lite OMNIVSINT800 uninterruptible power supply (UPS) Line-Interactive 0.8 kVA 475 W 4 AC outlet(s)

OmniVS 230V 800VA 475W Line-Interactive UPS, USB port, C13 Outlets

Trade Prices

Distributor Product SKU Stock Updated Price
Anixter 800VA 475W UPS INTERNATIONALBATTERY BACK UP TOWER AVR 565290 Register free see stock
Ingram Micro UPS INT 800VA 475W TOWER 230V F35021
TD Synnex 800VA 475W UPS INTERNATIONAL BATTERY BACK UP TOWER AVR 230V C13 1049547

Related Products

Description

OMNIVSINT800 line-interactive UPS system offers voltage regulation, surge suppression and long-lasting battery support for personal computers, internetworking equipment and other sensitive electronics. Internal UPS circuits support entry-level PC systems for up to 40 minutes during power failures so that connected equipment can be shut down without data loss. Automatic Voltage Regulation (AVR) circuits regulate brownouts as low as 159 volts back to usable levels without using battery power. Offers complete desktop power protection in an attractive black tower configuration. Includes four outlets with battery support and AC surge suppression. USB port enables optional unattended system shutdown without data loss in the case of extended power failure, USB cable included. PowerAlert® software available via free download. Built-in single-line RJ phone suppression jacks protect modem, fax machine, cordless phone or other peripheral with a standard dialup/DSL phone connection. Built-in audible alarm and four front-panel LEDs indicate line power status, battery power status, battery low/replace status and UPS overload. 800VA power handling ability supports entry-level PCs, network workstations, point-of-sale equipment, small business phone systems, audio/video equipment and home theater systems. Supports battery replacement via built-in access panel.

Specifications

Power
Output voltage regulation5%
Output power475 W
Input operation voltage (min)159 V
Input operation voltage (max)230 V
Output operation voltage (min)220 V
Output operation voltage (max)240 V
Surge energy rating340 J
Maximum current2.4 A
Efficiency97%
Output power capacity0.8 kVA
Input frequency50/60 Hz
Ports & interfaces
Cable length7.87" (0.2 m)
AC outlets quantity4 AC outlet(s)
AC outlet typesC13 coupler
Power plugC14 coupler
USB 2.0 ports quantity1
Performance
UPS topologyLine-Interactive
WaveformSine
Automatic Voltage Regulation (AVR)Yes
Number of input phases1
LED indicatorsYes
EMI/RFI noise filteringYes
Surge protectionYes
Surge protection featuresTelephone
Power protection featuresUnder voltage
Audible alarm(s)Yes
Features
Country of originChina
UPS topologyLine-Interactive
WaveformSine
Output voltage regulation5%
Automatic Voltage Regulation (AVR)Yes
Number of input phases1
Output power475 W
Input operation voltage (min)159 V
Input operation voltage (max)230 V
Output operation voltage (min)220 V
Output operation voltage (max)240 V
Surge energy rating340 J
Maximum current2.4 A
Efficiency97%
EMI/RFI noise filteringYes
Surge protectionYes
Surge protection featuresTelephone
Power protection featuresUnder voltage
Audible alarm(s)Yes
Output power capacity0.8 kVA
Input frequency50/60 Hz
Battery
Battery recharge time4.5 h
Typical backup time at half load11.5 min
Typical backup time at full load3.5 min
Hot-swap batteryYes
Cold startYes
Design
Country of originChina
Rack capacity2U
Form factorTower
LED indicatorsYes
Product colourBlack
CertificationUL1778, CE, GOST, SASO, IRAM
Cable length7.87" (0.2 m)
Housing materialPolyvinyl chloride (PVC)
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 50 °C
Operating relative humidity (H-H)0 - 95%
Technical details
Sustainability certificatesRoHS
Harmonized System (HS) code85078000
Weight & dimensions
Package width7.5" (190.5 mm)
Package depth13.7" (348 mm)
Package height9.7" (246.4 mm)
Weight19.5 lbs (8.85 kg)
Width5.25" (133.4 mm)
Package weight21.9 lbs (9.94 kg)
Height10.7" (273 mm)
Depth7.5" (190.5 mm)
Packaging data
Package width7.5" (190.5 mm)
Package depth13.7" (348 mm)
Package height9.7" (246.4 mm)
Package weight21.9 lbs (9.94 kg)
Logistics data
Products per master (outer) case2 pc(s)
Master (outer) case width11" (279.4 mm)
Master (outer) case length16.6" (421.6 mm)
Master (outer) case height14.9" (378.5 mm)
Master (outer) case gross weight43.9 lbs (19.9 kg)
Master (outer) case GTIN (EAN/UPC)10037332120967
Harmonized System (HS) code85078000
Certificates
CertificationUL1778, CE, GOST, SASO, IRAM
