Tripp Lite SR45UBSD rack cabinet 45U Freestanding rack Black

Tripp Lite SR45UBSD rack cabinet 45U Freestanding rack Black

  • Brand: Tripp Lite
  • Category:
  • SKU: SR45UBSD
  • EAN: 0037332174895 0373321748952
45U SmartRack Shallow-Depth Rack Enclosure Cabinet with doors & side panels

Trade Prices

Distributor Product SKU Stock Updated Price
Anixter

45U RACK ENCLOSURE 32" DEPTHW/ DOORS & SIDES 3000LB

 565489 Register free see stock
D&H

45U Rack Enclosure 32" Depth

 SR45UBSD
Ingram Micro

45U RACK ENCLOSURE CABINET

 QZ8453
ScanSource

45U Rack Enclosure 32"" Depth w

 POW-SR45UBSD
TD Synnex

Tripp Lite Series 45U SmartRack Shallow-Depth Rack Enclosure Cabinet with doors & side panels

 3468608

Related Products

Description

The shallow depth of the SR45UBSD makes it an ideal cabinet for shallow-depth audio/video equipment, smaller equipment installs or areas with limited floor space. It houses 3,500 pounds (1588 kilograms) of standard 19-inch rack equipment in 45U. Its front and rear pairs of vertical rails have square mounting holes that are adjustable in quarter-inch increments from four to 27 inches. Adjustment is quick and an easy-view depth index ensures consistent rail placement without requiring time-consuming measurements. Each rack space within the enclosure is numbered for ready reference.

Two of the adjustable vertical mounting rails support tool-less button-mount 0U installation of up to four compatible PDUs and cable managers. This feature makes it easier to route cabling to rack equipment and reduces cord clutter.

With its locking, reversible, removable front and rear doors and locking, removable side panels, the SR45UBSD provides ultimate equipment safety. The side panels are half size for ease of removal and reinstallation. The split rear door design allows the enclosure to be placed closer to a wall. The SR45UBSD meets all requirements toward PCI DSS compliance.

The top panel of the SR45UBSD is vented to help remove warm air from the enclosure and draw in cool air by convection. The top panel includes ports for cable routing and can be quickly removed without tools. To facilitate cable access, the SR45UBSD is open-bottom.

All components of the SR45UBSD are grounded to the enclosure frame. Front and rear threaded grounding points are provided for connection to the facility earth ground. The removable front and rear doors feature quick-release ground wires.

To simplify deployment, the SR45UBSD comes with preinstalled casters that enable it to be easily maneuvered into the desired location, where it can be secured by adjusting the preinstalled levelers. Note: The casters are intended for minor position adjustments and are not designed for moving the enclosure over long distances.

Specifications

Weight & dimensions
Package depth34" (863.6 mm)
Package width26" (660.4 mm)
Package height90.5" (2298.7 mm)
Package weight282 lbs (127.9 kg)
Width23.6" (600.2 mm)
Depth32.5" (825 mm)
Height83.7" (2127.2 mm)
Weight231.9 lbs (105.2 kg)
Maximum weight capacity3000.1 lbs (1360.8 kg)
Features
Rack capacity45U
TypeFreestanding rack
Maximum weight capacity3000.1 lbs (1360.8 kg)
Product colourBlack
CertificationUL60950; RoHS, CE
Packaging data
Package depth34" (863.6 mm)
Package width26" (660.4 mm)
Package height90.5" (2298.7 mm)
Package weight282 lbs (127.9 kg)
Package dimensions (WxDxH)26 x 34.2 x 90.2" (660.4 x 869.9 x 2292.3 mm)
Technical details
Package width26" (660.4 mm)
Package height90.5" (2298.7 mm)
TypeFreestanding rack
Harmonized System (HS) code8517.79.0000
Rack capacity45U
Colour
Product colourBlack
Certificates
CertificationUL60950; RoHS, CE
Logistics data
Master (outer) case width26" (660.4 mm)
Master (outer) case length34" (863.6 mm)
Master (outer) case height90.5" (2298.7 mm)
Master (outer) case gross weight282 lbs (127.9 kg)
Products per master (outer) case1 pc(s)
Country of originChina
Harmonized System (HS) code8517.79.0000
Other features
Package dimensions (WxDxH)26 x 34.2 x 90.2" (660.4 x 869.9 x 2292.3 mm)
