Tripp Lite U342-SHG-001 laptop dock/port replicator Wired USB 3.2 Gen 1 (3.1 Gen 1) Type-A Black

Tripp Lite U342-SHG-001 laptop dock/port replicator Wired USB 3.2 Gen 1 (3.1 Gen 1) Type-A Black

USB 3.x (5Gbps) Mini Dock with HDMI and VGA Video, GbE

Trade Prices

Distributor Product SKU Stock Updated Price
Anixter USB 3.0 HDMI / VGA MINIDOCKING STATION WITH GIGABITETHERNET 642839 Register free see stock
D&H USB 3.0 Min Dock STN U342SHG001
Ingram Micro USB HDMI VGA MINI DOCK STATION YN2590
TD Synnex USB 3.0 HDMI VGA MINI DOCK STATION GIGABIT ETHERNET HD15 RJ45 4099080

Related Products

Description

Universal USB dock adds HDMI, VGA, Gigabit Ethernet and a USB port to your computer, laptop or other device with a USB-A port. The USB-A port supports USB 3.2 Gen 1 speeds up to 5 Gbps, which is 10 times faster than USB 2.0.

The USB docking station features two independent external monitor outputs (HDMI, VGA) that can be separately used to expand or mirror your computer's main desktop. The HDMI output supports video resolutions up to 2048 x 1152 at 60 Hz, including 1080p, while the VGA (VGA) port supports 1920 x 1200 at 60 Hz (1080p). Only one monitor may be used at a time. A DVI monitor can be connected to the HDMI port via an HDMI-to-DVI adapter (sold separately)

An all-in-one solution, the U342-SHG-001 also features an RJ45 port for connecting to a Gigabit Ethernet network. The USB mini dock supports true 10/100/1000 Mbps (1 Gbps) Gigabit Ethernet speeds.

The U342-SHG-001 with built-in USB cable is an ideal accessory for enhancing laptop capability for users who need to connect and manage multiple devices at home or at the office. Compatible with Windows computers and select Surface tablets.

Specifications

Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity1
Host interfaceUSB 3.2 Gen 1 (3.1 Gen 1) Type-A
USB connector typeUSB Type-A
Ethernet LAN (RJ-45) ports1
HDMI ports quantity1
VGA (D-Sub) ports quantity1
Microphone inNo
Connectivity technologyWired
Network
Ethernet LANYes
Ethernet LAN data rates10,100,1000 Mbit/s
Ethernet LAN (RJ-45) ports1
Performance
Country of originChina
Product colourBlack
Card reader integratedNo
Technical details
Product colourBlack
Sustainability certificatesRoHS
Master (outer) case GTIN (EAN/UPC)10037332185348
Products per master (outer) case40 pc(s)
Master (outer) case width17.3" (439.4 mm)
Master (outer) case gross weight18.4 lbs (8.35 kg)
Master (outer) case length13.6" (345.4 mm)
Master (outer) case height11.7" (297.2 mm)
Storage
Card reader integratedNo
Sustainability
Sustainability certificatesRoHS
Weight & dimensions
Weight2.47 oz (70 g)
Width4.87" (123.8 mm)
Depth2.13" (54 mm)
Height0.689" (17.5 mm)
Package weight6.35 oz (180 g)
Package width6.5" (165.1 mm)
Package depth5.4" (137.2 mm)
Package height1.6" (40.6 mm)
Design
Country of originChina
Product colourBlack
Packaging data
Package weight6.35 oz (180 g)
Package width6.5" (165.1 mm)
Package depth5.4" (137.2 mm)
Package height1.6" (40.6 mm)
Packaging content
ManualYes
Logistics data
Products per master (outer) case40 pc(s)
Master (outer) case width17.3" (439.4 mm)
Master (outer) case gross weight18.4 lbs (8.35 kg)
Master (outer) case length13.6" (345.4 mm)
Master (outer) case height11.7" (297.2 mm)
