Tripp Lite SU10KRT3UHV uninterruptible power supply (UPS) Double-conversion (Online) 10 kVA 9000 W

Tripp Lite SU10KRT3UHV uninterruptible power supply (UPS) Double-conversion (Online) 10 kVA 9000 W

SmartOnline 200-240V 10kVA 9kW Double-Conversion UPS, 6U, Extended Run, Network Card Slot, USB, DB9, Switch, Hardwire

Trade Prices

Distributor Product SKU Stock Updated Price
Anixter

10000VA/7000W UNISON ON-LINE3U RACKMOUNT UPSHIGH VOLTAGE

 279783 Register free see stock
ScanSource

UPS 10kVA 9kW Smart Online 6U

 POW-SU10KRT3UHV

Related Products

Description

The SU10KRT3UHV 10kVA/9000W online double-conversion UPS system offers complete power protection for critical network applications. This system delivers online, double-conversion UPS protection with zero transfer time, suitable for advanced networking applications. Fault-tolerant auto-bypass prevents unexpected service interruptions during UPS overload or internal fault conditions. Included detachable PDU with manual bypass switch enables hot-swappable replacement of entire UPS power module with no interruption to connected equipment. Enhanced availability, fault tolerance and simple hot-swap replacement options make this UPS ideal for advanced networking applications in data centers, computer rooms, network closets and rugged industrial locations.

Specifications

Power
Output power9000 W
Input operation voltage (min)200 V
Input operation voltage (max)240 V
Output operation voltage (min)200 V
Output operation voltage (max)240 V
Output power capacity10 kVA
Input frequency50/60 Hz
Performance
UPS topologyDouble-conversion (Online)
Features
Country of originChina
UPS topologyDouble-conversion (Online)
Output power9000 W
Input operation voltage (min)200 V
Input operation voltage (max)240 V
Output operation voltage (min)200 V
Output operation voltage (max)240 V
Output power capacity10 kVA
Input frequency50/60 Hz
Ports & interfaces
AC outlet typesTerminal
Battery
Typical backup time at half load12.5 min
Typical backup time at full load4.3 min
Design
Country of originChina
Form factorRackmount/Tower
Product colourBlack
Operational conditions
Operating temperature (T-T)32 - 104 °C
Storage temperature (T-T)5 - 122 °C
Operating relative humidity (H-H)0 - 95%
Technical details
Compliance certificatesRoHS
Certificates
Compliance certificatesRoHS
Weight & dimensions
Package width26" (660.4 mm)
Package depth41" (1041.4 mm)
Package height31" (787.4 mm)
Package weight327.6 lbs (148.6 kg)
Packaging data
Package width26" (660.4 mm)
Package depth41" (1041.4 mm)
Package height31" (787.4 mm)
Package weight327.6 lbs (148.6 kg)
Logistics data
Country of originChina
Products per master (outer) case1 pc(s)
Master (outer) case width26" (660.4 mm)
Master (outer) case length41" (1041.4 mm)
Master (outer) case height31" (787.4 mm)
Master (outer) case gross weight327.6 lbs (148.6 kg)
