Tripp Lite SM2200RMDVTAA uninterruptible power supply (UPS) Line-Interactive 2.2 kVA 1920 W 8 AC outlet(s)

Tripp Lite SM2200RMDVTAA uninterruptible power supply (UPS) Line-Interactive 2.2 kVA 1920 W 8 AC outlet(s)

SmartPro Line Interactive Dual Voltage Rack/Tower UPS System

Trade Prices

Distributor Product SKU Stock Updated Price
Anixter

2200VA 1920W UPS SMARTRACKMOUNT AVR 120V / 230V

 565412 Register free see stock

Related Products

Description

Tripp Lite's dual input voltage SM2200RMDVTAA line interactive UPS system maintains 120V nominal output when powered by North American 120V or International 230V input. Protects a variety of computer, networking and other sensitive equipment types from blackouts, voltage fluctuations and transient surges. 3U rack / tower form factor with an installed depth of only 22.5 inches. Expandable battery runtime with optional BP48V24-2U and BP48V60RT3U external battery packs. Uninterruptible Power Supply (UPS) switches to battery-derived AC output during power failures and extreme voltage variations. Line interactive Automatic Voltage Regulation (AVR) offers voltage boost during brownouts and voltage cut during overvoltages to maintain regulated 120v output over an input range of 89 to 148V or 212 to 286V. Includes C20 power inlet with set of 4 international cord sets and both NEMA 5-15R and 5-15/20R output receptacles. Network-grade AC surge and noise suppression. Network management interfaces support simultaneous communications via USB port, DB9 serial port and SNMPWEBCARD slot. HID-compliant USB interface enables integration with built-in power management and auto shutdown features of Windows and Mac OS X. Supports simultaneous detailed monitoring of equipment load levels, self-test data and utility power conditions via all 3 network interfaces. Includes PowerAlert monitoring software and complete cabling. Emergency Power Off (EPO) interface. Integrated 2-bank programmable PDU switching supports load shedding and remote-reboot of up to 2 individual connected devices. 3-stage metered current monitoring and battery charge status LEDs. 95% efficiency in line power mode reduces energy cost and BTU emissions. Utility power and voltage regulation LEDs. Audible alarm. Self-test. Installation accessories for rackmount and upright tower form factors included. Field-replaceable, hot-swappable internal batteries and external battery packs. Attractive all-black color scheme. 2-year warranty; extended warranty and service contracts available.

Specifications

Power
Output power1920 W
Input operation voltage (min)120 V
Input operation voltage (max)230 V
Output operation voltage (min)120 V
Output operation voltage (max)120 V
Surge energy rating340 J
Maximum current20 A
Emergency Power Off (EPO)Yes
Output power capacity2.2 kVA
Input frequency50/60 Hz
Ports & interfaces
Cable length70.9" (1.8 m)
USB portYes
AC outlets quantity8 AC outlet(s)
AC outlet typesNEMA 5–15R, NEMA 5–20R
Power plugC20 coupler
Battery
Battery typeRBC49-DV
Battery technologySealed Lead Acid (VRLA)
Battery recharge time4.5 h
Typical backup time at half load30 min
Typical backup time at full load12 min
Performance
UPS topologyLine-Interactive
WaveformPure sine
LED indicatorsYes
Audible alarm(s)Yes
Features
Country of originTaiwan
UPS topologyLine-Interactive
WaveformPure sine
Output power1920 W
Input operation voltage (min)120 V
Input operation voltage (max)230 V
Output operation voltage (min)120 V
Output operation voltage (max)120 V
Surge energy rating340 J
Maximum current20 A
Emergency Power Off (EPO)Yes
Audible alarm(s)Yes
Output power capacity2.2 kVA
Input frequency50/60 Hz
Design
Country of originTaiwan
Rack capacity3U
Form factorRackmount
LED indicatorsYes
Product colourBlack
CertificationUL1778 TAA
Cable length70.9" (1.8 m)
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 50 °C
Operating relative humidity (H-H)0 - 95%
Certificates
CertificationUL1778 TAA
Weight & dimensions
Package width30" (762 mm)
Package depth30" (762 mm)
Package height12" (304.8 mm)
Weight104.3 lbs (47.3 kg)
Width17.7" (450.8 mm)
Package weight160.1 lbs (72.6 kg)
Height5.25" (133.4 mm)
Depth25.3" (641.4 mm)
Packaging data
Package width30" (762 mm)
Package depth30" (762 mm)
Package height12" (304.8 mm)
Package weight160.1 lbs (72.6 kg)
Logistics data
Country of originTaiwan
Products per master (outer) case1 pc(s)
Master (outer) case width30" (762 mm)
Master (outer) case length30" (762 mm)
Master (outer) case height12" (304.8 mm)
Master (outer) case gross weight160.1 lbs (72.6 kg)
Other features
InterfaceUSB
Battery typeRBC49-DV
Nominal output voltage120 V
Nominal input voltage120 V
