Tripp Lite OMNIX350HG uninterruptible power supply (UPS) Line-Interactive 0.35 kVA 225 W 6 AC outlet(s)

Tripp Lite OMNIX350HG uninterruptible power supply (UPS) Line-Interactive 0.35 kVA 225 W 6 AC outlet(s)

OmniSmart 230V 350VA 225W CE/IEC 60601-1 Medical Grade Line-Interactive UPS with Built-In Isolation Transformer

Trade Prices

Distributor Product SKU Stock Updated Price
Anixter 350VA INTL UPS OMNI SMARTLINE-INTERACTIVE 230V 6 565292 Register free see stock
Ingram Micro 350VA INTL UPS OMNI SMART KD7478
ScanSource UPS OmniSmart 230V 350VA 225W POW-OMNIX350HG
TD Synnex UPS 350VA INTERNATIONAL MEDICAL UPS 230V 3153684

Related Products

Description

The OMNIX350HG offers medical-grade UPS protection with built-in line-interactive voltage regulation. IEC320 plug and outlets, plus built-in isolation transformer with Faraday shield offer full isolation and remove common mode noise. Tested to CE/IEC 60601-1 as medical electrical equipment. 350VA power handling capacity supports computers, inter-networking equipment and other critical loads during commercial power failures. Line-interactive voltage regulation corrects brownouts as low as 159V back to normal 230V levels, saving battery reserves for use only during complete power failures. Includes two-line phone surge suppression and built-in USB communications port.

This UPS contains a lead acid battery designed to be connected continuously to an AC power source, except during brief power outages. It is not intended for frequent charge/discharge cycles, such as mobile cart applications where the UPS is often disconnected from the power source. Using the OMNIX350HG in this type of application will void the battery warranty.

Specifications

Power
Output power225 W
Input operation voltage (min)159 V
Input operation voltage (max)266 V
Output operation voltage (min)230 V
Output operation voltage (max)230 V
Output power capacity0.35 kVA
Input frequency50/60 Hz
Battery
Battery typeRBC52
Typical backup time at half load37 min
Typical backup time at full load15.5 min
Performance
UPS topologyLine-Interactive
WaveformSine
LED indicatorsYes
Audible alarm(s)Yes
Features
Country of originChina
UPS topologyLine-Interactive
WaveformSine
Output power225 W
Input operation voltage (min)159 V
Input operation voltage (max)266 V
Output operation voltage (min)230 V
Output operation voltage (max)230 V
Audible alarm(s)Yes
Output power capacity0.35 kVA
Input frequency50/60 Hz
Ports & interfaces
AC outlets quantity6 AC outlet(s)
AC outlet typesC13 coupler
Power plugC14 coupler
Design
Country of originChina
Form factorTower
LED indicatorsYes
Product colourBlack
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 50 °C
Operating relative humidity (H-H)0 - 95%
Storage relative humidity (H-H)0 - 95%
Technical details
Harmonized System (HS) code85078000
Weight & dimensions
Package width10.4" (264.9 mm)
Package depth8.23" (209 mm)
Package height14.1" (358.9 mm)
Weight25.4 lbs (11.5 kg)
Width5.15" (130.8 mm)
Package weight27.3 lbs (12.4 kg)
Height10.6" (269.2 mm)
Depth7.4" (188 mm)
Packaging data
Package width10.4" (264.9 mm)
Package depth8.23" (209 mm)
Package height14.1" (358.9 mm)
Package weight27.3 lbs (12.4 kg)
Logistics data
Products per master (outer) case1 pc(s)
Master (outer) case width10.4" (264.9 mm)
Master (outer) case length8.23" (209 mm)
Master (outer) case height14.1" (358.9 mm)
Master (outer) case gross weight27.3 lbs (12.4 kg)
Harmonized System (HS) code85078000
Other features
InterfaceSerial, USB
Battery typeRBC52
Nominal output voltage230 V
Nominal input voltage230 V
