Tripp Lite SMART2200RM2U uninterruptible power supply (UPS) Line-Interactive 1.95 kVA 1950 W 7 AC outlet(s)

Tripp Lite SMART2200RM2U uninterruptible power supply (UPS) Line-Interactive 1.95 kVA 1950 W 7 AC outlet(s)

SmartPro 120V 2.2kVA 1.92kW Line-Interactive Sine Wave UPS, SNMP, Webcard option, 2U Rack/Tower, LCD, USB, DB9 Serial

Trade Prices

Distributor Product SKU Stock Updated Price
Accutech Data Supplies UPS TRPSMART2200RM2U Register free see stock
ASI Corp Tripp Lite SmartPro 2200RM2U Rackmountable UPS 2U 2200VA 1600W 8 Outlets 11074
BlueStar TRIPP LITE, EATON TRIPP LITE SERIES SMARTPRO 1950VA 1950W 120V LINE-INTERACTIVE SINE WAVE UPS - 7 OUTLETS, EXTENDED RUN, NETWORK CARD OPTION, LCD, USB, DB9, 2U RACK/TOWER UPS SMART2200RM2U
D&H 2000VA Smart Pro Rckmnt 2U UPS SMART2200RM2U
Ingram Micro UPS SMART 2200VA 1920WAVR 120V CC5506
TD Synnex UPS 2200VA SMART AVR LCD USB DB9 2URM 2546667
TD Synnex Liquidation Use Only 14306668

Related Products

Description

Tripp Lite SmartPro Line Interactive UPS with enhanced LCD interface offers network-grade power protection for critical server, network and telecommunications equipment. Line Interactive Uninterruptible Power Supply (UPS) with built-in Auto-Voltage Regulation (AVR) actively corrects brownouts and overvoltages back to usable levels while maintaining a full battery charge in case of power failure. Tripp Lite's unique configuration excels in exceptionally poor-power environments with two separate levels of voltage boost to correct both slight undervoltages and severe brownout conditions. Interactive LCD interface reports UPS operating mode, detailed UPS and site-power data, plus enables a variety of UPS setup and configuration options. Super-fast switchover from line to battery power occurs within milliseconds to maintain operation of connected equipment without interruption or reboot. 96% line-mode efficiency offers reduced heat emissions and operating costs. Network management interfaces support communications via USB, RS-232 and optional SNMPWEBCARD network interface. HID-compliant USB port enables integration with built-in power management and auto shutdown features of Windows and Mac OS X. Network communications ports enable detailed monitoring of equipment load levels, self-test data and utility power conditions. Includes PowerAlert monitoring software and complete cabling. Switched output load banks enable scheduled and real-time remote reboot and load shedding of select outlets. Emergency Power Off (EPO) interface. LCD display panel easily rotates for viewing in rackmount or tower configurations. Audible alarm with push-button momentary alarm-cancel and silent-mode configuration options. Programmable self-test. Field-replaceable, hot-swappable battery modules.
- Tripp Lite SMART2200RM2U line interactive 2U rack/tower UPS with 2200VA / 2.2kVA / 1920W capacity
- Line interactive UPS with Automatic Voltage Regulation (AVR) corrects brownouts and overvoltages from 83 to 145V
- NEMA 5-20P input plug; 4 NEMA 5-15R & 4 NEMA 5-15/20R output receptacles, Two independently switchable output load banks
- Maintains uninterrupted operation of connected networking equipment during blackouts, surges, brownouts and overvoltages
- High 96% efficiency rating in line-power mode offers reduced power consumption and BTU emisssions
- Internal batteries offer 12 minutes at 50% load (960W) and 4.5 minutes at 100% load (1920W)
- Hot-swappable, user-replaceable internal batteries can be replaced with no disruption to connected equipment
- Front panel LCD monitoring screen with MODE and ENTER buttons reports operating mode with 5-bar battery charge graphic, plus 7 selectable screens of detailed UPS and site power information
- LCD interface also supports a number of advanced user setup and operating preferences
- Ships with 4 post rackmount installation hardware; Optional 2POSTRMKITWM enables 2 post rackmount/wallmount installation; Optional 2-9USTAND enables tower placement
- Built-in USB, RS-232 and optional SNMPWEBCARD accessory monitoring options
- HID-compliant USB port enables integration with built-in power management and auto shutdown features of Windows and Mac OS X
- Included PowerAlert UPS monitoring software; Built-in Emergency Power Off (EPO) interface with cable

Specifications

Power
Output voltage regulation-14, +6%
Output power1950 W
Input operation voltage (min)83 V
Input operation voltage (max)145 V
Output operation voltage (min)100 V
Output operation voltage (max)120 V
Surge energy rating570 J
Maximum current20 A
Efficiency96%
Emergency Power Off (EPO)Yes
Power factor0.9
Output power capacity1.95 kVA
Input frequency60 Hz
Ports & interfaces
Cable length118.1" (3 m)
AC outlets quantity7 AC outlet(s)
AC outlet typesNEMA 5–15R, NEMA 5–20R
Power plugNEMA 5-20P
USB 2.0 ports quantity1
Serial ports quantity1
RS-232 ports1
Battery
Battery typeRBC94-2U
Battery technologySealed Lead Acid (VRLA)
Battery recharge time4.5 h
Typical backup time at half load12 min
Typical backup time at full load4.5 min
Hot-swap batteryYes
Cold startYes
Performance
UPS topologyLine-Interactive
WaveformSine
Automatic Voltage Regulation (AVR)Yes
Number of input phases1
LED indicatorsYes
EMI/RFI noise filteringYes
Power protection featuresOver voltage, Under voltage
Audible alarm(s)Yes
Features
Country of originTaiwan
UPS topologyLine-Interactive
WaveformSine
Output voltage regulation-14, +6%
Automatic Voltage Regulation (AVR)Yes
Number of input phases1
Output power1950 W
Input operation voltage (min)83 V
Input operation voltage (max)145 V
Output operation voltage (min)100 V
Output operation voltage (max)120 V
Surge energy rating570 J
Maximum current20 A
Efficiency96%
EMI/RFI noise filteringYes
Emergency Power Off (EPO)Yes
Power protection featuresOver voltage, Under voltage
Power factor0.9
Audible alarm(s)Yes
Output power capacity1.95 kVA
Input frequency60 Hz
Design
Country of originTaiwan
Rack capacity2U
Form factorRackmount/Tower
LED indicatorsYes
Product colourBlack
Cooling typeActive
CertificationUL1778, CSA, NOM, FCC
Cable length118.1" (3 m)
Housing materialSteel
Display typeLCD
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 50 °C
Operating relative humidity (H-H)0 - 95%
Technical details
Compliance certificatesRoHS
Cooling
Cooling typeActive
Weight & dimensions
Package width24.3" (617.2 mm)
Package depth21.3" (541 mm)
Package height8.9" (226.1 mm)
Weight57.5 lbs (26.1 kg)
Width17.3" (439.9 mm)
Package weight77.8 lbs (35.3 kg)
Height3.43" (87.1 mm)
Depth19.5" (494.3 mm)
Packaging data
Package width24.3" (617.2 mm)
Package depth21.3" (541 mm)
Package height8.9" (226.1 mm)
Package weight77.8 lbs (35.3 kg)
Logistics data
Products per master (outer) case1 pc(s)
Master (outer) case width24.3" (617.2 mm)
Master (outer) case length21.3" (541 mm)
Master (outer) case height8.9" (226.1 mm)
Master (outer) case gross weight71.9 lbs (32.6 kg)
Certificates
CertificationUL1778, CSA, NOM, FCC
Other features
InterfaceUSB; DB9
Battery typeRBC94-2U
