Tripp Lite PDUMH15-RA power distribution unit (PDU) 13 AC outlet(s) 1U Black

Tripp Lite PDUMH15-RA power distribution unit (PDU) 13 AC outlet(s) 1U Black

Single-Phase Metered PDU, 1.4kW, 100-127V, 13 x 5-15R Out, 1 x 5-15P In, 15ft Cord, 1U Rack-Mount

Trade Prices

Distributor Product SKU Stock Updated Price
BlueStar TRIPP LITE, 1.4KW SINGLE-PHASE METERED PDU, 120V OUTLETS (13 5-15R), 5-15P, 100-127V INPUT, 15FT CORD, 1U RACK-MOUNT PDUMH15-RA Register free see stock
D&H PDU 120V 13 OUT 1URM PDUMH15RA
Ingram Micro PDU METERED 1.4KW 120V 15A 1U ZG7334
TD Synnex PDU METERED 15A 120V 5-15R 5-15P 1URM 4140895

Related Products

Description

Tripp Lite Metered PDU / Power Distribution Units offer real-time local reporting of load level in amps via built-in digital meter. Enables visual current monitoring of PDU output current to prevent circuit overloads as additional equipment is added. Offers reliable rackmount multi-outlet power distribution from any protected UPS, generator or mains input power source. High quality design includes rugged all-metal housing and secure rackmount installation with included mounting accessories.

Specifications

Design
PDU typesMetered
MountingHorizontal
DisplayLCD
Product colourBlack
CertificationUL60950-1 (USA), CAN/CSA C22.2 No. 60950-1-03
Rack capacity1U
Housing materialMetal
Ports & interfaces
AC outlets quantity13 AC outlet(s)
AC outlet typesNEMA 5–15R
Power plugNEMA 5–15P
Features
Cable length179.9" (4.57 m)
LED indicatorsYes
CertificationUL60950-1 (USA), CAN/CSA C22.2 No. 60950-1-03
Ergonomics
Cable length179.9" (4.57 m)
LED indicatorsYes
DisplayLCD
Power
Nominal input voltage100-127 V
Nominal output voltage100-127 V
Maximum current15 A
AC input frequency50 - 60 Hz
Weight & dimensions
Dimensions (WxDxH)17.5 x 3.74 x 1.75" (444.5 x 95 x 44.5 mm)
Weight4.61 lbs (2.09 kg)
Width17.3" (439.4 mm)
Depth3.75" (95.2 mm)
Height1.75" (44.4 mm)
Package width20.5" (520.7 mm)
Package depth10" (254 mm)
Package height2.25" (57.2 mm)
Package weight5.2 lbs (2.36 kg)
Package dimensions (WxDxH)20.5 x 10 x 2.25" (520.7 x 254 x 57.2 mm)
Packaging data
Package width20.5" (520.7 mm)
Package depth10" (254 mm)
Package height2.25" (57.2 mm)
Package weight5.2 lbs (2.36 kg)
Package dimensions (WxDxH)20.5 x 10 x 2.25" (520.7 x 254 x 57.2 mm)
Technical details
Master (outer) case GTIN (EAN/UPC)10037332183238
Compliance certificatesRoHS
Logistics data
Master (outer) case width20.7" (527 mm)
Master (outer) case length13.7" (349.2 mm)
Master (outer) case height9.75" (247.6 mm)
Master (outer) case gross weight32.2 lbs (14.6 kg)
Products per master (outer) case6 pc(s)
Country of originChina
