Tripp Lite B123-001 AV extender AV repeater Black

Tripp Lite B123-001 AV extender AV repeater Black

  • Brand: Tripp Lite
  • Category:
  • SKU: B123-001
  • EAN: 0037332141057 0163120278220 03 ...0278220 0373321410576 0078667466996 5054629730775more
HDMI Signal Booster / Extender Cable, 1920 x 1200 (1080p) 24Hz, Up to 150 ft. (45 m), (HDMI M/F), 1 ft, TAA

Trade Prices

Distributor Product SKU Stock Updated Price
Anixter 1FT HDMI ACTIVE SIGNALEXTENDER CABLE HDMI 24HZ M/F 565117 Register free see stock
Ingram Micro 1FT HDMI SIGNAL EXTENDER CABLE N70043
ScanSource 1ft HDMI Active Signal Extende POW-B123001
TD Synnex 1FT HDMI BOOSTER/EXTENDER CABLE 1080P 2017155

Related Products

Description

The B123-001 HDMI Signal Extender increases the distance a 1080p at 24 Hz (or 1920 x 1200) signal can be transmitted beyond the recommended 16 feet (4.9 meters). It supports computer video resolutions up to 1920 x 1200 and HD resolutions up to 1080p at 24 Hz at a maximum distance of 150 feet (45.7 meters) from the source. Use P568-Series HDMI cables in most applications. When extending a 1080p at 24 Hz (or 1920 x 1200) signal more than 75 feet (22.9 meters), use cable made with 24 AWG wiring, such as the P568-100-HD. 24 AWG HDMI cable is also needed when extending a 3D signal more than 50 feet (15.2 meters). A 3D signal can be extended up to 125 feet (38.1 meters) using 24 AWG HDMI cable. Simply connect the longer cable between the source and the B123-001, and then connect the built-in cable to the monitor. The built-in HDMI cable features a latching connector for a more secure connection. Software or drivers are not required. HDCP compliant. Compatible with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases.

Specifications

Features
TypeAV repeater
Maximum resolution1920 x 1200 pixels
Cable types supportedCat5, Cat5e
Maximum transfer distance1800" (45.7 m)
Supported video modes1080p
Cable length11.8" (0.3 m)
Product colourBlack
Ports & interfaces
HDMI in1
Number of HDMI outputs1
Packaging data
Package depth4.8" (121.9 mm)
Package width6.14" (156 mm)
Package height1.3" (33 mm)
Package weight1.76 oz (50 g)
Technical details
Connector 2HDMI
Connector 1HDMI
Country of originTaiwan
Quantity1
Compliance certificatesRoHS
Logistics data
Master (outer) case width13.5" (342.9 mm)
Master (outer) case length6.42" (163.1 mm)
Master (outer) case height5.35" (135.9 mm)
Master (outer) case gross weight24.3 oz (690 g)
Products per master (outer) case10 pc(s)
Master (outer) case GTIN (EAN/UPC)10037332141054
