Tripp Lite B123-001-60 AV extender Black

Tripp Lite B123-001-60 AV extender Black

  • Brand: Tripp Lite
  • Category:
  • SKU: B123-001-60
  • EAN: 0037332171184 0373321711840 00 ...1711840 0042111205608more
HDMI Signal Booster / Extender Cable, 1920 x 1200 (1080p) 60Hz, Up to 125 ft. (38 m), (HDMI M/F), 1 ft, TAA

Trade Prices

Distributor Product SKU Stock Updated Price
Anixter 1FT HDMI ACTIVE SIGNALEXTENDER CABLE HDMI 60HZ M/F 565118 Register free see stock
ASI Corp AC B123-001-60 1ft HDMI Signal Booster Extender 1080p 60Hz M F TAA 267413
Ingram Micro 1FT HDMI SIGNAL EXTENDER CABLE PP7006
ScanSource 1ft HDMI Active Signal Extende POW-B12300160
TD Synnex 1FT HDMI BOOSTER/EXTENDER CABLE 60HZ 3291431

Related Products

Description

The B123-001-60 HDMI Signal Extender increases the distance a 1080p at 60 Hz (or 1920 x 1200) signal can be transmitted beyond the recommended 16 feet (4.9 meters). It supports computer video resolutions up to 1920 x 1200 and HD resolutions up to 1080p at 60 Hz, at a maximum distance of 125 feet (38.1 meters) from the source. Use P568-Series HDMI cables in most applications. When extending a 1080p at 60 Hz (or 1920 x 1200) signal more than 75 feet (22.9 meters), use cable made with 24 AWG wiring, such as the P568-100-HD. 24 AWG HDMI cabling is also needed when extending a 3D signal more than 50 feet (15.2 meters). A 3D signal can be extended up to 125 feet using 24 AWG HDMI cable. Simply connect the longer cable between the source and the B123-001-60, and the built-in cable between the adapter and the monitor/TV. The built-in HDMI cable features a latching connector for a more secure connection. Software or drivers are not required. HDCP compliant. Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases.

Specifications

Features
Maximum resolution1920 x 1080 pixels
Maximum transfer distance1500" (38.1 m)
Supported video modes1080p
Supported graphics resolutions1920 x 1080 (HD 1080)
Product colourBlack
Power
External power adapterYes
Operating voltage5 V
Current2 A
Packaging data
Package depth6.1" (154.9 mm)
Package width4.6" (116.8 mm)
Package height1.3" (33 mm)
Package weight4.94 oz (140 g)
Technical details
Country of originTaiwan
Logistics data
Master (outer) case width6.5" (165.1 mm)
Master (outer) case length13.4" (340.4 mm)
Master (outer) case height5.4" (137.2 mm)
Master (outer) case gross weight30.3 oz (860 g)
Products per master (outer) case10 pc(s)
Master (outer) case GTIN (EAN/UPC)10037332171181
