Tripp Lite VS650T uninterruptible power supply (UPS) Line-Interactive 0.65 kVA 360 W 6 AC outlet(s)

Tripp Lite VS650T uninterruptible power supply (UPS) Line-Interactive 0.65 kVA 360 W 6 AC outlet(s)

Tripp Lite VS650T, Line-Interactive, 0.65 kVA, 360 W, Sine, 120 V, 50/60 Hz

Trade Prices

Distributor Product SKU Stock Updated Price
Anixter

VS SERIES LINE INTERACTIVE UPS650VA/360W 120V (6) 5-15RTOWER

 10074182 Register free see stock
BlueStar

TRIPP LITE, EOL, REFER TO AVR750U, 650VA 360W LINE-INTERACTIVE UPS WITH 6 OUTLETS - AVR, VS SERIES, 120V, 50/60 HZ, TOWER

 VS650T

Related Products

Description

Tripp Lite VS650T. UPS topology: Line-Interactive, Output power capacity: 0.65 kVA, Output power: 360 W. AC outlet types: NEMA 5-15R, Power plug: NEMA 5-15P, AC outlets quantity: 6 AC outlet(s). Form factor: Tower, Product color: Black, Cable length: 59.1" (1.5 m). Width: 4" (101.6 mm), Depth: 11.8" (299.7 mm), Height: 5.6" (142.2 mm). Master (outer) case width: 14.2" (360.7 mm), Master (outer) case length: 23.6" (599.4 mm), Master (outer) case height: 9.8" (248.9 mm)

Specifications

Power
Output power360 W
Input operation voltage (max)120 V
Output operation voltage (min)110 V
Output operation voltage (max)120 V
Surge energy rating316 J
Maximum current6 A
Output power capacity0.65 kVA
Input frequency50/60 Hz
Ports & interfaces
Cable length59.1" (1.5 m)
AC outlets quantity6 AC outlet(s)
AC outlet typesNEMA 5-15R
Power plugNEMA 5-15P
Performance
Audible alarm modesFault, Overload alarm
UPS topologyLine-Interactive
WaveformSine
Automatic Voltage Regulation (AVR)Yes
Number of input phases1
LED indicatorsYes
Power protection featuresOver voltage
Audible alarm(s)Yes
Features
Country of originChina
Audible alarm modesFault, Overload alarm
UPS topologyLine-Interactive
WaveformSine
Automatic Voltage Regulation (AVR)Yes
Number of input phases1
Output power360 W
Input operation voltage (max)120 V
Output operation voltage (min)110 V
Output operation voltage (max)120 V
Surge energy rating316 J
Maximum current6 A
Power protection featuresOver voltage
Audible alarm(s)Yes
Output power capacity0.65 kVA
Input frequency50/60 Hz
Design
Country of originChina
Form factorTower
LED indicatorsYes
Product colourBlack
Cable length59.1" (1.5 m)
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 45 °C
Operating relative humidity (H-H)0 - 90%
Weight & dimensions
Package width5.5" (139.7 mm)
Package depth13.5" (342.9 mm)
Package height8.7" (221 mm)
Weight9.9 lbs (4.49 kg)
Width4" (101.6 mm)
Package weight11.1 lbs (5.04 kg)
Height5.6" (142.2 mm)
Depth11.8" (299.7 mm)
Packaging data
Package width5.5" (139.7 mm)
Package depth13.5" (342.9 mm)
Package height8.7" (221 mm)
Package weight11.1 lbs (5.04 kg)
Logistics data
Products per master (outer) case4 pc(s)
Master (outer) case width14.2" (360.7 mm)
Master (outer) case length23.6" (599.4 mm)
Master (outer) case height9.8" (248.9 mm)
Master (outer) case gross weight44.1 lbs (20 kg)
Master (outer) case GTIN (EAN/UPC)10037332212891
