Tripp Lite SMART1050TSU, Line-Interactive, 1.05 kVA, 900 W, Sine, 110 V, 120 V

Trade Prices

Distributor Product SKU Stock Updated Price
Anixter UPS SMART TOWER1050VA 900W BATTERY BACK UPDESKTOP AVR LCD USB 10259889 Register free see stock
Arlington Industries 8-OUT LCD LINE INTERACTIVE TOWER UPS TRPSMART1050TSU
D&H 1050VA 900W Line-Interactive U SMART1050TSU
Ingram Micro UPS SMART 1050VA 900WAVR LCD 6TZ534
TD Synnex 1050VA 900W UPS SMART TOWER DESKTOP AVR 5600932

Related Products

Description

Tripp Lite SMART1050TSU. UPS topology: Line-Interactive, Output power capacity: 1.05 kVA, Output power: 900 W. AC outlet types: NEMA 5–15R, AC outlets quantity: 8 AC outlet(s). Typical backup time at full load: 3 min, Typical backup time at half load: 8.5 min. Form factor: Tower, Product color: Black, Housing material: Acrylonitrile butadiene styrene (ABS). Width: 5.5" (139.7 mm), Depth: 15" (381 mm), Height: 7.5" (190.5 mm)

Specifications

Power
Output frequency50/60 Hz
Output power900 W
Input operation voltage (min)110 V
Input operation voltage (max)120 V
Output operation voltage (min)110 V
Output operation voltage (max)120 V
Surge energy rating316 J
Maximum current12 A
Power factor0.86
Output power capacity1.05 kVA
Input frequency50/60 Hz
Ports & interfaces
Cable length59.1" (1.5 m)
Serial interfaceYes
AC outlets quantity8 AC outlet(s)
AC outlet typesNEMA 5–15R
Performance
Audible alarm modesAlarm when on battery, Battery replacement, Fault, Low battery alarm, Overload alarm
UPS topologyLine-Interactive
WaveformSine
Automatic Voltage Regulation (AVR)Yes
Number of input phases1
LED indicatorsYes
EMI/RFI noise filteringYes
Surge protectionYes
Surge protection featuresDigital Subscriber Line (DSL), Network
Audible alarm(s)Yes
Features
Output frequency50/60 Hz
Country of originVietnam
Audible alarm modesAlarm when on battery, Battery replacement, Fault, Low battery alarm, Overload alarm
UPS topologyLine-Interactive
WaveformSine
Automatic Voltage Regulation (AVR)Yes
Number of input phases1
Output power900 W
Input operation voltage (min)110 V
Input operation voltage (max)120 V
Output operation voltage (min)110 V
Output operation voltage (max)120 V
Surge energy rating316 J
Maximum current12 A
EMI/RFI noise filteringYes
Surge protectionYes
Surge protection featuresDigital Subscriber Line (DSL), Network
Power factor0.86
Audible alarm(s)Yes
Output power capacity1.05 kVA
Input frequency50/60 Hz
Battery
Typical backup time at half load8.5 min
Typical backup time at full load3 min
Cold startYes
Design
Country of originVietnam
Form factorTower
LED indicatorsYes
Product colourBlack
Cooling typeActive
Cable length59.1" (1.5 m)
Built-in fanYes
Housing materialAcrylonitrile butadiene styrene (ABS)
Display typeLCD
Operational conditions
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-15 - 45 °C
Operating relative humidity (H-H)0 - 90%
Storage relative humidity (H-H)0 - 90%
Technical details
Output frequency50/60 Hz
Cooling
Cooling typeActive
Built-in fanYes
Weight & dimensions
Package width9.3" (236.2 mm)
Package depth19.5" (495.3 mm)
Package height11.7" (297.2 mm)
Weight23.1 lbs (10.5 kg)
Width5.5" (139.7 mm)
Package weight24.3 lbs (11 kg)
Height7.5" (190.5 mm)
Depth15" (381 mm)
Packaging data
ManualYes
Cables includedRS-232, USB cable
Package width9.3" (236.2 mm)
Package depth19.5" (495.3 mm)
Package height11.7" (297.2 mm)
Package weight24.3 lbs (11 kg)
Logistics data
Products per master (outer) case1 pc(s)
Master (outer) case width9.3" (236.2 mm)
Master (outer) case length19.5" (495.3 mm)
Master (outer) case height11.7" (297.2 mm)
Master (outer) case gross weight24.3 lbs (11 kg)
Packaging content
ManualYes
Cables includedRS-232, USB cable
